IS31AP4996
ABSOLUTE MAXIMUM RATINGS
(Note 1)
Supply voltage, V
CC
Voltage at any input pin
Maximum junction temperature, T
JMAX
Storage temperature range, T
STG
Operating temperature range, T
A
Maximum power dissipation, SOP-8(25°C/85°C) (Note 2)
MSOP-8(25°C/85°C)
-0.3V
~ +6.0V
-0.3V
~ V
CC
+0.3V
150°C
-65°C
~ +150°C
−40°C
~ +85°C
720mW/380mW
590mW/310mW
Note 1:
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. These are stress ratings
only and functional operation of the device at these or any other condition beyond those indicated in the operational sections of the specifications
is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
Note 2:
Thermal simulation @ 25°C /85°C ambient temperature, still air convection, 2s2p boards according to JESD51. The Pd (max by package)
is evaluated by (Tjmax-Ta)/Theta-Ja.
ELECTRICAL CHARACTERISTICS
The following specifications apply for C
IN
= 0.1μF, R
IN
= R
F
= 20kΩ, C
BYPASS
= 0.47μF, unless otherwise specified.
Limits apply for T
A
= 25°C. V
CC
=5V (Note 3 or specified)
Symbol
I
CC
I
SD
V
SD_H
V
SD_L
V
OS
Po
t
WU
THD+N
PSRR
Parameter
Quiescent power supply current
Standby current
Shutdown voltage input high
Shutdown voltage input low
Output offset voltage
Output power (8Ω)
Wake-up time
(Note 4)
Total harmonic distortion+noise
(Note 4)
Power supply rejection ratio
(Note 4)
THD+N = 1%; f = 1kHz
THD+N = 10%; f = 1kHz
C
BYPASS
= 0.47μF
Po = 0.5Wrms; f = 1kHz
Vripple p-p = 200mV
Input Grounded
f = 217Hz
f = 1kHz
1.15
1.40
100
0.074
56
68
250
Condition
Io = 0A, no Load
V
SD
= V
CC
, R
L
=
∞
V
CC
= 5.5V
V
CC
= 2.7V
1.4
0.4
15
Min.
Typ.
3.0
2
Max.
Unit
mA
μA
V
V
mV
W
ms
%
dB
The following specifications apply for C
IN
= 0.1μF, R
IN
= R
F
= 20kΩ, C
BYPASS
= 0.47μF, unless otherwise specified.
Limits apply for T
A
= 25°C. V
CC
=3V (Note 3 or specified)
Symbol
I
CC
I
SD
Po
t
WU
THD+N
Parameter
Quiescent power supply current
Standby current
Output power (8Ω)
Wake-up time
(Note 4)
Total harmonic distortion+noise
(Note 4)
Condition
Io = 0A, no Load
V
SD
= V
CC
, R
L
=
∞
THD+N = 1%; f = 1kHz
THD+N = 10%; f = 1kHz
C
BYPASS
= 0.47μF
Po = 0.3Wrms; f = 1kHz
380
490
90
0.076
200
Min.
Typ.
2.2
2
Max.
Unit
mA
μA
mW
ms
%
Note 3:
Production testing of the device is performed at 25°C. Functional operation of the device and parameters specified over other
temperature range, are guaranteed by design, characterization and process control.
