Philips Semiconductors
Product specification
Rectifier diodes
schottky barrier
GENERAL DESCRIPTION
Dual, low leakage, platinum barrier,
schottky rectifier diodes in a plastic
envelope featuring low forward
voltage drop and absence of stored
charge. These devices can withstand
reverse voltage transients and have
guaranteed reverse surge capability.
The devices are intended for use in
switched mode power supplies and
high frequency circuits in general
where low conduction and zero
switching losses are important.
PBYR2545CT series
QUICK REFERENCE DATA
SYMBOL
V
RRM
V
F
I
O(AV)
PARAMETER
PBYR25-
Repetitive peak reverse
voltage
Forward voltage
Output current (both
diodes conducting)
MAX.
35CT
35
0.62
30
MAX.
40CT
40
0.62
30
MAX.
45CT
45
0.62
30
UNIT
V
V
A
PINNING - TO220AB
PIN
1
2
3
tab
DESCRIPTION
anode 1 (a)
cathode (k)
anode 2 (a)
cathode (k)
PIN CONFIGURATION
tab
SYMBOL
a1
1
k2
1 23
a2
3
LIMITING VALUES
Limiting values in accordance with the Absolute Maximum System (IEC 134).
SYMBOL
V
RRM
V
RWM
V
R
I
O(AV)
I
O(RMS)
I
FRM
I
FSM
PARAMETER
CONDITIONS
MIN.
-
-
-
-
-
-
-
-
-35
35
35
35
MAX.
-40
40
40
40
30
43
30
135
150
-45
45
45
45
UNIT
V
V
V
A
A
A
A
A
Repetitive peak reverse voltage
Crest working reverse voltage
Continuous reverse voltage
T
mb
≤
136 ˚C
Output current (both diodes
conducting)
1
RMS forward current
Repetitive peak forward current
per diode
Non-repetitive peak forward
current, per diode
square wave;
δ
= 0.5;
T
mb
≤
130 ˚C
I
2
t
I
RRM
I
RSM
T
stg
T
j
t = 25
µs; δ
= 0.5;
T
mb
≤
130 ˚C
t = 10 ms
t = 8.3 ms
sinusoidal T
j
= 125 ˚C prior
to surge; with reapplied
V
RWM(max)
2
I t for fusing
t = 10 ms
Repetitive peak reverse current t
p
= 2
µs; δ
= 0.001
per diode.
Non-repetitive peak reverse
t
p
= 100
µs
current per diode.
Storage temperature
Operating junction temperature
-
-
-
-65
-
91
1
1
175
150
A
2
s
A
A
˚C
˚C
1
For output currents in excess of 20 A, connection should be made to the exposed metal mounting base.
January 1996
1
Rev 1.100
Philips Semiconductors
Product specification
Rectifier diodes
schottky barrier
THERMAL RESISTANCES
SYMBOL
R
th j-mb
R
th j-a
PARAMETER
Thermal resistance junction to
mounting base
Thermal resistance junction to
ambient
CONDITIONS
per diode
both diodes
in free air.
PBYR2545CT series
MIN.
-
-
-
TYP.
-
-
60
MAX.
1.5
1.0
-
UNIT
K/W
K/W
K/W
STATIC CHARACTERISTICS
T
j
= 25 ˚C unless otherwise stated
SYMBOL
V
F
I
R
C
d
PARAMETER
Forward voltage (per diode)
Reverse current (per diode)
Junction capacitance (per
diode)
CONDITIONS
I
F
= 30 A; T
j
= 125˚C
I
F
= 20 A; T
j
= 125˚C
I
F
= 30 A
V
R
= V
RWM
V
R
= V
RWM
; T
j
= 125 ˚C
f = 1MHz; V
R
= 5V; T
j
= 25 ˚C to
125 ˚C
MIN.
-
-
-
-
-
-
TYP.
0.65
0.53
0.77
100
12
800
MAX.
0.73
0.62
0.82
200
40
-
UNIT
V
V
V
µA
mA
pF
January 1996
2
Rev 1.100
Philips Semiconductors
Product specification
Rectifier diodes
schottky barrier
PBYR2545CT series
15
PF / W
Vo = 0.302
Rs = 0.012
PBYR1645
Tmb(max) / C
D = 1.0
0.5
127.5
IR / mA
100
150 C
10
PBYR1645
10
0.1
0.2
135
125 C
1
100 C
5
I
t
p
D=
t
p
T
t
142.5
0.1
75 C
Tj = 50 C
T
0
0
5
10
15
IF(AV) / A
20
150
25
0.01
0
25
VR/ V
50
Fig.1. Maximum forward dissipation P
F
= f(I
F(AV)
) per
diode; square current waveform where
I
F(AV)
=I
F(RMS)
x
√
D.
PF / W
Vo = 0.302
Rs = 0.012
Fig.4. Typical reverse leakage current per diode;
I
R
= f(V
R
); parameter T
j
12
10
PBYR1645
Tmb(max) / C
132
a = 1.57
2.2
1.9
135
138
141
144
147
150
15
Cd / pF
10000
PBYR1645
2.8
8
6
4
2
0
4
1000
0
5
IF(AV) / A
10
100
1
10
VR / V
100
Fig.2. Maximum forward dissipation P
F
= f(I
F(AV)
) per
diode; sinusoidal current waveform where a = form
factor = I
F(RMS)
/ I
F(AV)
.
IF / A
Tj = 25 C
Tj = 125 C
40
PBYR1645
Fig.5. Typical junction capacitance per diode;
C
d
= f(V
R
); f = 1 MHz; T
j
= 25˚C to 125 ˚C.
50
Zth j-mb (K/W)
10
max
typ
1
30
20
0.1
10
P
D
t
p
t
0
0
0.2
0.4
0.6
0.8
VF / V
1
1.2
1.4
0.01
10us
1ms
tp / s
0.1s
10s
Fig.3. Typical and maximum forward characteristic
I
F
= f(V
F
); parameter T
j
Fig.6. Transient thermal impedance per diode;
Z
th j-mb
= f(t
p
).
January 1996
3
Rev 1.100
Philips Semiconductors
Product specification
Rectifier diodes
schottky barrier
MECHANICAL DATA
Dimensions in mm
Net Mass: 2 g
PBYR2545CT series
4,5
max
10,3
max
1,3
3,7
2,8
5,9
min
15,8
max
3,0 max
not tinned
3,0
13,5
min
1,3
max
1 2 3
(2x)
2,54 2,54
0,9 max (3x)
0,6
2,4
Fig.7. TO220AB; pin 2 connected to mounting base.
Notes
1. Refer to mounting instructions for TO220 envelopes.
2. Epoxy meets UL94 V0 at 1/8".
January 1996
4
Rev 1.100
