16.2
Introduction
Belden IBDN
FiberExpress Systems
Optical fiber systems offer many benefits:
high bandwidth and transmission speed,
the potential for network growth, extended
reach, fault tolerance, greater data security
and support for Gigabit and multi-Gigabit
protocols and networked applications.
Beyond these traditional benefits, however,
Belden offers the FiberExpress Solution,
a complete end-to-end cabling system
supporting both centralized and fiber-to-
the-desk topologies, as well as backbone
and campus cabling configurations. Our
FiberExpress Solutions meet or exceed all
applicable TIA/EIA, ISO/IEC and IEEE
standards and offer:
■
■
■
■
■
The FiberExpress Manager
The FiberExpress Manager
makes fiber management
easier than ever before.
Designed to streamline
termination, connection
and maintenance
activities, the FiberExpress
Manager uses a scalable,
modular approach to
adapt to a wide variety of
situations. The total system
provides extra high connection density
while facilitating cable routing and patch
cord management. The FiberExpress
Manager is adaptable for almost all
situations, traditional field termination or
pre-terminated modules, which reduces
design complexity and increases
deployment efficiency.
Extended Reach
Optical Fiber Cables
Extended Reach Optical Fiber Cables
propel your network into the future
of cable technology with our
multimode FiberExpress
FX300, FX600 or FX2000
series. These series were
developed to meet the
existing needs of networks at 1 Gb/s
(Ethernet, 1000Base-SX and 1000Base-LX)
and new networks at 10 Gb/s (Ethernet,
10GBase-S and 10GBase-LX4). These
series offer better reach for laser-based
systems. For 1 Gb/s Ethernet at 850 nm
(VCSEL), the FX300 and FX600 series
provide a range of 984 ft (300 m) and
1,968 ft (600 m), respectively. For 10 Gb/s
Ethernet at 850 nm (VCSEL), the FX2000
series provide a range of 984 ft (300 m) for
10GBase-S where all of multimode series
can offer a 984 ft (300 m) range at 1300 nm
(laser) for 10GBase-LX4. All of this while
assuring total compatibility with LED systems
and FDDI fiber installation cables. Our
single-mode cable offering enhances
the options for longer distance support —
up to 40 km — for any of the Gigabit
Ethernet applications.
The FiberExpress Bar
The FiberExpress Bar is an
extremely compact, modular
and resilient linking panel.
Resembling a power bar,
it offers 6 or 12 fibers,
pre-terminated with an SC,
SC duplex, ST-compatible,
LC, MT-RJ or FC connectors
and a cord terminated with a multi-fiber
MPO connector — all of which are factory
verified. The FiberExpress Bar can adapt to
all kinds of properties or developments,
and can serve as a consolidation or linking
point. It’s available in both single-mode and
multimode media.
For the ultimate in quick, easy and
reliable optical networking we also offer
the FiberExpress Pre-connectorized
System. Based on the concept of building
blocks, the complete range of pre-terminated
FiberExpress components bring flexibility to
the design stage. The in-factory fabrication
and verification of pre-terminated connections
ensures the high-performance and high-
quality of the product. These products are
“plug and go” and their deployment requires
no specialized tools — you can deploy
12 fibers in the same amount of time it
takes to connect a power cord to a standard
electrical plug. This pre-terminated
technology will help to preserve the initial
investment by its ability to be re-deployed
while always ensuring quality results.
Reduced design complexities
Greater deployment facility
Quick installation
Increased flexibility
Cost effective pricing
Primary FiberExpress
System Components
Key components of the FiberExpress
Systems are summarized below and are
found on the catalog pages that follow.
Optimax
®
Connectors
Optimax Connectors are a
revolutionary field-installable
optical fiber connector. The
unique design of the patented
mechanical splice body of
Optimax incorporates a factory
mounted fiber stub and a
pre-polished ceramic ferrule.
This technology consistently provides a
fast, secure and reliable LC, SC or ST
Compatible optical fiber termination for
multimode or single-mode cable. All critical
steps are performed in the factory, ensuring
a superior quality connection every time.
Quality Installation and Service
All Belden IBDN systems are designed,
installed and field-tested by fully-trained
and certified system contractors and
integrators to further assure superior
systems performance. They are also
backed by a strict System Certification
and Warranty Program.
System Certification and
Warranty Program
The Belden IBDN Certification Program
is a rigorous process that ensures that
your Belden IBDN ‘Certified’ System is
composed of Belden IBDN components,
designed and installed by a factory-trained
Certified System Vendor. Belden IBDN
‘Certified’ Systems are supported by a
series of warranties that surpass conventional
product warranties. Certification adds
important end-to-end system performance
guarantees and ensures full compliance
with cabling industry standard specifications
— even after system installation (Installable
Performance
®
). A 25-year Product Warranty
and a Lifetime Application Assurance
program accompany each Belden IBDN
‘Certified’ System installation. These
warranty programs include coverage for
both parts and labor.
F o r m o r e i n f o r m a t i o n , c o n t a c t
B e l d e n Te c h n i c a l S u p p o r t :
1 - 8 0 0 - B E L D E N - 1
• w w w . b e l d e n . c o m
C O M M E R C I A L
N E T W O R K I N G
—
O P T I C A L
F I B E R
16.3
Fiber Channel Topology
FiberExpress
®
System Matrix
Page
No.
Fiber-to-the-Desk (FTTD)
and Centralized Fiber
Fiber Backbone
(In-Building)
Fiber Backbone
(Campus)
FiberExpress
Pre-Terminated Solutions*
FiberExpress Cables
Distribution & Breakout Cable Series
Multimode and Single-mode
Interconnect Cable Series
Multimode and Single-mode
Loose Tube (Campus) Cable Series
MM, SM, Composite MM/SM
Ribbon Cable Series
Multimode and Single-mode
16.20–
16.23
16.19
16.27–
16.34
16.26
●
●
●
●
●
●
●
●
●
Cross-Connect Hardware in the Telecom Room
FiberExpress Manager with
16.11
FiberExpress Manager Connector Modules
●
Multimode and Single-mode
FiberExpress Rack Mount Patch Panel
16.12
with Universal Adapter Strips
●
Multimode and Single-mode
FiberExpress Wall Mount Patch Panel
with Universal Adapter Strips
Multimode and Single-mode
FiberExpress Bar:
Multimode and Single-mode
16.13
●
●
●
●
●
●
●
●
●
●
16.8
●
●
Outlets at the Work Area
MDVO
®
Multimedia Outlets
with MDVO Multimedia Modules
MediaFlex
®
Outlets
with MediaFlex Multimedia Inserts
FiberExpress Bar
Multimode and Single-mode (as MUTOA)
Fiber Connectivity
Optimax
®
Connectors
Multimode and Single-mode
Epoxy Field Mountable Connectors
Multimode and Single-mode
Fiber Pigtails
Multimode and Single-mode
MM = Multimode • SM = Single-mode
16.16
16.15
16.8
●
●
●
●
16.4
16.5
16.8
●
●
●
●
●
●
●
●
●
*FiberExpress Pre-terminated Solutions provide simple-to-install, high-performance fiber channels through custom length, high precision factory terminated cables and matching optical connectivity components.
F o r m o r e i n f o r m a t i o n , c o n t a c t
B e l d e n Te c h n i c a l S u p p o r t :
1 - 8 0 0 - B E L D E N - 1
• w w w . b e l d e n . c o m
16
•
Networking — Fiber
Patch Cords in the Telecom Room and at the Work Area
FiberExpress Patch Cords:
16.6
●
Multimode and Single-mode
●
●
●
C O M M E R C I A L
N E T W O R K I N G
—
O P T I C A L
F I B E R
16.4
FiberExpress Connectors
Optimax
®
Field Installable Connectors and Installation Tool Kits
AX101982 Optimax LC Connector
Optimax Field Installable Connector
The Optimax Connectors
are reliable field installable optical fiber connectors that are easy to install.
They do not require epoxy, curing or polishing. Their unique design incorporates a factory polished
fiber stub in a splice mechanism which provides a fast, secure, and reliable termination on optical fiber
cables. All critical steps are performed in the factory, ensuring a superior-quality connection every time.
Only simple tools are required for installation, making Optimax a cost effective field termination.
Optimax Connectors are high-quality LC, SC and ST Compatible connectors that use a ceramic ferrule with
a physical contact (PC) polish for Multimode and super physical contact (SPC) polish for Single-mode
that ensures the best possible mating of optical fibers. Connectors are available for 62.5 or 50/125 µm
Multimode fiber and Single-mode fiber installations.
AX100029 with AX101794 Optimax SC Connector
Optimax Installation Tool Kit
The Optimax Installation Tool Kit
is packaged in a small convenient carrying case and includes an
Optimax LC, SC and ST Compatible installation and training video, installation instructions and all the
tools required to terminate 900 µm buffered optical fiber and jacketed optical fiber.
The Optimax Installation Tool Kit has all the tools and supplies required to install both the Optimax LC,
SC or ST Compatible Multimode and Single-mode connectors. Certain tool kit items can be purchased
separately to accommodate installers already possessing basic optical fiber installation tools.
Description
A0408835 with AX101793 Optimax ST
Compatible Connector
Belden Part Number
FiberExpress Connectors
Optimax Field Installable Connector
LC 62.5 µm, Multimode*
LC 50 µm, Multimode*
LC Single-mode*
SC 62.5 µm, Multimode*
SC 50 µm, Multimode*
SC Single-mode*
ST Compatible 62.5 µm, Multimode*
ST Compatible 50 µm, Multimode*
ST Compatible Single-mode*
LC Accessory Kit for jacketed fiber (2 mm boot and a crimp sleeve)
SC Accessory Kit for jacketed fiber (3 mm boot, crimp sleeves, cord adapter)
ST Accessory Kit for jacketed fiber (3 mm boot, crimp sleeves)
Optimax Installation Tool Kit
LC/SC/ST Compatible
(includes installation tools, fiber cleaver, crimping tool, instruction manual,
microscope, tweezers, alcohol wipes, marker, scissors, waste bottle,
fiber stripper, cable stripper and Training Video)
Basic (excludes fiber stripper & cleaver)
Optimax LC Tool Kit Upgrade
(includes LC installation tool, instructions manual, foam for the case)
Optimax Individual Components
Fiber Cleaver
Installation Tool LC (does not include tool-clamp)
Installation Tools ST Compatible and SC (includes tool-clamp)
Microscope
Refurbishing Materials (80 alcohol wipes and a black felt tip marker)
Installation Instruction Manual, LC
Installation Instruction Manual, SC
Installation Instruction Manual, ST Compatible
Installation & Training Video, CD (see literature ordering form on the web)
Crimp Tool complete with die
AX101981
AX101982
AX101983
AX100029
AX101077
AX101792
A0408835
AX101075
AX101791
AX101984
AX101794
AX101793
AX100947
AX100947 Optimax Tool Kit
AX100949
AX102061
A0408829
AX102062
A0403634
AX100910
AX100951
AX102063
PX101318
PX101317
NOT0651
A0403641
These products are in the process of being assessed for RoHS compliance. Please check our Web Site for the most current RoHS status.
*For 900 µm buffered fiber only. For Optimax Single-mode termination on jacketed fiber, please use the appropriate Accessory Kit.
F o r m o r e i n f o r m a t i o n , c o n t a c t
B e l d e n Te c h n i c a l S u p p o r t :
1 - 8 0 0 - B E L D E N - 1
• w w w . b e l d e n . c o m
C O M M E R C I A L
N E T W O R K I N G
—
O P T I C A L
F I B E R
16.5
FiberExpress Connectors
Epoxy Field Installable Connectors
A0390851 Optical Fiber Field Installable
Epoxy Connector, ST Compatible
Epoxy Field Installable Connector
Epoxy Field Installable Connectors
are available as Multimode and Single-mode ST Compatible
and SC field installable connectors. They require heat-cured epoxy and polishing.
Both types have a ceramic ferrule. Each connector comes complete with all the parts necessary
for termination of tight buffered fibers as well as jacketed fibers. Parts include crimp sleeves, boots,
cord adapter and dust cap.
Belden Part Number
Description
Multimode
Single-mode
FiberExpress Connectors
Epoxy Field Installable Connector
ST Compatible
SC Simplex
SC Duplex
A0390851
AX100919
AX100929
AX101412
AX101411
These products are in the process of being assessed for RoHS compliance. Please check our Web Site for the most current RoHS status.
F o r m o r e i n f o r m a t i o n , c o n t a c t
B e l d e n Te c h n i c a l S u p p o r t :
1 - 8 0 0 - B E L D E N - 1
• w w w . b e l d e n . c o m
16
•
Networking — Fiber
京公网安备 11010802033920号
EEWORLD
