Ceramic SMD Crystal Oscillator
SMD 5.0 x 3.2mm CMOS
F
EATURE
Output Logic: CMOS
Small SMD Ceramic Package
High precision and high frequency stability
MO5M series
Applications: Wireless, Mobile Communication, WiMAX, WLAN, PDA,
DSD, Notebook
P
ART
N
UMBERING
S
YSTEM
MO5 M 33
(1)
No
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(2)
(3)
J
(4)
Item
C
(5)
50M0
(6)
Code
MO5
M
33
J
C
50M0
Blank
Blank
Blank
Description
Oscillator Unit
M: CMOS
33: 3.3V
J: ±50ppm
C: -20~+70ºC
50M0: 50.000MHz
Blank: Tri-State
Blank: 15pF
Blank: 45/55%
Series Reference (options)
Ceramic SMD Crystal Oscillator 5.0x3.2mm 4 Pads
M: CMOS
25: 2.5V, 18: 1.8V
F: ±20ppm, G: ±25ppm, H: ±30ppm (see avail options)
A: -10~+60ºC, B: 0~+70ºC, I: -40~+85ºC (see options)
13K7 ~ 133M0 (K and M denotes decimal point)
N: No Connection
Blank: 15pF (Standard)
T: 40/60%
Meritek Series
Logic
Supply Voltage
Frequency Stability
Operating Temp.
Frequency
Pin 1
Output Load
Duty Cycle
D
IMENSIONS AND
R
ECOMMENDED
P
ATTERN
Pin
1
2
3
4
(Unit:mm)
Function
Tri-State Enable/Disable
GND/Case
Output
Vdd
A
VAILABLE
O
PTIONS
Parameters
Supply Voltage
Frequency Stability
Operating Temp.
Part Number Options
18: 1.8V±10%, 25: 2.5V±10%, 33: 3.3V±10%
F: ±20ppm, G: ±25ppm, H: ±30ppm, J: ±50ppm, K: ±100ppm
A: -10~+60C, B: 0~+70C, C: -20~+70C, K: -30~+85C, I: -40~+85C, R: -40~+105C
Note: Custom options available. Contact Meritek for more information.
E
LECTRICAL
C
HARACTERISTICS
Parameters
Frequency Range
Logic
Supply Voltage
Frequency Stability
Meritek Electronics Corporation
|
www.meritekusa.com
Characteristic
0.0137 ~ 133.000 MHz
CMOS
3.3V ±10% (see options)
±50 ppm (see options)
Rev.8a 04/02/2018
Ceramic SMD Crystal Oscillator
SMD 5.0 x 3.2mm CMOS
Operating Temperature
Storage Temperature
Duty Cycle
Aging @25°C (first year)
Output Load
Ouput Level (CMOS)
Supply Current
Standby Current
Start Up Time
13.70 KHz ~ 70.00 KHz
Rise/ Fall Time (Tr/Tf)
0.3125 MHz ~ 99.99 MHz
100.0MHz ~ 133.0MHz
Tri-State (Input Pin 1)
Enable High or Float
Disable Low or GND
High (Logic 1)
Low (Logic 0)
MO5M series
-20 ~ +70°C (see options)
-55 ~ +125°C
50±5%
±3 ppm
15pF max.
90% Vdd min.
10% Vdd max.
See Table 1
10µA max.
10mSec max. (5 Typ.)
50nSec max.
7nSec max. (5 Typ.)
7nSec max. (3 Typ.)
0.7 Vdd min.
0.3 Vdd max.
40pSec max.
1pSec max.
Absolute Clock Period Jitter
RMS Phase Jitter (12Khz~20MHz)
T
ABLE 1: SUPPLY CURRENT
Frequency
13.70 KHz ~ 93.00 KHz
0.3125 MHz ~ 39.99 MHz
40.00 MHz ~ 74.99 MHz
75.00 MHz ~ 133.00 MHz
3.3V
1
10
20
35
(mA max.)
2.5V
0.5
8
18
30
1.8V
0.1
7
15
25
R
ECOMMENDED
S
OLDERING
P
ROFILES
Reflow Condition
Pre
Heat
Temp. Min T
s(min)
Temp. Max T
s(max)
Time (min. to max.) (t
s
)
150°C
180°C
60~120 seconds
1°C/second max.
3°C/second max.
230°C
30~40 seconds
260°C
10 seconds max.
6°C/second
Average ramp up rate (T
L
) to peak
T
s(max)
to T
L
(Ramp-up rate)
Reflow
Temp. (T
L
)
Time (min. to max.) (t
L
)
Peak Temperature (T
P
)
Time within 5°C of actual peak
Temperature (t
p
)
Ramp-down Rate
*Specifications subject to change without notice.
Meritek Electronics Corporation
|
www.meritekusa.com
Rev.8a 04/02/2018
