53CFD-D20-H28L

Description
Potentiometer, Cermet, 1W, 150ohm, 5% +/-Tol, -150,150ppm/Cel, 4965,
CategoryPassive components    The resistor
File Size249KB,3 Pages
ManufacturerBourns
Websitehttp://www.bourns.com
Environmental Compliance
Download Datasheet Parametric View All

53CFD-D20-H28L Overview

Potentiometer, Cermet, 1W, 150ohm, 5% +/-Tol, -150,150ppm/Cel, 4965,

53CFD-D20-H28L Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid770758600
Reach Compliance Codenot_compliant
structureSquare
Maximum operating temperature125 °C
Minimum operating temperature1 °C
Package height13.25 mm
Package length12.5 mm
Package formPanel Mount
Package width16.51 mm
Rated power dissipation(P)1 W
resistance150 Ω
Resistor typePOTENTIOMETER
rotation angle270 deg
series53
size code4965
technologyCERMET
Temperature Coefficient150 ppm/°C
Tolerance5%
CO
M
PL
IA
NT
Features
RoHS compliant*
Conductive plastic or cermet
Linear and audio tapers
PC board and bushing mount
Gangable
Metal bushing and shaft
Sealed for board washing
*R
oH
S
51/53 - Sealed 1/2 ” (12.5 mm) Square Control
Electrical Characteristics
1
Conductive Plastic
Cermet
Standard Resistance Range
Linear ...................................................................................................1 K ohms to 1 megohm ......................... 150 ohms to 1 megohm
Audio ....................................................................................................1 K ohms to 1 megohm ......................... 1 K ohms to 1 megohm
Total Resistance Tolerance
Linear Tapers ........................................................................................±10 % or ±20 % .................................... ±10 % or ±5 %
Audio Tapers ........................................................................................±10 % or ±20 % .................................... ±10 %
Independent Linearity .................................................................................±5 % ...................................................... ±5 %
Absolute Minimum Resistance ...................................................................2 ohms maximum .................................. 2 ohms maximum
Effective Electrical Angle ............................................................................270 ° ±5 ° .............................................. 270 ° ±5 °
Contact Resistance Variation .....................................................................2 % ........................................................ 2 %
Dielectric Withstanding Voltage (MIL-STD-202 – Method 301)
Sea Level ..............................................................................................1,500 VAC minimum .............................. 1,500 VAC minimum
70,000 ..................................................................................................500 VAC minimum ................................. 500 VAC minimum
Insulation Resistance .................................................................................1,000 megohms minimum ..................... 1,000 megohms minimum
Power Rating At 70 °C (Derate To 0 At 125 °C)
(Voltage Limited By Power Dissipation or 350 VAC, Whichever Is Less)
Linear Tapers ........................................................................................0.5 watt.................................................. 1.0 watt
Audio Tapers ........................................................................................0.25 watt................................................ 0.5 watt
Theoretical Resolution ................................................................................Essentially infinite .................................. Essentially infinite
Environmental Characteristics
1
Operating Temperature Range ...................................................................+1 °C to +125 °C ................................... +1 °C to +125 °C
Storage Temperature Range ......................................................................-55 °C to +125 °C.................................. -55 °C to +125 °C
Temperature Coefficient Over Storage Temperature Range ......................±1,000 ppm/°C ...................................... ±150 ppm/°C
Vibration (Single Section) ...........................................................................15 G ....................................................... 15 G
Total Resistance Shift ...........................................................................±2 % maximum ..................................... ±2 % maximum
Voltage Ratio Shift ................................................................................±5 % maximum ..................................... ±5 % maximum
Shock (Single Section) ...............................................................................30 G ....................................................... 30 G
Total Resistance Shift ...........................................................................+2 % maximum ..................................... ±2 % maximum
Voltage Ratio Shift ................................................................................±5 % maximum ..................................... ±5 % maximum
Load Life.....................................................................................................1,000 hours ........................................... 1,000 hours
Total Resistance Shift ...........................................................................±10 % TRS maximum ........................... ±5 % TRS maximum
Rotational Life (No Load) ............................................................................50,000 cycles ........................................ 25,000 cycles
Total Resistance Shift ...........................................................................±10 % TRS maximum ........................... ±10 % TRS maximum
Contact Resistance Variation @ 25,000 Cycles ...................................±2 % ...................................................... ±4 %
Moisture Resistance (MIL-STD-202, Method 103, Condition B)
Total Resistance Shift ...........................................................................±10 % TRS ............................................ ±5 % TRS
IP Rating .....................................................................................................IP 64 ...................................................... IP 64
Mechanical Characteristics
Stop Strength ............................................................................................................................................................................................... 56 N-cm (5 lb.-in.)
Mechanical Angle ...................................................................................................................................................................................................... 290 ° ±5 °
Torque
Starting (Dual Sections).............................................................................................................................................. +0.35 N-cm (+0.5 oz.-in.) maximum
Running (Single Section) ............................................................................................................................................. 0.15 to 1.4 N-cm (0.2 to 2.0 oz.-in.)
Running (Dual Section) ................................................................................................................................................ 0.35 to 1.8 N-cm (0.5 to 2.5 oz.-in.)
Mounting (Torque on Bushing) .......................................................................................................................... 1.7 to 2.0 N-m (15 to 18 lb.-in.) maximum
Weight (Single Section).............................................................................................................................................................................................. 5.5 grams
(Additional Section) ............................................................................................................................................................................................. 3.0 grams
Terminals ................................................................................................................................................................................................... PC pin or solder lug
Soldering Condition .................................................................. Recommended hand soldering using Sn95/Ag5 no clean solder, 0.025 ” wire diameter.
Maximum temperature 399 °C (750 °F) for 3 seconds. No wash process to be used with no clean flux.
Part can be wave soldered at 260 °C (500 °F) for 5 seconds, no wash process with no clean flux.
Marking.................................................................................................................. Manufacturer’s trademark, part number, resistance value and date code.
Ganging (Multiple Section Potentiometer) ............................................................................................................................................ 2 sections maximum**
Hardware ...........................................One lockwasher and one mounting nut is shipped with each potentiometer, except where noted in the part number.
1
At room ambient: +25 °C nominal and 50 % relative humidity nominal, except as noted.
** Additional sections available on special request with higher minimum order quantities.
*RoHS Directive 2002/95/EC Jan 27, 2003 including Annex.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
