TC1N758A.TR

Description
Zener Diode, 10V V(Z), 5%, 0.5W, Silicon, Unidirectional, DO-35, HERMETIC SEALED, GLASS PACKAGE-2
CategoryDiscrete semiconductor    diode
File Size174KB,6 Pages
ManufacturerTak Cheong
Websitehttp://www.takcheong.com/
Environmental Compliance
Download Datasheet Parametric View All

TC1N758A.TR Overview

Zener Diode, 10V V(Z), 5%, 0.5W, Silicon, Unidirectional, DO-35, HERMETIC SEALED, GLASS PACKAGE-2

TC1N758A.TR Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
Parts packaging codeDO-35
package instructionO-LALF-W2
Contacts2
Reach Compliance Codecompliant
ECCN codeEAR99
Is SamacsysN
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeZENER DIODE
Maximum dynamic impedance17 Ω
JEDEC-95 codeDO-35
JESD-30 codeO-LALF-W2
JESD-609 codee3
Number of components1
Number of terminals2
Maximum operating temperature200 °C
Package body materialGLASS
Package shapeROUND
Package formLONG FORM
Peak Reflow Temperature (Celsius)NOT SPECIFIED
polarityUNIDIRECTIONAL
Maximum power dissipation0.5 W
Certification statusNot Qualified
Nominal reference voltage10 V
surface mountNO
technologyZENER
Terminal surfaceTin (Sn)
Terminal formWIRE
Terminal locationAXIAL
Maximum time at peak reflow temperatureNOT SPECIFIED
Maximum voltage tolerance5%
Working test current20 mA
Base Number Matches1
TAK CHEONG
SE M I CO N DU CTO R
500 mW DO-35 Hermetically
Sealed Glass Zener Voltage
Regulators
Absolute Maximum Ratings
Parameter
Power Dissipation
Storage Temperature Range
Operating Junction Temperature
Lead Temperature (1/16” from case for 10 seconds)
T
A
= 25°C unless otherwise noted
Value
500
-65 to +200
+200
+230
Units
mW
°C
°C
°C
AXIAL LEAD
DO35
DEVICE MARKING DIAGRAM
L
7x
xT
L
: Logo
Device Code : TC1N7xxT
Tolerance (T) : (Blank)
:
A
:C
:D
These ratings are limiting values above which the serviceability of the diode may be impaired.
Specification Features:
Zener Voltage Range 3.3 to 12 Volts
DO-35 Package (JEDEC)
Through-Hole Device Type Mounting
Hermetically Sealed Glass
Compression Bonded Construction
All external surfaces are corrosion resistant and leads are readily solderable
Cathode indicated by polarity band
Cathode
=
10%
= 5%
= 2%
= 1%
Anode
ELECTRICAL SYMBOL
Electrical Characteristics
Device Type
T
A
= 25°C unless otherwise noted
I
R
@ V
R
Z
ZT
@ I
ZT
V
Z
@ I
ZT
V
R
I
ZT
(Volts)
(Ω)
(µA)
(mA)
(Volt)
Nominal
Max
Max
TC1N746A
3.3
20
28
10
1
TC1N747A
3.6
20
24
10
1
TC1N748A
3.9
20
23
10
1
TC1N749A
4.3
20
22
2
1
TC1N750A
4.7
20
19
2
1
TC1N751A
5.1
20
17
1
1
TC1N752A
5.6
20
11
1
1
TC1N753A
6.2
20
7
0.1
1
TC1N754A
6.8
20
5
0.1
1
TC1N755A
7.5
20
6
0.1
1
TC1N756A
8.2
20
8
0.1
1
TC1N757A
9.1
20
10
0.1
1
TC1N758A
10
20
17
0.1
1
TC1N759A
12
20
30
0.1
1
V
F
Forward Voltage = 1.5 V Maximum @
I
F
= 200 mA for all types
Notes:
1. The type numbers listed have zener voltage as shown and have a standard tolerance on the nominal zener voltage of ±5%.
Suffix (BLANK) = ±10%, Suffix C = ±2% and D = ±1%.
2. For detailed information on price, availability and delivery of nominal zener voltages between the voltages shown and tighter
voltage tolerances, contact your nearest Tak Cheong Electronics representative.
3. The zener impedance is derived from the 60-cycle ac voltage, which results when an ac current having an rms value equal to
10% of the dc zener current (I
ZT
) is superimposed to
I
ZT
.
March 2004
Page 1
TC1N746A through TC1N759A Series
®
