Square Air Core Inductors
• Excellent Q factors – up to 130
• Current handling as high as 4.4 Amps!
• 15 inductance values from 6.0 to 27 nH
Designer’s Kit C424
contains 10 each of all values
Terminations
RoHS compliant tin-silver over copper
Ambient temperature
–40°C to +125°C with
Irms
current,
+125°C to +145°C with derated current
Storage temperature
Component: –55°C to +125°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+5 to +70 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C
/ 85% relative humidity)
Mean Time Between Failures (MTBF)
1 billion hours
PCB washing
Only pure water or alcohol recommended
Part number
1
0806SQ-6N0JL_
0806SQ-8N9JL_
0806SQ-12NJL_
0806SQ-16NJL_
0806SQ-19NJL_
0807SQ-6N9JL_
0807SQ-10NJL_
0807SQ-14NJL_
0807SQ-17NJL_
0807SQ-22NJL_
0908SQ-8N1JL_
0908SQ-12NJL_
0908SQ-17NJL_
0908SQ-22NJL_
0908SQ-27NJL_
Inductance
2
Q
3
±5% (nH)
typ
6.0
8.9
12.3
15.7
19.4
6.9
10.2
13.7
17.0
22.0
8.1
12.1
16.6
21.5
27.3
64
90
90
90
90
100
100
100
100
100
130
130
130
130
130
SRF
typ
4
(GHz)
5.2
4.3
4.8
4.4
4.0
4.6
4.0
4.3
4.0
3.5
5.2
4.3
3.4
3.7
3.2
DCR
max
(mOhm)
6.0
7.0
8.0
9.0
10.0
6.0
7.0
8.0
9.0
10.0
6.0
7.0
8.0
9.0
10.0
1. When ordering, please specify
termination
and
packaging
code:
Irms
5
(A)
2.9
2.9
2.9
2.9
2.9
2.7
2.7
2.7
2.7
2.7
4.4
4.4
4.4
4.4
4.4
0908SQ-27NJLC
Termination: L
= RoHS compliant tin-silver (96.5/3.5) over copper.
Special order, added cost:
T
= RoHS tin-silver-copper (95.5/4/0.5) over copper
or
S
= non-RoHS tin-lead (63/37) over copper.
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape.
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge),
use code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked.
2. Inductance measured at 400 MHz, 0.1 Vrms, 0 A using an Agilent/
HP 4287A LCR meter with an Agilent/HP 16193A test fixture.
3. Q measured at 400 MHz using an Agilent/HP 4291A impedance
analyzer.
4. SRF measured using an Agilent/HP 8753 network analyzer and a
Coilcraft SMD-D test fixture.
5. Current that causes a 20°C temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
See Qualification Standards section for environmental and test data.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 617-1
Revised 05/28/08
© Coilcraft, Inc. 2008
