3-1462050-0: DescriptionRF RELAY, SPDT, MOMENTARY, 0.05A (COIL), 3VDC (COIL), 140mW (COIL), 2A (CONTACT), 220VDC (CONTACT), 3000MHz, SURFACE MOUNT-STRAIGHT, ROHS COMPLIANT; CategoryMechanical and electronic products relay; File Size70KB，2 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

3-1462050-0 Overview

RF RELAY, SPDT, MOMENTARY, 0.05A (COIL), 3VDC (COIL), 140mW (COIL), 2A (CONTACT), 220VDC (CONTACT), 3000MHz, SURFACE MOUNT-STRAIGHT, ROHS COMPLIANT

3-1462050-0 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1805114319
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
ECCN code	EAR99
YTEOL	0
body width	7.5 mm
body height	10.5 mm
Body length or diameter	14.9 mm
Characteristic impedance	75 Ω
Maximum coil current (DC)	0.05 A
Coil operating voltage (DC)	2.25 V
Coil power	140 mW
Coil release voltage (DC)	0.3 V
Coil resistance	64 Ω
Maximum coil voltage (DC)	3 V
Coil/Input Power Type	DC
Contact (AC) maximum rated R load	2A@250VAC
Maximum contact current (AC)	2 A
Maximum contact current (DC)	2 A
Contact (DC) maximum rated R load	2A@220VDC
Maximum contact voltage (AC)	250 V
Maximum contact voltage (DC)	220 V
Contact/Output Power Type	AC/DC
Maximum insertion loss	-0.3 dB
Maximum isolation	-50 dB
Installation features	SURFACE MOUNT-STRAIGHT
operating hours	8 ms
Maximum operating frequency	3000 MHz
Minimum operating frequency
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
method of packing	BOX; TAPE AND REEL
physical size	14.9mm x 7.5mm x 10.5mm
Relay action	MOMENTARY
Relay function	SPDT
Relay type	RF RELAY
release time	8 ms
seal	IP67/RT3
surface mount	NO
Termination type	SOLDER
voltage standing wave ratio	1.3

Preview

Download Datasheet

View All

THIS DRAWING IS A CONTROLLED DOCUMENT.

LOC

DIST

REVISIONS

P

LTR

DESCRIPTION

DATE

DWN

APVD

HJ

-

B3

B4

B5

C

Printing

New HF3 46E

ECR-12-003906, New HF3 43I(S)

REVISED PER ECO-13-009645

09JUL2010

12JAN2012

29FEB2012

18JUN2013

UKo

HD

BK

AK

Mark 1)

lot no

2007

date code

RELEASED FOR PUBLICATION

Mark 2)

Relay-Typ

HF3 01

HF3 01S

HF3 02

Mark 1)

01

01S

02

02S

03

03L

03S

03SR

04

05

05S

06

06L

06S

07

21

22

23

04APR2007

NAME

MATERIAL

Mark 2)

3

4.5

5

6

9

12

24

3

4.5

5

-

PN

1462050-1

3-1462050-0

1-1462050-6

3-1462050-1

1462050-2

2-1462050-6

2-1462050-2

2-1462050-5

1-1462050-7

1462050-3

2-1462050-3

1462050-4

2-1462050-8

2-1462050-7

1462050-5

1462050-6

1-1462050-8

1462050-7

FINISH

HF3 02S

HF3 03

HF3 03L

HF3 03S

HF3 03SR

HF3 04

HF3 05

HF3 05S

HF3 06

HF3 06L

HF3 06S

HF3 07

HF3 21

HF3 22

HF3 23

DIMENSIONS:

DWN

CHK

THIS DRAWING IS UNPUBLISHED.

C

mm

TOLERANCES UNLESS

OTHERWISE SPECIFIED:

UKo 9193

HD 9121

PRODUCT SPEC

APVD

-

TE Connectivity

DIN 7168-m

-

0 PLC

1 PLC

2 PLC

3 PLC

4 PLC

ANGLES

-

APPLICATION SPEC

HF3-Relay 75

Marking

CAGE CODE DRAWING NO

RESTRICTED TO

-

WEIGHT

-

CUSTOMER DRAWING

SIZE

A4

00779

1462050-1

SCALE

-

SHEET

5:1

1

OF

2

REV

C

1469-35 (3/11)
