LCD-016N002D
Vishay
16 x 2 Character LCD
FEATURES
• Type: Character
• Display format: 16 x 2 characters
• Built-in controller: KS 0066 (or equivalent)
• Duty cycle: 1/16
• 5 x 8 dots includes cursor
• + 5 V power supply
• LED can be driven by pin 1, pin 2, or A and K
• Optional: Smaller character size (2.95 mm x 4.35 mm)
• Compliant to RoHS directive 2002/95/EC
MECHANICAL DATA
ITEM
Module Dimension
Viewing Area
Dot Size
Dot Pitch
Mounting Hole
Character Size
STANDARD VALUE
85.0 x 30.0
66.0 x 16.0
0.55 x 0.65
0.60 x 0.70
81.0 x 24.0
2.96 x 5.56
mm
UNIT
ABSOLUTE MAXIMUM RATINGS
ITEM
SYMBOL
STANDARD VALUE
MIN.
- 0.3
- 0.3
TYP.
-
-
MAX.
7.0
V
DD
UNIT
Power Supply V
DD
to V
SS
Input Voltage
V
I
Note
• V
SS
= 0 V, V
DD
= 5.0 V
V
ELECTRICAL CHARACTERISTICS
ITEM
Input Voltage
Supply Current
SYMBOL
V
DD
I
DD
CONDITION
V
DD
= + 5 V
V
DD
= + 5 V
- 20 °C
Recommended LC Driving
Voltage for Normal Temperature
Version Module
0 °C
V
DD
to V
0
25 °C
50 °C
70 °C
LED Forward Voltage
LED Forward Current - Array
LED Forward Current - Edge
EL Power Supply Current
V
F
I
F
I
EL
25 °C
25 °C
V
EL
= 110 V
AC
, 400 Hz
STANDARD VALUE
MIN.
4.7
-
-
-
-
3.5
3.2
-
-
-
-
TYP.
5.0
1.2
-
-
3.8
-
-
4.2
100
20
-
MAX.
5.3
1.5
5.2
4.2
-
-
-
4.6
-
40
5.0
V
mA
mA
V
UNIT
V
mA
OPTIONS
PROCESS COLOR
TN
x
STN
Gray
x
STN
Yellow
x
STN
Blue
x
FSTN
B&W
STN
Color
None
x
BACKLIGHT
LED
x
EL
x
CCFL
For detailed information, please see the “Product Numbering System” document.
Document Number: 37297
Revision: 29-Oct-08
For technical questions, contact:
displays@vishay.com
www.vishay.com
