ATTENUATORS
2.9mm, Flange Mount to Pin, DC - 18 GHz, 2 Watts
SPECIFICATIONS:
Models: 2086K-XX, 2087K-XX
Electrical:
Frequency Range
Available dB Values
Attenuation Accuracy
0 - 6 dB
7 - 1 dB
2
VSWR
DC - 4 GHz
4 - 1 GHz
2.4
1
2.4 - 18 GHz
Input Power
Peak Power
Impedance
Operating Temp Range
DC - 18 GHz
0 - 1 dB
2
In 1 dB Increments
±0.3 dB
±0.5 dB
1. 5:1 Max.
1
1.25:1 Max.
1.50:1 Max.
2 Watts Avg. @ +25°C
Derated Linearly to 0.5 Watts @ +1 C
25
(5uSec Pulse, .05% Duty Cycle)
o
.055 [1.40]
Ø.0360 ±.0005
[0.914 ±0.013]
.09 [2.3]
Ø.015 [0.38]
Flat Max.
250 Watts Max.
RECOMMENDED INTERFACE
PIN FOR MATING [SMA]
50 Ohms
-65°C to +125°C
Mechanical:
2.9mm Connectors
Mates with SMA, 3.5mm and K* Series Connectors
as well as SMK IAW MIL
-STD-348)
.50 [12.70]
SQ.
Passivated Stainless Steel
Gold Plated Beryllium Copper
* K is a Trademark of Anritsu Corp.
Conductors
.340 [8.64]
TYP
4-HOLE FLANGE
4X Ø.102 [2.59]
THRU
Model Number:
2086K-XX
2.9mm Female Connector
Model Number:
2087K-XX
2.9mm Male Connector
.70±.02
[17.78±0.51]
.065 [1.65]
.76±.02
[19.30±0.51]
.065 [1.65]
Ø.28 [7.11]
Ø.28 [7.11]
Mates with
SMA Male Pin
Mates with
SMA Male Pin
Ordering Examples:
Model Number:
2086K-1
2
1 dB; 2.9mm Female
2
HOW TO ORDER:
Model Number:
20XXK-YY
Base Number
86 = 2.9mm Female
87 = 2.9mm Male
dB Value
Model Number:
2087K-6
6 dB; 2.9mm Male
Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.
Design, specifications are subject to change without notice. Contact factory for technical
specifications before purchasing or use.
2087K: REV -
Aeroflex / Inmet, Inc.
300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.
888-244-6638 or 734-426-5553 • FAX: 734-426-5557
www.aeroflex-inmet.com
