SFAF501G - SFAF508G
5.0AMPS. Isolated Glass Passivated Super Fast Rectifiers
ITO-220AC
Features
UL Recognized File # E-326243
High efficiency, low VF.
High current capavility
High reliability
High surge current capability
Low power loss.
For use in low voltage, high frequency inverter, free
wheeling, and polarity protection application
Green compound with suffix "G" on packing
code & prefix "G" on datecode.
Mechanical Data
Case: ITO-220AC molded plastic
Epoxy: UL 94V-0 rate flame retardant
Terminals: Pure tin plated, lead free, solderable per
MIL-STD-202, Method 208 guaranteed
Polarity: As marked
High temperature soldering guaranteed:
260
o
C/10 seconds .16".,(4.06mm) from case.
Weight: 1.70 grams
Ordering Information(example)
Part No.
Package
Packing
50 / TUBE
Packing code
C0
Packing code
(Green)
C0G
SFAF501G ITO-220AC
Maximum Ratings and Electrical Characteristics
Rating at 25
℃
ambient temperature unless otherwise specified.
Parameter
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
Peak Forward Surge Current, 8.3 ms Single Half Sine-wave
Superimposed on Rated Load (JEDEC method)
Maximum Instantaneous Forward Voltage (Note 1)
@5A
Maximum DC Reverse Current
at Rated DC Blocking Voltage
Typical Junction Capacitance (Note 3)
Typical Thermal Resistance
Operating Temperature Range
Storage Temperature Range
Note 1: Pulse Test with PW=300 usec, 1% Duty Cycle
@ T
A
=25
℃
@ T
A
=125
℃
Symbol
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
Trr
Cj
R
θJC
T
J
T
STG
SFAF
501G
50
35
50
SFAF
502G
100
70
100
SFAF
503G
150
105
150
SFAF
504G
200
140
200
5
SFAF
505G
300
210
300
SFAF
506G
400
280
400
SFAF
507G
500
350
500
SFAF
508G
600
420
600
Units
V
V
V
A
A
125
0.975
10
400
35
70
5.0
- 65 to + 150
- 65 to + 150
O
1.3
1.7
V
uA
uA
nS
pF
C/W
O
O
Maximum Reverse Recovery Time (Note 2)
C
C
Note 2: Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A.
Note 3: Measured at 1 MHz and Applied Reverse Voltage of 4.0V D.C.
Version:E12
RATINGS AND CHARACTERISTIC CURVES (SFAF501G THRU SFAF508G)
FIG.1- MAXIMUM FORWARD CURRENT DERATING
CURVE
AVERAGE FORWARD CURRENT (A)
FIG. 2- TYPICAL REVERSE CHARACTERISTICS
1000
6
5
INSTANTANEOUS REVERSE CURRENT. (uA)
4
3
2
1
0
0
50
100
150
CASE TEMPERATURE (
o
C)
RESISTIVE OR
INDUCTIVELOAD
WITH HEAT SINK
100
TA=100℃
10
TA=75℃
1
TA=25℃
PEAK FORWARD SURGE CURRENT.
(A)
FIG. 3- MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
150
120
90
60
0.1
0
20
40
60
80
100
120
140
8.3ms Single Half Sine Wave
JEDEC Method
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
FIG. 5- TYPICAL FORWARD CHARACTERISTICS
30
TA=25℃
0
1
10
NUMBER OF CYCLES AT 60 Hz
100
100
SFAF805G-SFAF806G
INSTANTANEOUS FORWARD CURRENT. (A)
FIG. 4- TYPICAL JUNCTION CAPACITANCE
100
90
CAPACITANCE (pF)
80
70
60
50
40
1
10
100
1000
REVERSE VOLTAGE. (V)
10
SFAF801G-SFAF804G
TA=25
o
C
1
SFAF807G-SFAF808G
TA=25
o
C
Pulse Width=300us
1% Duty Cycle
0.4
0.6
0.8
1
1.2
1.4
FORWARD VOLTAGE. (V)
1.6
1.8
0.1
Version:E12
