This document was generated on 10/10/2013
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
76291-0068
Active
EdgeLine® High Speed Connectors
EdgeLine® 12.5 Gbps CoPlanar Connector, 68 Circuits
Documents:
3D Model
Drawing (PDF)
Product Specification PS-76291-001 (PDF)
Application Specification AS-76291-001 (PDF)
Application Specification AS-76291-002 (PDF)
RoHS Certificate of Compliance (PDF)
image - Reference only
Edge Card Connectors
76291
62100-7200
62202-2802
Edgecard to PCB
EdgeLine® High Speed Connectors
EdgeLine®
883906112745
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
Series
General
Product Family
Series
Application Tooling Part Link
Application Tooling Part Link
Component Type
Overview
Product Name
UPC
Physical
(p)ower-(s)ignal Configuration
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
Entry Angle
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Plating min - Termination
Temperature Range - Operating
Termination Interface: Style
68s - 0p
68
68
Black
200
Vertical
None
Copper Alloy
Gold over Nickel
Tin
High Temperature Thermoplastic
9.320/g
2.04mm
Yes
Yes
1.57mm
Tray
No
0.75mm
0.75mm
0.762µm
0.762µm
-40°C to +85°C
Through Hole
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
76291Series
Application Tooling
|
FAQ
Tooling specifications and manuals are
found by selecting the products below.
Crimp Height Specifications are then
contained in the Application Tooling
Specification document.
Global
Description
Product #
Removal Tool for
0621007200
12.5 Gbps Coplanar
Press-In Tool for
0622022802
12.5 Gbps Coplanar
Electrical
Current - Maximum per Contact
Voltage - Maximum
1.5A
50V AC (RMS)/DC
Material Info
Reference - Drawing Numbers
Application Specification
Product Specification
S-Parameter Model
Sales Drawing
AS-76291-001, AS-76291-002
PS-76291-001
SP-76291-0002
SD-76291-001
