D-subminiature
Accessories
Dust Caps
•
•
•
For use with all Cinch D-subminiature connectors.
Used to protect connector contacts when connector is not mated.
Made of polyethylene (black).
Ordering Information
Fits
Shell
Size
E
E
A
A
B
B
C
C
D
D
Fits
Standard
Density Catalog No. Description
9
DE-59-20
Socket
9
DE-60-20
Plug
15
DA-59-20
Socket
15
DA-60-20
Plug
25
DB-59-20
Socket
25
DB-60-20
Plug
37
DC-59-20
Socket
37
DC-60-20
Plug
50
DD-59-20
Socket
50
DD-60-20
Plug
A
in
.694
.749
1.022
1.077
1.562
1.635
2.210
2.283
2.116
2.179
mm
17.63
19.02
25.95
27.36
39.67
41.52
56.13
57.99
53.75
55.35
in
.627
.682
.955
1.010
1.495
1.568
2.143
2.216
2.049
2.112
B
mm
15.93
17.32
24.25
25.65
37.97
39.83
54.43
56.29
52.04
53.64
in
.362
.412
.362
.412
.362
.430
.362
.430
.474
.536
C
mm
9.19
10.46
9.19
10.46
9.19
10.92
9.19
10.92
12.04
13.61
D
in
mm
.295
7.49
.345
8.76
.295
7.49
.345
8.76
.295
7.49
.363
9.22
.295
7.49
.363
9.22
.407 10.34
.469 11.91
Guide Pin Plates
•
Aligns connectors before actual mating. Generally used in blind mate applications.
•
•
•
•
Male or female guide plates will accommodate Cinch male or female connectors.
Plate: Cold-rolled steel with cadmium plating and yellow chromate finish.
Guide pin (male): Stainless steel, passivated.
Screws, rivets (male plate), washers (male plate): Steel with cadmium plating and yellow chromate finish.
Plug
Socket
Ordering Information
Fits
Shell Standard
Size Density
E
A
B
C
D
9
15
25
37
50
A
Plug
N/A
DA-22213
DB-22255
DC-22070
DD-21962
Socket
N/A
DA-22214
DB-22254
DC-22071
DD-21961
2.281 57.93
2.820 71.63
3.468 88.09
3.375 85.73
in
mm
in
B
mm
C
in
mm
in
D
mm
in
F
mm
in
G
mm
K
in
mm
1.000 25.40
1.000 25.40
1.000 25.40
1.125 28.58
1.312 33.32
1.852 47.04
2.500 63.50
2.406 61.112
.750 19.05
.750 19.05
.750 19.05
.874 21.88
.898
1.168
1.492
1.437
22.81
29.67
37.90
36.50
1.663 42.24
2.203 55.96
2.851 72.42
2.749 69.82
1.906 48.41
2.446 62.13
3.094 78.59
3.000 76.20
Call Toll Free: 1 (800) 323-9612
4-96
