MAX8877EUK25+T Overview

ldo voltage regulators 150ma linear regulator

MAX8877EUK25+T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Maxim
Parts packaging code	SOT-23
package instruction	LSSOP, TSOP5/6,.11,37
Contacts	5
Reach Compliance Code	compli
ECCN code	EAR99
Factory Lead Time	6 weeks
Adjustability	FIXED
Maximum drop-back voltage 1	0.12 V
Nominal dropback voltage 1	0.165 V
Maximum absolute input voltage	7 V
Maximum input voltage	6.5 V
Minimum input voltage	2.6 V
JESD-30 code	R-PDSO-G5
JESD-609 code	e3
length	2.9 mm
Maximum grid adjustment rate	0.0146%
Maximum load regulation	0.12%
Humidity sensitivity level	1
Number of functions	1
Output times	1
Number of terminals	5
Working temperatureTJ-Max	150 °C
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current 1	0.15 A
Maximum output voltage 1	2.55 V
Minimum output voltage 1	2.425 V
Nominal output voltage 1	2.5 V
Package body material	PLASTIC/EPOXY
encapsulated code	LSSOP
Encapsulate equivalent code	TSOP5/6,.11,37
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH
method of packing	TAPE AND REEL
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Maximum seat height	1.45 mm
surface mount	YES
technology	CMOS
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.95 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum voltage tolerance	3%
width	1.625 mm

Preview

Download Datasheet

View All

19-1301; Rev 2; 1/01

Low-Noise, Low-Dropout, 150mA Linear

Regulators with '2982 Pinout

__________________General Description

The MAX8877/MAX8878 low-noise, low-dropout linear

regulators operate from a 2.5V to 6.5V input and deliver

up to 150mA. These devices are pin-compatible with

the industry-standard '2982 and offer an improved

dropout voltage. Typical output noise is 30µV

RMS

, and

typical dropout is only 165mV at 150mA. The output

voltage is preset to voltages in the range of 1.5V to

5.0V, in 100mV increments.

Designed with an internal P-channel MOSFET pass

transistor, the MAX8877/MAX8878 maintain a low

100µA supply current, independent of the load current

and dropout voltage. Other features include a 10nA

logic-controlled shutdown mode, short-circuit and ther-

mal-shutdown protection, and reverse battery protec-

tion. The MAX8878 also includes an auto-discharge

function, which actively discharges the output voltage

to ground when the device is placed in shutdown. Both

devices come in regular and thin 5-pin SOT23 pack-

ages.

____________________________Features

Pin-Compatible with the Industry-Standard '2982

Low Output Noise: 30µV

RMS

Low 55mV Dropout at 50mA Output

(165mV at 150mA output)

Low 85µA No-Load Supply Current

Low 100µA Operating Supply Current

(even in dropout)

Thermal-Overload and Short-Circuit Protection

Reverse Battery Protection

Output Current Limit

Preset Output Voltages (±1.4% Accuracy)

10nA Logic-Controlled Shutdown

MAX8877/MAX8878

________________________Applications

Cellular Telephones

Cordless Telephones

PCS Telephones

PCMCIA Cards

Modems

Hand-Held Instruments

Palmtop Computers

Electronic Planners

_________________Ordering Information

PART**

MAX8877C/Dxy

MAX8877EUKxy-T

MAX8877EZKxy-T

MAX8878C/Dxy

MAX8878EUKxy-T

TEMP.

RANGE

0°C to +70°C

-40°C to +85°C

0°C to +70°C

-40°C to +85°C

PIN-PACKAGE

Dice*

5 SOT23-5 Regular

5 SOT23-5 Thin

Dice*

5 SOT23-5 Regular

MAX8878EZKxy-T

-40°C to +85°C 5 SOT23-5 Thin

*Dice

are tested at T

= +25°C only.

**xy

is the output voltage code (see Expanded Ordering

Information table at end of data sheet).

____________Typical Operating Circuit

INPUT

2.5V TO 6.5V

1µF

OFF

0.01µF

OUT

3.3µF

OUTPUT

PRESET

1.5V TO 5.0V

150mA

_____________________Pin Configuration

TOP VIEW

OUT

MAX8877

MAX8878

SHDN

GND

MAX8877

MAX8878

SHDN

SOT23-5

REGULAR AND THIN

________________________________________________________________

Maxim Integrated Products

For price, delivery, and to place orders, please contact Maxim Distribution at 1-888-629-4642,

or visit Maxim’s website at www.maxim-ic.com.
