REVISION BB
DO NOT
SCALE FROM
THIS PRINT
.200 5.08
REF
((No OF POS -1) x .019685 [.50000])
+.010 [.25] .005 [.13]
.03937 1.0000
C
L
SEE NOTE 4
POSITION 2
PATENT NUMBERS
5713755/5961339
BKT-1XX-XX-XX-V-XX
No OF POSITIONS
-07 THRU -69
(UNSHROUDED)
-15 THRU -69
(SHROUDED)
BODY SPEC
SEE TABLE 1
PLATING SPECIFICATIONS
-L: 10µ" SELECTIVE GOLD IN
CONTACT AREA, MATTE TIN ON TAIL
-F: 3µ" FLASH SELECTIVE GOLD IN
CONTACT AREA, MATTE TIN ON TAIL
-H: 30µ" HEAVY GOLD IN CONTACT AREA
3µ" MIN ON TAIL
-LM: 10µ" LIGHT SELECTIVE GOLD IN
CONTACT, MATTE TIN ON TAIL
-FM: 3µ" FLASH SELECTIVE GOLD IN
CONTACT, MATTE TIN TAIL
OPTIONS
-S: END SHROUDS (SEE FIG 2)
(N/A BELOW 15 POSITIONS)
-A: ALIGNMENT PINS
(SEE FIG 3 - SHEET 2)
(MINIMUM 13 POSITIONS)
-P: PICK & PLACE PAD
(SEE FIG 4, SHEET 2)
(AVAILABLE ON POSITIONS
-13 THRU -69) (SEE NOTE 3)
-TR: TAPE & REEL PACKAGING
(SEE FIG 6 - SHEET 2)
STYLE
-V: VERTICAL
C
L
BKT-141-XX
.100 2.54 REF
.019685 0.50000
(TYP)
((No OF POS +1) x .019685 [.50000])
+.010 [.25] .005 [.13]
.220±.010 5.59±0.25
(SEE NOTE 2)
POSITION 1
.0120 0.305 SQ (TYP) REF
T-1S16-03-XX-2
"B" REF
90°±3°
.004[.10]
1 MAX TOE
(ANY DIRECTION)
.100 2.54 REF
((No OF POS +1)
x .019685[.50000])+.096[2.44]
((No OF POS -1) x
.019685 [.50000])
+ .016 [.41]
.065 1.65
"A"
.010 0.25 REF
(STYLES: -01, -03, -04, -05)
+.005[.13]
-.000[.00]
.250 6.35
REF
.175 4.45
REF
2 MAX SWAY
(ANY DIRECTION)
BET-XX-L
"A"
+.005[.13]
-.000[.00]
((No OF POS+1) x
.019685[.50000] +.016[.41]
BET-XX-R
"C"
(STYLES: -02)
(DIFFERENT AS SHOWN,
OTHERWISE SAME AS ABOVE)
.142 3.61
REF
FIG 1
(FIVE POSITIONS WILL BE LOST FOR EVERY CUT MADE)
CUT
CUT IN-PROCESS VIEW
DIFFERENT AS SHOWN,
OTHERWISE SAME AS FIG 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
FIG 2
NOTES:
1. C REPRESENTS A CRITICAL DIMENSION.
2. SHEAR TAILS TO DIMENSION AS SHOWN.
3. USE LMP-01 FOR LEAD STYLES -01 & -02. USE LMP-06 FOR STYLES -03,
-04 & -05. (SEE FIGURE 4).
4. CENTER TOP VOID CORING MAY OR MAY NOT BE PRESENT.
5. MIN RETENTION: 12 oz.
DECIMALS
.XX: .01 [.3]
3
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DO NOT SCALE DRAWING
MATERIAL:
SHEET SCALE: 4:1
1MM C.L. STAGGERED SURFACE MOUNT TERMINAL STRIP ASSEMBLY
DWG. NO.
INSULATOR: LCP, UL 94 VO, COLOR BLACK.
TERMINAL: PHOS BRONZE, SPRING TEMPER
F:\DWG\MISC\MKTG\BKT-1XX-XX-XX-V-XX-MKT.SLDDRW
BKT-1XX-XX-XX-V-XX
SHEET
1
OF
2
BY:
BRATCHER 03/28/95
REVISION BB
(((No OF POS -1)/2) X
.03937[1.000]) - .11811[3.000]
.047 1.19 REF
.059 1.50
.033 0.84 REF
.045 1.14
"P"
(SEE NOTE)
"M"
(SEE NOTE)
.225 5.72 REF
.073 1.85
.140 3.56
.035 0.89 (REF)
SM-A6 (2 PLCS)
(STYLES: -01, -03, -04, -05)
(STYLE: -02)
FIG 3: -A: ALIGNMENT PINS
DIFFERENT AS SHOWN,
OTHERWISE SAME AS FIG 1
C
L
-03, -04 & -05
LMP-06
.225 5.72 REF
.080 2.03
.164 4.17
REF
LMP-01
C
L
-01 & -02
NOTE:
"M' = USED MEASURED
DIMENSION (REF)
"P" = (("M" - .225[5.72]) / 2)
.020[.51]
FIG 4: -P: -PICK & PLACE PAD
PT-1-24-02-36
PT-BKT001
PT-1-24-03-38
PT-BKT001
DIFFERENT AS SHOWN,
OTHERWISE SAME AS FIG 1
POSITION 1
PT-1-24-03-16
STYLE
-01, -02
-01, -02
-01, -02
-03
-04
-05
-05
TUBE VIEWS
PACKAGING TABLE
OPTIONS
PACKAGING TUBE
-A, -A-P, -P
PT-1-24-02-36
NONE
PT-BKT001
-S, -S-A, -S-P, -S-A-P
PT-1-24-03-16
NONE, -A, -S, -S-A, -S-P, -S-A-P,
PT-BKT001
NONE, -A, -A-P, -S, -S-A, -S-P, -S-A-P, -P
NONE, -A, -P, -A-P
-S, -S-A, -S-P, -S-A-P
PT-BKT001
PT-BKT001
PT-1-24-03-38
PLUGS
TP-24-02
TP-03
TP-03
TP-03
TP-03
TP-03
TP-03
USER DIRECTION OF FEED
FIG 5: -TR: -TAPE & REEL
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
1MM C.L. STAGGERED SURFACE MOUNT TERMINAL STRIP ASSEMBLY
DWG. NO.
BKT-1XX-XX-XX-V-XX
SHEET
2
OF
2
F:\DWG\MISC\MKTG\BKT-1XX-XX-XX-V-XX-MKT.SLDDRW
BY:
BRATCHER 03/28/95
