Datasheet> All Categories > Discrete semiconductor> diode> MBR20060CT

Preview

MBR20060CT: Descriptionschottky diodes & rectifiers 60v 200a schottky recovery; CategoryDiscrete semiconductor diode; File Size760KB，3 Pages; ManufacturerGeneSiC; Websitehttp://www.genesicsemi.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

MBR20060CT Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MBR20060CT	-	-	View	Buy Now

MBR20060CT Overview

schottky diodes & rectifiers 60v 200a schottky recovery

MBR20060CT Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	GeneSiC
package instruction	R-PUFM-X2
Reach Compliance Code	compli
ECCN code	EAR99
application	POWER
Shell connection	CATHODE
Configuration	COMMON CATHODE, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	0.75 V
JESD-30 code	R-PUFM-X2
Maximum non-repetitive peak forward current	1500 A
Number of components	2
Phase	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-40 °C
Maximum output current	100 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum repetitive peak reverse voltage	60 V
Maximum reverse current	5000 µA
surface mount	NO
technology	SCHOTTKY
Terminal form	UNSPECIFIED
Terminal location	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

MBR20045CT thru MBR200100CTR

Silicon Power

Schottky Diode

Features

• High Surge Capability

• Types up to 100 V V

RRM

Twin Tower Package

V

RRM

= 20 V - 100 V

I

F

= 200 A

Maximum ratings, at T

j

= 25 °C, unless otherwise specified ("R" devices have leads reversed)

Parameter

Repetitive peak reverse

voltage

RMS reverse voltage

DC blocking voltage

Continuous forward

current

Surge non-repetitive

forward current, Half

Sine Wave

Operating temperature

Storage temperature

Symbol

V

RRM

V

RMS

V

DC

I

F

T

C

≤

136 °C

Conditions

MBR20045CT (R) MBR20060CT (R) MBR20080CT (R) MBR200100CT (R) Unit

45

32

45

200

1500

-40 to 175

60

42

60

200

1500

-40 to 175

80

56

80

200

1500

-40 to 175

100

70

100

200

1500

-40 to 175

V

A

°C

I

F,SM

T

C

= 25 °C, t

p

= 8.3 ms

T

j

T

stg

Electrical characteristics, at Tj = 25 °C, unless otherwise specified

Parameter

Diode forward voltage

Reverse current

Symbol

V

F

I

R

Conditions

I

F

= 100 A, T

j

= 25 °C

V

R

= 20 V, T

j

= 25 °C

V

R

= 20 V, T

j

= 125 °C

MBR20045CT (R) MBR20060CT (R) MBR20080CT (R) MBR200100CT (R) Unit

0.65

5

200

0.75

5

200

0.84

5

200

0.84

5

200

V

mA

Thermal characteristics

Thermal resistance,

junction - case

R

thJC

0.5

°C/W

www.genesicsemi.com

1
