50004-03001-001 datasheet, PDF

Datasheet> All Categories > The connector> The connector> 50004-03001-001

50004-03001-001: DescriptionBoard Connector, 30 Contact(s), 2 Row(s), Male, Straight, 0.01 inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle; CategoryThe connector The connector; File Size151KB，1 Pages; ManufacturerAces Electronics Co., Ltd.; Environmental Compliance

Download Datasheet Parametric View All

50004-03001-001 Overview

Board Connector, 30 Contact(s), 2 Row(s), Male, Straight, 0.01 inch Pitch, Surface Mount Terminal, Locking, Black Insulator, Receptacle

50004-03001-001 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Aces Electronics Co., Ltd.
Reach Compliance Code	unknown
Is Samacsys	N
Board mount options	PEG
body width	0.157 inch
subject depth	0.059 inch
body length	0.358 inch
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	AU ON NI
Contact completed and terminated	Gold (Au) - with Nickel (Ni) barrier
Contact point gender	MALE
Contact material	COPPER ALLOY
contact mode	RECTANGULAR
Contact resistance	10 mΩ
Dielectric withstand voltage	300VAC V
Durability	30 Cycles
Insulation resistance	500000000 Ω
Insulator color	BLACK
insulator material	THERMOPLASTIC
JESD-609 code	e4
Manufacturer's serial number	50004
Plug contact pitch	0.01 inch
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	80 °C
Minimum operating temperature	-40 °C
PCB contact pattern	RECTANGULAR
PCB contact row spacing	4.4958 mm
Plating thickness	FLASH inch
polarization key	POLARIZED HOUSING
Rated current (signal)	0.5 A
Guideline	UL
reliability	COMMERCIAL
Terminal pitch	0.4064 mm
Termination type	SURFACE MOUNT
Total number of contacts	30
Base Number Matches	1

Preview

Download Datasheet

View All

PACKAGE

88668-XXXX-TRP*

88668-XXXX-TRP-AP

88668-XXXX-TRP

Other Housing Color

001

Black

002

Black

003

Black

004

Black

FITTING

BOSS

±0.05

CKT

一般公差

Dim A

5.90

7.10

7.90

8.30

9.10

11.10

13.10

19.10

Dim B

5.20

6.40

7.20

7.60

8.40

10.40

12.40

18.40

Dim C

2.40

3.60

4.40

4.80

5.60

7.60

9.60

15.60

Dim D

4.00

5.20

6.00

6.40

7.20

9.20

11.20

17.20

宏致電子股½有限公司

檢驗尺寸標示

品名

½圖

審核

圖號

核准

數字"2"結案(ECN-0907051)

修訂

慨述

日期

申請人

表面處理

比例

單½

張數
