CZM1-100 Series
Surface Mount Voltage Controlled Oscillators
FEATURES:
!
Surface Mount/Tape & Reel
!
Small .5” x .5” x .1” Size
!
Linear Wideband Tuning Range
!
Low Cost
!
Standard Pad Locations
!
-40°C to 85°C Operating Temperature
!
3.3V & 5V parts also available -
Please
Contact Champion
The
CZM1-100
is a fundamental mode reflection oscillator that utilizes a silicon bipolar transis-
tor and hyper-abrupt silicon varactor diodes to create a highly linear VCO with wideband tuning
characteristics. The device is useful for many wireless applications where high frequency and
linear modulation is required.
The process is very repeatable from unit to unit and assembled in ISO 9001 approved manu-
facturing facility with the latest surface mount equipment. Every unit is DC and RF tested with
our fully automated computerized test stations to provide the highest reliabile product.
E L E C T R I C A L S P E C I F I C AT I O N S
Model
Parameter
Frequency Range
Tuning Voltage
RF Output Power
Supply Voltage
Supply Current
Phase Noise
Modulation Sensitivity
Tuning Linearity
Modulation Bandwidth
Harmonics
Frequency Pushing
Frequency Pulling
Frequency Drift
Tuning Input Capacitance
Absolute Maximum Ratings
Supply Voltage
Tuning Voltage
Storage Temperature
Solder Assembly Temperature
V
V
oC
-45
230oC for 10 secs.
+15
+22
95
3dB BW
2nd
VCC = 7.75 to 8.25
1.5:1 VSWR
-40o to 85oC
Test Condition
VC = 0V to 20V
Vt
75 - 180MHz
VCC
ICC
ssb @ 10KHz
Vt = 1-12V
Units
MHz
V
dBm
V
mA
dBc/Hz
MHz/V
ratio
MHz
dBC
MHz/V
MHz
MHz
pF
3
27
CZM1-100
Min
75
0
+9
+12
+12
32
-106
7
1.5
3
-15
1
2
-8
2.6
50
Typical
Max
180
+20
+15
PA R T N U M B E R I N G G U I D E
CZM1-100-xxx
Part Number Assigned by Champion; Based
on Customer Requirements
2553 N. Edgington Street, Franklin Park, IL 60131
"
Phone: 847.451.1000
"
Fax: 847.451.7585
800-888-1499 or www.champtech.com
1
CZM1-100 Series
Surface Mount Voltage Controlled Oscillators
Notes:
!
Exceeding Limits may cause permanent damage.
!
A series dropping resistor will allow operation at higher voltage
!
External bypassing of both Vcc and Vt can improve phase noise performance and power supply
decoupling.
!
Specifications subject to change without notice.
MECHANICAL AND ENVIRONMENTAL SPECIFICATIONS
TEST METHODS
Temperature Cycle
Mechanical Shock
Vibration
Humidity Steady State
Thermal Shock
Electrostatic Discharge
Solderability
Hermeticity
Resistance to Soldering
Lead Integrity
Marking Permanence
Life Test
REFERENCE PROCEDURES
MIL-STD-833, Mtd 1010, Cond. B
MIL-STD-202, Mtd 213, Cond. D
MIL-STD 202, Mtd 204, Cond. B
MIL-STD-202, Mtd 103
MIL-STD-883, Mtd 1011.7 Cond. A
MIL-STD-883, Mtd 3015 Class II
MIL-STD-883, Mtd 2022.2
MIL-STD-883, Mtd 1014.8, Cond. A1
DESCRIPTION
-55°C to +125°C; Air-to-Air; 100 cycles; 10 min.
dwell
500 g’s
10-2000 Hz; 0.06 inch; 15g; 3 planes
40°C; 90%-95% R.H.; 56 days
100°C to 0°C; Water-to-Water; 15 cycles
2 KV to 4 KV Threshold
Solder dip; Meniscograph Criteria
Mass spectro. 2 x 10-8 atmos. CC/sec He
MIL-STD-202, Mtd 210D, Cond. J
235°C; 30 seconds
MIL-STD-883, Mtd 2004.5, Cond. A, B1 Lead tension & bend stress
MIL-STD-883, Mtd 2015.8
MIL-STD-883, Mtd 1005.6
Resistance to solvents
125
°C, powered, 1000 hours minimum
2553 N. Edgington Street, Franklin Park, IL 60131
"
Phone: 847.451.1000
"
Fax: 847.451.7585
800-888-1499 or www.champtech.com
2
