MAGNUM
®
Single & Double Row
Filtered Connectors
EM3533 Series
Euro-Mag Terminal Blocks
Pluggable Block (Mates with EM2221 Series);
3.50 Centers
SPECIFICATIONS
Rating:
8A, 300V
Center Spacing:
.138” (3.50 mm)
Wire Range:
#16-26 AWG
Housing Material:
UL rated 94V0 Thermoplastic
Contact Material:
Brass Tin Plated
Cage Clamp:
Brass, Nickel Plated
Screw Size:
M2.0 Nickel Plated Steel
Operating Temperature:
105°C (221°F) max., -40°C
(-40°F) min.
Torque Rating:
2.5 in-lb.
Construction:
Mold to Length
Agency Information:
UL/CSA; CE Certified
TABLE A
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
L (mm)
L+0.5
_
15.6+0.3
_
(0.614")
EM353308
Euro-MAG Series
Pluggable
Base & Rail Mount
Connectors
7.80
11.30
14.80
18.30
21.80
25.30
28.80
32.30
35.80
33.30
42.80
46.30
49.80
3.5+0.1
_
(0.138")
2.15+0.3
_
(0.084")
11.2+0.3
_
(0.441")
6.6+0.3
_
(0.260")
To convert to inches, divide by 25.4
Power Distribution Blocks
Part Numbering System
Series
# of Poles
EM 3 5 3 3
02
to
14
WIRE MANAGEMENT PRODUCTS
86
EM2221 Series
Euro-Mag Terminal Blocks
Closed Header; (Mates with EM3553 Series);
3.50 Centers
SPECIFICATIONS
Rating:
8A, 300V
Center Spacing:
.138” (3.50 mm)
Housing Material:
UL rated 94V0 Thermoplastic
Contact Material:
Brass Tin Plated
Operating Temperature:
105°C (221°F) max., -40°C
(-40°F) min.
Recommended PCB Hole Diameters:
.055" (1.40)
Construction:
Mold to Length
Agency Information:
UL/CSA; CE Certified
TABLE A
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
L (mm)
7.60
11.10
14.60
18.10
21.60
25.10
28.60
32.10
35.60
39.10
42.60
42.10
49.60
3.5+0.3
_
(0.138")
EM222112H
Single & Double Row
Filtered Connectors
EM222108V
HORIZONTAL
¿1.3
(¿0.051")
9.2+0.3
_
(0.362")
1.2+0.3
_
(0.047")
Euro-MAG Series
Pluggable
3.5+0.1
_
(0.138")
9.2+0.3
_
(0.362")
6.9+0.3
_
(0.272")
L+0.5
_
1.2+0.3
_
(0.047")
0.8
(.031")
2.06+0.3
_
(0.081")
3.5+0.1
_
(0.138")
Base & Rail Mount
Connectors
VERTICAL
¿1.3
(¿0.051")
3.5+0.1
_
(0.138")
6.9+0.3
_
(0.272")
2.06+0.3
_
(0.081")
To convert to inches, divide by 25.4
2.9+0.3
_
(0.114")
.80+0.1
_
(0.031")
2.9+0.3
_
(0.114")
3.4+0.3
_
(0.134")
3.5+0.1
_
(0.138")
9.2+0.3
_
(0.362")
L+0.5
_
Power Distribution Blocks
Part Numbering System
Series
# of Poles
Orientation
6.9+0.3
_
(0.272")
EM2 2 2 1
02
to
14
H
- horizontal
V
- vertical
WIRE MANAGEMENT PRODUCTS
87
MAGNUM
®
Single & Double Row
Filtered Connectors
EM2413 Series
Euro-Mag Terminal Blocks
Pluggable Block with Flanges (Mates with
EM2201 Series); 3.50 Centers
SPECIFICATIONS
Rating:
8A, 300V
Center Spacing:
.138” (3.50 mm)
Wire Range:
#16-26 AWG
Housing Material:
UL rated 94V0 Thermoplastic
Contact Material:
Brass Tin Plated
Cage Clamp:
Brass, Nickel Plated
Screw Size:
M2.0 Nickel Plated Steel
Operating Temperature:
105°C (221°F) max., -40°C
(-40°F) min.
Torque Rating:
2.5 in-lb.
Construction:
Mold to Length
Agency Information:
UL/CSA; CE Certified
TABLE A
Poles
2
3
4
5
6
7
8
9
10
11
12
L (mm)
17.40
20.90
24.40
27.90
31.40
34.90
38.40
41.90
45.40
48.90
52.40
15.6
(0.614")
L
EM241307
Euro-MAG Series
Pluggable
Base & Rail Mount
Connectors
11.2
(0.441")
6.6
(0.60")
2.15
(0.084")
3.5–.1
(0.138")
To convert to inches, divide by 25.4
Power Distribution Blocks
Part Numbering System
Series
# of Poles
EM 2 4 1 3
02
to
12
WIRE MANAGEMENT PRODUCTS
88
EM2201 Series
Euro-Mag Terminal Blocks
Header with Flanges (Mates with EM2413
Series); 3.50 Centers
SPECIFICATIONS
Rating:
8A, 300V
Center Spacing:
.138” (3.50)
Housing Material:
Green Polyamide Type 6/6, 94V0
Contact Material:
Brass Tin Plated
Operating Temperature:
105°C (221°F) max., -40°C
(-40°F) min.
Recommended PCB Hole Diameters:
.055" (1.40)
Construction:
Mold to Length
Agency Information:
UL/CSA; CE Certified
TABLE A
Poles
2
3
4
5
6
7
8
9
10
11
12
L (mm)
17.40
20.90
24.40
27.90
31.40
34.90
38.40
41.30
45.40
48.90
52.40
EM220110H
Single & Double Row
Filtered Connectors
EM220109V
HORIZONTAL
Euro-MAG Series
Pluggable
fl
fl
Base & Rail Mount
Connectors
To convert to inches, divide by 25.4
HORIZONTAL
Power Distribution Blocks
Part Numbering System
Series
# of Poles
Orientation
fl
fl
EM2 2 0 1
02
to
12
H
- horizontal
V
- vertical
WIRE MANAGEMENT PRODUCTS
89
MAGNUM
®
Single & Double Row
Filtered Connectors
EM3553 Series
Euro-Mag Terminal Blocks
(Mates with EM3593 Series);
3.81 Centers
SPECIFICATIONS
Rating:
8A, 300V
Center Spacing:
.150” (3.81 mm)
Consult factory for .300” (7.62 mm)
Wire Range:
#18-20 AWG
Housing Material:
UL rated 94V0 Thermoplastic
Contact Material:
Brass Tin Plated
Screw Size:
M2x3 Zinc Plated Steel
Operating Temperature:
105°C (221°F) max., -40°C
(-40°F) min.
Torque Rating:
3.0 in-lbs.
Construction:
Mold to Length
Agency Information:
UL/CSA; CE Certified
TABLE A
Position
02
03
04
05
06
07
08
09
10
11
12
L (mm)
7.90
11.71
15.52
19.33
23.14
26.95
30.76
34.57
38.38
42.19
46.00
L+0.5
_
15.6+0.3
_
(0.614")
EM355308
Euro-MAG Series
Pluggable
Base & Rail Mount
Connectors
3.5+0.1
_
(0.138")
2.15+0.3
_
(0.084")
11.2+0.3
_
(0.441")
6.6+0.3
_
(0.260")
To convert to inches, divide by 25.4
Power Distribution Blocks
Part Numbering System
Series
# of Positions
Mating Header:
EM3593 pg. 93
02
to
12
WIRE MANAGEMENT PRODUCTS
EM 3 5 5 3
90
