MAX16962RATEA/V+T Overview

voltage regulators - switching regulators 4A 2.2mhz sync SD DC-DC cnvtr

MAX16962RATEA/V+T Parametric

Parameter Name	Attribute value
Manufacture	Maxim Integrated
Product Category	Voltage Regulators - Switching Regulators
RoHS	Yes
Packaging	Reel
Factory Pack Quantity	2500

Preview

Download Datasheet

View All

MAX16962

4A, 2.2MHz, Synchronous Step-Down

DC-DC Converter

General Description

The MAX16962 is a high-efficiency, synchronous step-

down converter that operates with a 2.7V to 5.5V input

voltage range and provides a 0.8V to 3.6V output voltage

range. The wide input/output voltage range and the abil-

ity to provide up to 4A to load current make this device

ideal for on-board point-of-load and post-regulation

applications. The MAX16962 achieves -3.7%/+2.6% out-

put error over load, line, and temperature ranges.

The MAX16962 features a 2.2MHz fixed-frequency PWM

mode for better noise immunity and load transient

response, and a pulse frequency modulation mode

(SKIP) for increased efficiency during light-load opera-

tion. The 2.2MHz frequency operation allows for the use

of all-ceramic capacitors and minimizes external compo-

nents. The optional spread-spectrum frequency modula-

tion minimizes radiated electromagnetic emissions.

Integrated low R

DSON

switches improve efficiency at

heavy loads and make the layout a much simpler task

with respect to discrete solutions.

The MAX16962 is offered with factory-preset output

voltages or with an adjustable output voltage. (See the

Selector Guide

for options). Factory preset output volt-

age versions allow customers to achieve -3.7%/+2.6%

output voltage accuracy without using external resistors,

while the adjustable output voltage version provides the

flexibility to set the output voltage to any desired value

between 0.8V to 3.6V using an external resistive divider.

Additional features include 8ms soft-start, 16ms power-

good output delay, overcurrent, and overtemperature

protections.

The MAX16962 is available in thermally enhanced

16-pin TSSOP-EP and 4mm x 4mm, 16-pin

TQFN-EP packages, and is specified for operation over

the -40NC to +125NC automotive temperature range.

Benefits and Features

Small External Components



2.2MHz Operating Frequency

Ideal for Point-of-Load Applications



4A Maximum Load Current



Adjustable Output Voltage: 0.8V to 3.6V



2.7V to 5.5V Operating Supply Voltage

High Efficiency at Light Load



26µA Skip Mode Quiescent Current

Minimizes Electromagnetic Interference



Programmable SYNC I/O Pin



Operates Above AM-Radio Band



Available Spread Spectrum

Low Power Mode Saves Energy



1µA Shutdown Current



Open-Drain Power-Good Output

Limits Inrush Current During Startup



Soft-Start

Overtemperature and Short-Circuit Protections

4mm x 4mm, 16-Pin Thin QFN and 16-Pin TSSOP

Packages

-40°C to 125°C Operating Temperature Range

Applications

Automotive Infotainment

Point-of-Load Applications

Industrial/Military

Typical Application Circuit

PV1

4.7µF

OUTS

0.47µH

LX1

LX2

PGND1

10Ω

1µF

GND

PGND2

OUT1

20kΩ

OUT1

47µF

Ordering Information

appears at end of data sheet.

PV2

MAX16962

For pricing, delivery, and ordering information, please contact Maxim Direct

at 1-888-629-4642, or visit Maxim’s website at www.maximintegrated.com.

19-6213; Rev 3; 7/15
