PIN RECEPTACLES
for 0,38 - 0,64 diameter pins
M
ON
S
I
CHI
A
PINS
NE
D
0660
1,73 DIA.
0,51
2,18
1,24 DIA.
4,57
5,08
0677
1,6 DIA.
1,04
2,26
5,21
1,24 DIA.
0555
1,83 DIA.
0,97
2,29
1,3 DIA.
6,3
3,43
4,06
0558
1,98 DIA.
2,24 2,26
4,57
1,47 DIA.
1,09 DIA.
HOLE
0555-0-15-XX-20-XX-10-0
0660-0-15-XX-30-XX-10-0
Solder mount in 1,3 min.
mounting hole
0677-0-15-XX-30-XX-10-0
Solder mount in 1,3 min.
mounting hole
Solder mount in 1,35 min. mounting hole
Also available on 16mm wide carrier
tape: 1,800 parts per 330mm reel.
Order as: 0555-0-57-XX-20-XX-10-0
0558-0-15-XX-30-XX-10-0
Solder mount in 1,55 min.
mounting hole
0675/0679
1,83 DIA.
1,17
2,57
1,32 DIA.
L
3,05
1065/1066/7065
Basic Part
Number
Length
L
0,51
1,83 DIA.
1,42 DIA.
2,41
Basic Part
Number
3,3
L
Length
L
0675-0
0679-0
3,68
5,16
1065-0
1066-0
7065-0
4,83
4,06
4,6
1,14 DIA.
067X-0-15-XX-30-XX-10-0
Solder mount in 1,37 min.
mounting hole
X06X-0-15-XX-30-XX-10-0
Solder mount in 1,4 min.
mounting hole
0682
0,43
1,83 DIA.
2,24
1,37 DIA.
3,73
4,22
0667
0,41
1,83 DIA.
2,36
1,4 DIA.
3,61
4,09
0665
4286
1,78 DIA.
0,46
0,25
4,14
2,03
3,56
1,98 DIA.
2,24 2,26
3,81
4,57
1,27 DIA.
1,47 DIA.
1,47 DIA.
0682-0-15-XX-32-XX-10-0
0667-0-15-XX-30-XX-10-0
0665-0-15-XX-30-XX-10-0
Solder mount in 1,55 min.
mounting hole
Solder mount in 1,42 min. mounting hole Solder mount in 1,45 min. mounting hole
Also available on 16mm wide carrier
Also available on 16mm wide carrier
tape: 1,500 parts per 330mm reel.
tape: 1,700 parts per 330mm reel.
Order as: 0682-0-57-XX-32-XX-10-0
Order as: 0667-0-57-XX-30-XX-10-0
4286-0-15-XX-30-XX-10-0
Hex press-fit in 1,4
plated thru hole
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±0,13
DIAMETERS: ±0,05
ANGLES:
±.002°
ORDER CODE: XXXX - X - 15 - XX - XX - XX - 10 - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
5,08μm TIN/LEAD OVER NICKEL
80
5,08μmTIN OVER NICKEL (RoHS)
15
0,25μm GOLD OVER NICKEL (RoHS)
2002/95/EC
SPECIFY CONTACT FINISH:
02
2,54μm TIN/LEAD OVER NICKEL
84
2,54μm TIN OVER NICKEL (RoHS)
27
0,76μm GOLD OVER NICKEL (RoHS)
RoHS
SELECT CONTACT
#30 or #32
CONTACT (DATA ON PAGE 219)
