YAGEO CORPORATION
ELECTROLYTIC CAPACITORS
NM
[ For Wide Temperature ]
Applicable for Large Power Source, Converter Circuit
Screw Type Aluminum
Electrolytic Capacitors
ELECTRICAL CHARACTERISTICS
Operating Temperature Range -40 to +105°C
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
25 ~ 100V
220 ~ 330000µF
±20% (120Hz, +20°C)
I = 0.02CV or 5mA whichever is smaller.
(After 5 Minutes Application of DC Rated Voltage at 20°C)
Dissipation Factor
at 120Hz, +20°C
Endurance
After the rated voltage has been applied at 105°C for 2000 hours and then
has resumed its original condition for 16 hours.
(a) Capacitance Change: ±20% Initial Measured Value
(b) Dissipation Factor:
≤
2 Times Initial Specified Value
(c) Leakage Current:
≤
Initial Specified Value
Shelf Life
After having been stored for 1000 hours at 105°C, the rated voltage has
been applied for 30 minutes and then has resumed its original condition for
16 hours.
(a) Capacitance Change: ±20% Initial Measured Value
(b) Dissipation Factor:
≤
2 Times Initial Specified Value
(c) Leakage Current:
≤
Initial Specified Value
MULTIPLIER FOR RIPPLE CURRENT
Frequency Coefficient
FREQUENCY (Hz)
50
FACTOR
FACTOR
0.80
1.10
FREQUENCY (Hz)
300
60
0.80
1K
1.30
100 (120)
1.00
≥
10K
1.40
Less than the Value Specified in the Standard Product Tables
Endurance : 105°C 2000 Hours
High Ripple Current, Load Life of 2000 hours at 105°C
-25 to +105°C
160 ~ 450V
DESCRIPTION
DIAGRAM OF DIMENSIONS
Unit: mm
Sleeve
M5x0.8
Dø
35
51
63.5
76
89
F
12.7
22
28.6
32
32
L
±
2
20max
Dø
±
1
Safety Vent
F
±
1
160
CASE SIZE & PERMISSIBLE RIPPLE CURRENT OF STANDARD PRODUCTS
CAP. (μF)
RATED VOLTAGE W V (SURGE VOLTAGE W V)
25 (32)
SIZE
RIPPLE
CURRENT
35 (44)
DISSIPATION SIZE
FACTOR
RIPPLE
CURRENT
50 (63)
DISSIPATION SIZE
FACTOR
35 x 50
35 x 50
35 x 50
35 x 50
35 x 80
35 x 80
35 x 100
51 x 75
51 x 115
63.5 x 95
63.5 x 115
76 x 115
89 x 130
2.90
4.20
5.10
6.30
8.00
10.00
11.30
12.90
14.80
19.90
0.35
0.35
0.35
0.40
0.40
0.50
0.60
0.80
1.00
1.00
35 x 80
35 x 80
35 x 100
51 x 75
51 x 95
51 x 115
63.5 x 115
76 x 115
89 x 130
2.60
3.70
4.50
5.50
6.70
8.10
10.00
12.10
13.80
17.60
0.30
0.30
0.30
0.35
0.40
0.45
0.50
0.60
0.70
0.70
35 x 80
35 x 80
35 x 100
51 x 75
51 x 115
63.5 x 95
63.5 x 115
76 x 115
89 x 130
RIPPLE
CURRENT
2.20
3.30
3.40
4.10
4.90
5.90
7.80
9.50
11.60
14.10
18.90
D x L: mm
DISSIPATION
FACTOR
0.2
0.25
0.25
0.25
0.30
0.35
0.40
0.40
0.45
0.50
0.50
3300
4700
6800
10000
15000
22000
33000
47000
68000
100000
150000
220000
330000
Note: 1. Ripple Current: (A/rms) 105°C, 120Hz
2. Dissipation Factor: 120Hz / 20°C
161
CASE SIZE & PERMISSIBLE RIPPLE CURRENT OF STANDARD PRODUCTS
CAP. (μF)
RATED VOLTAGE W V (SURGE VOLTAGE W V)
63 (79)
SIZE
RIPPLE
CURRENT
80 (100)
DISSIPATION SIZE
FACTOR
RIPPLE
CURRENT
100 (125)
DISSIPATION SIZE
FACTOR
35 x 50
35 x 50
35 x 50
35 x 50
35 x 80
35 x 80
35 x 100
51 x 75
51 x 95
63.5 x 95
63.5 x 115
76 x 115
89 x 130
2.10
2.20
3.10
3.70
4.40
5.70
6.80
9.20
10.90
13.00
17.20
0.15
0.20
0.20
0.20
0.25
0.25
0.30
0.30
0.35
0.40
0.40
35 x 50
35 x 80
35 x 80
35 x 100
51 x 75
51 x 95
63.5 x 95
76 x 95
76 x 115
89 x 130
2.10
3.00
3.60
4.00
5.20
6.20
8.20
9.70
12.50
16.40
0.15
0.15
0.15
0.20
0.20
0.25
0.25
0.30
0.30
0.30
35 x 80
35 x 80
35 x 100
51 x 75
51 x 95
63.5 x 95
76 x 95
76 x 130
89 x 130
RIPPLE
CURRENT
1.40
1.70
2.50
3.00
3.90
5.00
6.50
7.60
9.70
11.80
15.00
D x L: mm
DISSIPATION
FACTOR
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.20
0.20
0.25
0.25
1000
1500
2200
3300
4700
6800
10000
15000
22000
33000
47000
68000
100000
Note: 1. Ripple Current: (A/rms) 105°C, 120Hz
2. Dissipation Factor: 120Hz / 20°C
162
CASE SIZE & PERMISSIBLE RIPPLE CURRENT OF STANDARD PRODUCTS
CAP. (μF)
RATED VOLTAGE W V (SURGE VOLTAGE W V)
160 (200)
SIZE
RIPPLE
CURRENT
200 (250)
DISSIPATION SIZE
FACTOR
35 x 50
35 x 50
35 x 50
35 x 80
35 x 80
35 x 100
51 x 80
51 x 95
63.5 x 95
76 x 95
76 x 130
89 x 130
1.00
1.10
1.70
2.00
2.70
3.50
4.40
5.90
7.60
10.30
13.20
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
35 x 50
35 x 50
35 x 80
35 x 100
51 x 75
51 x 95
63.5 x 95
63.5 x 115
76 x 115
89 x 130
RIPPLE
CURRENT
0.80
1.00
1.10
1.70
2.20
2.80
3.70
4.90
6.30
8.10
10.90
250 (300)
DISSIPATION SIZE
FACTOR
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
35 x 50
35 x 50
35 x 80
35 x 100
51 x 75
51 x 95
63.5 x 95
63.5 x 115
76 x 115
76 x 155
89 x 155
RIPPLE
CURRENT
0.80
1.00
1.40
1.90
2.30
3.10
4.20
5.40
6.90
9.30
12.20
D x L: mm
DISSIPATION
FACTOR
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
330
470
680
1000
1500
2200
3300
4700
6800
10000
15000
22000
Note: 1. Ripple Current: (A/rms) 105°C, 120Hz
2. Dissipation Factor: 120Hz / 20°C
163
CASE SIZE & PERMISSIBLE RIPPLE CURRENT OF STANDARD PRODUCTS
CAP. (μF)
RATED VOLTAGE W V (SURGE VOLTAGE W V)
400 (450)
SIZE
RIPPLE
CURRENT
DISSIPATION
FACTOR
450 (500)
SIZE
RIPPLE
CURRENT
1.10
1.50
2.10
2.70
4.20
D x L: mm
DISSIPATION
CURRENT
0.15
0.15
0.15
0.15
0.15
220
330
470
680
1000
1200
1500
1800
2200
2700
3300
3900
51 x 75
51 x 95
51 x 115
51 x 130
63.5 x 95
63.5 x 115
63.5 x 130
63.5 x 155
76 x 115
4700
63.5 x 195
76 x 130
5600
63.5 x 195
76 x 155
6800
8200
10000
89 x 155
89 x 155
89 x 195
2.50
3.00
3.60
4.10
4.50
5.30
6.20
7.20
6.80
8.70
7.80
9.60
9.20
10.70
11.80
14.10
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
35 x 50
35 x 100
51 x 80
51 x 95
51 x 100
51 x 130
5.70
0.15
63.5 x 115
7.30
0.15
76 x 130
10.10
0.15
76 x 155
12.60
0.15
89 x 155
15.80
0.15
Note: 1. Ripple Current: (A/rms) 105°C, 120Hz
2. Dissipation Factor: 120Hz / 20°C
