AA05E-024L-120SL datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> AA05E-024L-120SL

Preview

AA05E-024L-120SL: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 5W, Hybrid; CategoryPower/power management The power supply circuit; File Size98KB，2 Pages; ManufacturerVertiv; Environmental Compliance

Download Datasheet Parametric View All

AA05E-024L-120SL Overview

DC-DC Regulated Power Supply Module, 1 Output, 5W, Hybrid

AA05E-024L-120SL Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	,
Reach Compliance Code	unknow
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	36 V
Minimum input voltage	18 V
Nominal input voltage	24 V
JESD-30 code	R-MDMA-P10
JESD-609 code	e3
Maximum load regulation	1%
Number of functions	1
Output times	1
Number of terminals	10
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output voltage	12.12 V
Minimum output voltage	11.88 V
Nominal output voltage	12 V
Package body material	METAL
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	INDUSTRIAL
Terminal surface	Tin (Sn) - with Nickel (Ni) barrie
Terminal form	PIN/PEG
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	5 W
Fine-tuning/adjustable output	NO
Base Number Matches	1

Preview

Download Datasheet

View All

Astec Conventional Power

5 Watts

AA05E

Total Power:

Input Voltages:

No. of Outputs:

5 Watts

12V, 24V or 48V

Single, Dual

Electrical Specs

Input

Input Range

Input Capacitance

Input reverse voltage

protection

Input Filter

Efficiency

9-18 Vdc; 18-36 Vdc; 36-72 Vdc

2.5 µF (typ)

Fuse recommended

Pi

85% typ

Output

Voltage Tolerance

Line Regulation

Load Regulation

Noise/Ripple

Short Circuit Protection

Overvoltage Protection

Transient Response

Switching Frequency

Temperature Coefficient

Output 1 and 2 - ±1%

Output 1 and 2 - ± 0.5%

±1%

1 % mV P-P (see note 1)

Continuous Current Limit

Zener Clamp

500 µsec max (50% step load change

to within 1%Vo)

200kHz

± 0.02%/° C

Special Features

• 2:1 Input range

• 1.25 x 0.80 x 0.40 Case size

• 1500Vdc Isolation

Isolation

I/O isolation

Isolation resistance

1500Vdc

1 x 109 ohms

Environmental

Operating ambient temperature

-40°C to +85°C (full load, no derating)

Baseplate: 100°C max

Storage temperature: -40°C to +125°C

Humidity: 5% to 95%(non-condensing)

Cooling method: Convection

MTBF: >1,000,000 hours (MIL-HDBK-217F)

Conducted EMI: EN55022, Class B

UL, CSA, EN60950 Certified

62

North America (USA): 1-888-41-ASTEC

Europe (UK): 44 (1384) 842-211

Asia (HK): 852-2437-9662
