HANDLE
AAAHZ SHOWN
CONNECTOR
QT3FZ SHOWN
3 PIN
4 PIN
5 PIN
6 PIN
7 PIN
CONTACTS AS VIEWED FACING FEMALE CONECTOR
AAA
SERIES:
Q-G CONNECTOR
# OF CONTACT SOCKETS:
3, 4, 5, 6 OR 7
GENDER:
F - FEMALE
HANDLE STYLE:
BLANK - METAL HANDLE
P - PLASTIC HANDLE
F
Z
0.71
18.0
FLAT
2.97
F
75.4
SMALLER CABLES
SHORTEN ASSEMBLY
0.62
15.8
0.65
16.4
FLAT
0.78
19.7
0.84
21.2
0.49
12.3
1.99
50.6
SEE TABLE FOR
FLEX RELIEF SIZE
FINISH:
BLANK - NICKEL FINISH & GREEN INSERT
B - BLACK FINISH & BLACK INSERT
CONTACT SOCKET PLATING:
BLANK - SILVER
AU - GOLD
FLEX RELIEF STYLE:
BLANK - FLEX RELIEF I.D. 0.135 [3.4mm]
RECOMMENDED CABLE O.D. 0.100 - 0.220 [2.5mm - 5.6mm]
L - FLEX RELIEF I.D. 0.225 [5.7mm]
RECOMMENDED CABLE O.D. 0.220 - 0.285 [5.6mm - 7.2mm]
F
NOTES:
1. CONNECTORS AND HANDLES ARE SHIPPED SIDE BY SIDE OR IN BULK.
2. MATERIALS:
HANDLE METAL - ZINC ALLOY, NICKEL PLATED OR BLACK SATIN CHROME PLATED
F
HANDLE PLASTIC - THERMOPLASTIC, BLACK
CABLE CLAMP AND FLEX RELIEF - THERMOPLASTIC, BLACK
HOUSING AND LATCH - ZINC ALLOY, NICKEL OR BLACK SATIN CHROME PLATED
INSULATOR - THERMOPLASTIC, GREEN OR BLACK
GROUND TERMINAL - SPECIAL COPPER ALLOY, TIN PLATED
CONTACT SOCKETS - SPECIAL COPPER ALLOY, SILVER OR GOLD PLATED
O-RING - THERMOPLASTIC RUBBER, BLACK
3. THESE PRODUCTS ARE RoHS COMPLIANT.
F
E
D
C
B
A
REV
0.87
22.0
CUSTOMER DRAWING
STAR SYMBOL DENOTES CRITICAL DIMENSION
27081
25891
25711
24940
24552
24446
ECO NUMBER
THIS DRAWING DESCRIBES A DESIGN CONSIDERED PROPRIETARY IN NATURE, DEVELOPED AND MANUFACTURED
BY SWITCHCRAFT INC. AND IS RELEASED ON A CONFIDENTIAL BASIS FOR IDENTIFICATION PURPOSES ONLY.
01/25/13
9-9-08
10-17-07
3-11-05
10-13-03
8-12-03
DATE
BL
SRC
JGK
JL
JL
JL
BY
TJK
TJK
TJK
TJK
BRH
BRH
APVD
UNLESS OTHERWISE SPECIFIED
1. ALL DIMENSIONS IN INCHES
- TWO PLACE DECIMALS
0.01
- THREE PLACE DECIMALS
0.005
- ANGLES
1
- ALL DIA. CONCENTRIC WITHIN 0.005 T.I.R.
2. FEATURES ON THE SAME CENTERLINE
MUST BE ALIGNED WITHIN 0.002
3. REMOVE ALL BURRS
SIZE
FINISH
WIDTH
MULT
LBS/M
MATERIAL
SPEC No.
TEMPER
SPEC No.
FIRST USED ON
DATE DRAWN
BY
CHKD
SCALE
1.5:1
03-07-03
NAME
BRH
BRH
8-12-03
BRH
8-12-03
PART No.
APVD
SHEET
1
OF
1
REV
REVISIONS
DO NOT SCALE DRAWING
FEMALE XLR CONNECTOR, RoHS
AAA_FZ SERIES
F
SolidWorks CAD File
B
