This document was generated on 11/05/2009
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0712310003
Active
4.20mm (.165") Pitch Mini-Fit® Header, Surface Mount Compatible, Single Row,
Vertical, with Snap-in Plastic Peg PCB Lock, 3 Circuits, Tin (Sn) Plating, with Positive
Lock
Documents:
3D Model
Drawing (PDF)
General
Product Family
Series
Application
Comments
Overview
Product Name
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PC Tail Length (in)
PC Tail Length (mm)
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Surface Mount Compatible (SMC)
Temperature Range - Operating
Termination Interface: Style
Product Specification PS-71690-001 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
PCB Headers
71231
Wire-to-Board
High Temperature|Square Pin|Solder Type
Mini-Fit BMI;
Mini-Fit®
No
3
3
Natural
30
No
94V-0
No
No
None
Yes
Brass
Tin
Tin
High Temperature Thermoplastic
1
Vertical
0.125 In
3.17 mm
Yes
Yes
0.093 In
2.40 mm
Tray
0.165 In
4.20 mm
150
3.75
150
3.75
Yes
Yes
Partial
No
Yes
-40°C to +105°C
Through Hole
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Halogen-Free
Status
Not Halogen-Free
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
71231 Series
Mates With
5557 Mini-Fit® Receptacle Housing, 71694
Mini-Fit® IDT Header
Electrical
CSA
Current - Maximum
UL
Voltage - Maximum
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
Material Info
Reference - Drawing Numbers
Product Specification
Sales Drawing
LR19980
9A
E29179
600V
40
SMC & Wave Capable (TH only)
3
235
PS-71690-001
SDA-71231-****
