Spacing 5.08 mm
AKZ950/..-5.08-GREEN-INV
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.2 mm²
4.0 mm²
0.2 mm²
4.0 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
-
-
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
11.66
16.74
21.82
26.90
31.98
37.06
42.14
47.22
52.30
57.38
62.46
67.54
72.62
77.70
82.78
87.86
92.94
98.02
103.10
108.18
113.26
118.34
123.42
Article Designation
AKZ950/2-5.08-GREEN-INV
AKZ950/3-5.08-GREEN-INV
AKZ950/4-5.08-GREEN-INV
AKZ950/5-5.08-GREEN-INV
AKZ950/6-5.08-GREEN-INV
AKZ950/7-5.08-GREEN-INV
AKZ950/8-5.08-GREEN-INV
AKZ950/9-5.08-GREEN-INV
AKZ950/10-5.08-GREEN-INV
AKZ950/11-5.08-GREEN-INV
AKZ950/12-5.08-GREEN-INV
AKZ950/13-5.08-GREEN-INV
AKZ950/14-5.08-GREEN-INV
AKZ950/15-5.08-GREEN-INV
AKZ950/16-5.08-GREEN-INV
AKZ950/17-5.08-GREEN-INV
AKZ950/18-5.08-GREEN-INV
AKZ950/19-5.08-GREEN-INV
AKZ950/20-5.08-GREEN-INV
AKZ950/21-5.08-GREEN-INV
AKZ950/22-5.08-GREEN-INV
AKZ950/23-5.08-GREEN-INV
AKZ950/24-5.08-GREEN-INV
Article Number
50950027028F
50950037028F
50950047028F
50950057028E
50950067028E
50950077028E
50950087028D
50950097028D
50950107028D
50950117028D
50950127028D
50950137028D
50950147028D
50950157028D
50950167028D
50950177028D
50950187028D
50950197028D
50950207028D
50950217028D
50950227028D
50950237028D
50950247028D
PU
200
200
200
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.25 mm²
min
Stranded with Ferrule 2.5 mm²
max
Dimensions
Stripped Length
Materials
Clamp
Screw
Contact Pin
Brass
Steel
Brass
7.0 mm
Colours
GREEN
LIGHT GREEN
21
RAL6018
similar RAL 6018
RAL6018
22
23
24
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Counterparts (Spacing 5.08 mm)
Pin Strip/Terminal Blocks
STLZ950-INV AKZ1200
AKZ4951
Accessories
Figure
AKZ950
AKZ1110
Designation
Coding star CS3-5.0/5.08-RED
Article Number
50000000025
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
50000000006
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
Ratings
*
Usegroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
Pollution Degree
B
300 V
10 A
C
-
-
D
300 V
10 A
min
0.2 mm² (4 A)
0.2 mm² (4 A)
0.50 Nm
M3
4.0 kV
3
* Approval Pending
250 V
10 A
III
max
2.5 mm² (10 A)
2.5 mm² (10 A)
AWG 28-12
AWG 28-12
0.50 Nm
M3
1.6 kV
-
-
-
-
-
AWG 28-12
AWG 28-12
0.50 Nm
M3
1.6 kV
