Pin-Indicating Type
Fast-Acting
1
⁄
4
˝ x 1
1
⁄
4
˝ (6.3mm x 32mm)
Dimensions - in
GLD/GBA
Time-Current Characteristic Curves–Average Melt
100
AMP
RATING
0.75
1
8
10
1.27"
(±0.031)
(32.2mm)
(not blown)
1.44"
(36.5mm)
(blown)
10
(Approximate)
0.255" Max
0.249˝ Min
TIME IN SECONDS
Electrical Ratings (Catalog Symbol and Amps)
GLD-
1
⁄
2
GLD- ⁄
4
3
CURRENT IN AMPS
GLD-6
GLD-10
GLD-12
GLD-15
GBA-6
GBA-10
GBA-15
GLD-2
GLD-3
GLD-4
1
GLD-1
GLD-1- ⁄
2
GBA-
1
⁄
2
GBA- ⁄
4
3
GLD-5
GBA-2
GBA-3
GBA-4
GBA-1
GBA-1- ⁄
2
1
GBA-5
Carton
Qty.
100
Weight
Amp
Ratings
1
Carton Quantity and Weight
⁄
2-
15
Lbs.
0.86
0.390
Kg.
General Information:
• Use in power electronic circuits in which a fuse opening must
be quickly apparent.
• Opening of fuse results in the ejection of end pin.
• Type
GLD
has an
albaloy-plated
pin for positive, electrical
signal circuit activation.
• Type
GBA
has a
red
pin for high visibility.
• The Cooper Bussmann Series 8000 fuse blocks are
recommended for visual indication.
• For visual indication use Cooper Bussmann panel-mounted
fuseholder HLD (15A maximum)
• Ferrules: Nickel-plated brass endcaps.
The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of
this document are by definition uncontrolled. This bulletin is intended to clearly present comprehensive product data and provide technical informa-
tion that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to change design or construction of
any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice,
any technical information contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
© 2012 Cooper Bussmann
St. Louis, MO 63178
www.cooperbussmann.com
1012 BU-SB12694
Page 1 of 1
Data Sheet 2012
100
200
Catalog Symbol:
GLD/GBA
GLB-albaloy-plated indicating pin
GBA-red indicating pin
Non-Time-Delay: Indicating
Amp Rating:
1
⁄
2
to 15 Amps
Agency Information:
CE, UL Listed, Std. 248-14
1
⁄
2
-5A/125Vac, 10kA AIC
Guide JDYX, File E19180
UL Recognized, 6A/125Vac, 1kA AIC
10-15A/50Vac/dc, 300 AIC
Guide JDYX2, File E19180
CSA Certified,
1
⁄
2
-5A/125Vac, 10kA AIC
Class 1422-01, File 53787
1
.1
.4
10
1
.01
2
15
3
5
