REVISION J
DO NOT
SCALE FROM
THIS PRINT
(No OF POS X 2.00[.079])
+ 0.55[.022]) REF
DESIGNED & DIMENSIONED
IN MILLIMETERS[INCHES]
T2SDX-05-24-X-XX.XX-S SHOWN
(No OF POS - 1) X 2.00[.079]
N (SEE TABLE 1)
(No OF POS X 2.00[.079])
+ 4.75[.187] REF
7.00 .276
REF
T2SDX-XX-XXX-XX-XX.XX-XX-XXX
TEFLON CABLE OPTION
-T: TEFLON (AVAILABLE WITH
24, 28, 30 AWG ONLY)
(LEAVE BLANK FOR STANDARD
PVC INSULATION)
No OF POSITONS
-02, -04, -05, -07, -10, -15, -20,
-25, & -30 (PER ROW)
AVAILABLE AS STANDARD
-05 THRU -50 AVAILABLE AS ASO
WIRE GAUGE (AWG)
-24, -26, -28,& -30
COLOR CODE:
(LEAVE BLANK FOR ALL BLACK WIRE)
**-C: COLOR CODED WIRE, SEE TABLE 3,
SHEET 3 FOR COLOR SEQUENCE
(AVAILABLE WITH 24 AWG ONLY
AND NOT AVAILABLE WITH TEFLON)
PLATING SPECIFICATION
-L: 10µ" LIGHT SELECTIVE GOLD IN CONTACT
AREA, BRIGHT ACID TIN ON TAIL
-S: 30µ" SELECTIVE GOLD IN CONTACT AREA,
BRIGHT ACID TIN ON TAIL
-F: 3µ" FLASH GOLD IN CONTACT AREA,
BRIGHT ACID TIN ON TAIL
3.42 .135 (TYP)
-NXX OPTION (END 2)
(ONLY AVAILABLE WITH -D, -T, & -TR)
-NUS: NOTCH UP, STRAIGHT
(PIN 1 TO N-1)
-NDS: NOTCH DOWN, STRAIGHT
(PIN 1 TO 2)
-NUX: NOTCH UP, CROSSED
(PIN 1 TO N)
-NDX: NOTCH DOWN, CROSSED
(PIN 1 TO 1)
END OPTION
-S: SINGLE ENDED (SEE FIG 1)
-D: DOUBLE ENDED (SEE FIG'S 2, 3, 4, & 5)
-T: TRANSFER ENDED (SEE FIG'S 6, 7, 8, & 9)
-TR: TRANSFER ENDED WITH RETENTION
LATCH (SEE FIG'S 10, 11, 12, & 13)
ASSEMBLED LENGTH
SPECIFY IN INCHES
SINGLE ENDED: 03.00 INCH MINIMUM
DOUBLE ENDED: 03.25 INCH MINIMUM
FIG 1
02
7.70 .303
REF
7.50 .295
REF
01
POS 01 INDICATOR
"A"
N-1 (SEE TABLE 1)
3.53 .139 REF (TYP)
(No OF POS X 2.00[.079])
+ 2.15[.085] REF
4.14 .163
REF
15.40 .606
REF
ITD2-XX-D
C
ASSEMBLED LENGTH
(SEE NOTE 8)
DWC-XX-XX-300
OR DWCT-XX-01
1.30 .051
REF (TYP)
LABEL-ET-XX
"A"
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PULLOUT FORCE: 2.5 LBS [11.1 N].
C
3. CONTACTS MUST BE INSERTED UNTIL RETENTION
FEATURES LOCK INTO PLACE.
C
4. ALL FINISHED GOODS ARE TO BE ELECTRICALLY
TESTED INCLUDING HI-POT TEST AT 1000 VOLTS DC.
AFTER FINAL ELECTRICAL TEST, LABEL EACH ASSEMBLY WITH
(1) LABEL-ET.
5. TINNED COPPER WIRE IS RoHS COMPLIANT.
6. PARTS TO BE LAYER PACKAGED.
7. END OF DISCRETE WIRE MUST FALL WITHIN THIS RANGE AFTER CRIMP.
8. FOR LENGTHS OF 12.00 INCHES AND LESS, TOLERANCE TO BE ± 3.18[.125],
FOR LENGTHS GREATER THAN 12.00 INCHES, TOLERANCE TO BE ± 2%
9. REFER TO CRIMP SPECIFICATIONS PRINT FOR CRIMP AND STRIP DIMENSIONS,
TOLERANCES, AND TOOLING.
10. NOTE DELETED.
F:\DWG\MISC\MKTG\T2SDX-XX-XXX-XX-XX.XX-XX-XXX-MKT.SLDDRW
SECTION "A"-"A"
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN MILLIMETERS.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
X.X: 0.3 [.01]
2
X.XX: 0.13 [.005]
X.XXX: 0.051 [.0020]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
MATERIAL:
SHEET SCALE: 2:1
INSULATOR: LCP, COLOR: BLACK
TERMINAL: PHOS BRONZE
CABLE INSULATION: SEE CALLOUT
WIRE: TINNED COPPER
2.00mm TERMINAL DISCRETE CABLE ASSM.
T2SDX-XX-XXX-XX-XX.XX-XX-XXX
BY:
J. BORGELT
5/18/09
SHEET
1
OF
3
REVISION J
T2SDX-05-28-X-XX.XX-D-NUS SHOWN
(SAME AS FIG 1 EXCEPT AS SHOWN)
(PIN 01 TO N-1)
C
FIG 2
ASSEMBLED LENGTH
(SEE NOTE 8)
01
NOTCHES
UP
N-1
DWL-13-XXX-D-XX.XX-XX OR
DWLT-13-XX-X-XX.XX-XX-XX FOR
(-T) TEFLON OPTION (SEE TABLE 2)
N
02
N
N-1
NOTCHES
UP
02
01
T2SDX-05-28-X-XX.XX-T-NUS SHOWN
(SAME AS FIG 1 EXCEPT AS SHOWN)
(PIN 01 TO 01)
C
ASSEMBLED LENGTH
(SEE NOTE 8)
FIG 6
(No OF POS X 2.00[.079])
+ 3.50[.138] REF
(No OF POS X 2.00[.079])
+ .43[.017] REF
N-1
NOTCHES
UP
01
11.38 .448 REF
02
N
N
N-1
NOTCHES
UP
01
02
DWL-13-XXX-D-XX.XX-XX OR
DWLT-13-XX-X-XX.XX-XX-XX
FOR (-T) TEFLON OPTION
(SEE TABLE 2)
ISD2-XX-D
5.29 .208 REF
T2SDX-05-28-X-XX.XX-D-NUX SHOWN
(SAME AS FIG 1 EXCEPT AS SHOWN)
(PIN 01 TO N)
N
N-1
NOTCHES
UP
01
01
NOTCHES
UP
N-1
N
02
02
N
N-1
NOTCHES
UP
01
FIG 3
T2SDX-05-28-X-XX.XX-T-NUX SHOWN
(SAME AS FIG 6 EXCEPT AS SHOWN)
(PIN 01 TO 02)
N-1
NOTCHES
UP
01
02
N
FIG 7
02
T2SDX-05-28-X-XX.XX-D-NDS SHOWN
(SAME AS FIG 1 EXCEPT AS SHOWN)
(PIN 01 TO 02)
N
N-1
NOTCHES
UP
02
01
N
N-1
NOTCHES
DOWN
01
N
N-1
NOTCHES
UP
02
01
FIG 4
T2SDX-05-28-X-XX.XX-T-NDS SHOWN
(SAME AS FIG 6 EXCEPT AS SHOWN)
(PIN 01 TO N)
02
01
NOTCHES
DOWN
N-1
FIG 8
02
N
T2SDX-05-28-X-XX.XX-D-NDX SHOWN
(SAME AS FIG 1 EXCEPT AS SHOWN)
(PIN 01 TO 01)
N
N-1
NOTCHES
UP
02
01
02
N
N-1
NOTCHES
DOWN
01
N
N-1
NOTCHES
UP
02
01
FIG 5
T2SDX-05-28-X-XX.XX-T-NDX SHOWN
(SAME AS FIG 6 EXCEPT AS SHOWN)
(PIN 01 TO N-1)
02
01
NOTCHES
DOWN
N-1
FIG 9
N
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DO NOT SCALE DRAWING
SHEET SCALE: 1.25:1
2.00mm TERMINAL DISCRETE CABLE ASSM.
DWG. NO.
DESCRIPTION:
T2SDX-XX-XXX-XX-XX.XX-XX-XXX
BY:
J. BORGELT
F:\DWG\MISC\MKTG\T2SDX-XX-XXX-XX-XX.XX-XX-XXX-MKT.SLDDRW
5/18/09
SHEET
2
OF
3
REVISION J
T2SDX-05-28-X-XX.XX-TR-NUS SHOWN
(SAME AS FIG 6 EXCEPT AS SHOWN)
(PIN 01 TO 01)
(No OF POS X 2.00[.079])
+ 3.50[.138] REF
2.64 .104
REF
N-1
NOTCHES
UP
01
ISD2-XX-D-M
2.19 .086
REF
FIG 10
2.03 .080
REF (TYP)
N
(APPLIES TO -S END OPTION ONLY)
(TO BE BUILT DOUBLE-ENDED INITIALLY
FOR E-TEST AND THEN SEPERATED)
IN-PROCESS 1
N
N-1
NOTCHES
UP
ASSEMBLED LENGTH
(SEE NOTE 8)
02
(ASSEMBLED LENGTH X 2)
+12.70[.500] ADDER
(SEE NOTE 8)
CUT LINE
02
01
T2SDX-05-28-X-XX.XX-TR-NUX SHOWN
(SAME AS FIG 10 EXCEPT AS SHOWN)
(PIN 01 TO 02)
N
N-1
NOTCHES
UP
02
01
N-1
NOTCHES
UP
01
02
N
FIG 11
T2SDX-05-28-X-XX.XX-TR-NDS SHOWN
(SAME AS FIG 10 EXCEPT AS SHOWN)
(PIN 01 TO N)
N
N-1
NOTCHES
UP
02
01
N
02
01
NOTCHES
DOWN
N-1
FIG 12
T2SDX-05-28-X-XX.XX-TR-NDX SHOWN
(SAME AS FIG 10 EXCEPT AS SHOWN)
(PIN 01 TO N-1)
N
N-1
NOTCHES
UP
02
01
N
02
01
NOTCHES
DOWN
N-1
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
FIG 13
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
2.00mm TERMINAL DISCRETE CABLE ASSM.
T2SDX-XX-XXX-XX-XX.XX-XX-XXX
BY:
J. BORGELT
F:\DWG\MISC\MKTG\T2SDX-XX-XXX-XX-XX.XX-XX-XXX-MKT.SLDDRW
5/18/09
SHEET
3
OF
3
