Customer Specification
PART NO. 45273
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
(1) Color Code
Pair
1
c) Pair
(1) Twists:
2) Cable Assembly
a) Twists:
b) Core Wrap
3) Shield:
a) Drain Wire
b) Braid
4) Jacket
a) Color(s)
b) Ripcord
Color
WHITE-BLACK
3 X 1 PAIR
24 (7/32) AWG TC
0.016" Wall, Nom. TPE
Alpha Wire Color Code B
Pair
2
Color
WHITE-BROWN
Pair
3
Color
WHITE-RED
0.024
0.056
2/Cond Cabled Together
8.0 Twists/foot (min)
3 Components Cabled
5.3 Twists/foot (min)
Nonwoven Polyester Tape, 25% Overlap, Min.
A/P/A Tape, 25% Overlap, Min.
24 (7/32) AWG TC
TC,70% Coverage, Min.
0.042" Wall, Nom.,TPE
0.314 (0.328 Max.)
Slate, Black, Yellow, Orange, Blue, Green, Red, Sand Beige, White
1 End 810 Denier Nylon
ALPHA WIRE-* P/N 45273
XTRAGUARD(R) 4 RU AWM 20237 --- LLXXXXXX CSA AWM
I/II A/B 125C 300 VOLTS FT1
P-07-KA070017-MSHA CE
(SEQ FOOTAGE)
* = Factory Code
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
c) Print
Applicable Specifications
1) UL
2) CSA International
AWM/STYLE 20237
AWM I/II A/B
FT1
3) Other
4) CE:
PENNSYLVANIA BUREAU OF MINE SAFETY
APPROVED
EU Low Voltage Directive 2006/95/EC
125°C / 300 VRMS
125°C / 300 V
RMS
Environmental
1) California Proposition 65:
The outer surface materials used in the manufacture of this part meet the requirements of
California Proposition 65.
Properties
Physical & Mechanical Properties
1) Temperature Range
2) Bend Radius
3) Pull Tension
4) Sunlight Resistance
Electrical Properties
1) Voltage Rating
2) Mutual Capacitance
3) Ground Capacitance
4) Characteristic Impedance
5) Inductance
6) Conductor DCR
7) OA Shield DCR
-50 to 125°C
10X Cable Diameter
29 Lbs, Maximum
Yes
(For Engineering purposes only)
300 VRMS
14.4 pf/ft @1 kHz, Nominal
26 pf/ft @1 kHz, Nominal
109 Ω
0.22 µH/ft, Nominal
26 Ω/1000ft @20°C, Nominal
3.2 Ω/1000ft @20°C, Nominal
Other
Packaging
a) Bulk(Made-to-order)
Flange x Traverse x Barrel (inches)
