Coaxial Cables
1538-8389-2045, -2046
V1.02
%DVH
Coaxial Cables
Low Loss, High Power Handling
Ultra-low Intermodulation
Stable Loss and Phase When Flexed
Triple Shielded
Durable, Rugged, Reliable
Operates in Any Environment
DIN 7-16 or Type N Connectors
Cost Effective Value
TM
1538-8389-2043, -2044
V2.00
Features
•
•
•
•
•
•
•
•
Description
series coaxial cables are premium performance
RF and microwave interconnection cables. They are optimized for
low loss, high power operation, electrical stability, low intermod-
ulation, ruggedness and flexibility in any environment.
%DVH/,1(
TM
Applications
%DVH/,1(
cables are ideal for wireless network base station
applications in equipment shelters, between shelter and tower, or
at the tower top.
TM
Specifications
Length, ft, (m) ± 0.5in (1.0cm)
Connector Interface Type
Oper. Frequency Range, GHz
VSWR at 2 GHz
Intermodulation, dBc
Shielding Effectiveness, dB/ft
Operating Temperature °F, (°C)
Weight, lb (Kg)
Connector Retension, lb, (Kg)
Impedance, Ohms ± 2 Ohms
Insertion Loss, Maximum
Power Handling, Maximum
Bend Radius, Min. in, (cm)
-3
3ft
(0.9m)
1538-8389-2043
-4
-5
4 ft
5 ft
(1.2m)
(1.5m)
DIN 7-16 MALE
DC to 3.0
-6
6 ft
(1.8m)
-3
3ft
(0.9m)
1538-8389-2044
-4
-5
4 ft
5 ft
(1.2m)
(1.5m)
Type N MALE
DC to 6.0
-6
6 ft
(1.8m)
0.6 (0.25)
1.10:1 Typ, 1.15:1 Max
-150 Typical
Better than -100
-75° (-60°) to 250° (125°)
0.7 (0.30) 0.8 (0.35) 0.9 (0.40) 0.5 (0.20) 0.6 (0.25) 0.7 (0.30) 0.8 (0.35)
50 (22.7)
50
See Performance Rating Curves On Reverse Side
See Performance Rating Curves On Reverse Side
0.88 (2.2) Static, 1.75 (4.4) Dynamic
Specifications subject to change without notice.
North America:
Tel.
Fax
(800) 366-2266
(800) 618-8883
Asia/Pacific: Tel.
Fax
+85 2 2111 8088
+85 2 2111 8087
M/A-COM, Inc.
Europe:
Tel.
Fax
+44 (1344) 869 595
+44 (1344) 300 020
