LM3671TL-1.875 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> LM3671TL-1.875

LM3671TL-1.875: Description1.15A SWITCHING REGULATOR, 2600kHz SWITCHING FREQ-MAX, PBGA5, 1.05 X 1.38 MM, 0.60 MM HEIGHT, 0.50 MM PITCH, MICRO SMD, 5 PIN; CategoryPower/power management The power supply circuit; File Size8MB，25 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

LM3671TL-1.875 Overview

1.15A SWITCHING REGULATOR, 2600kHz SWITCHING FREQ-MAX, PBGA5, 1.05 X 1.38 MM, 0.60 MM HEIGHT, 0.50 MM PITCH, MICRO SMD, 5 PIN

LM3671TL-1.875 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	incompatible
Parts packaging code	BGA
package instruction	1.05 X 1.38 MM, 0.60 MM HEIGHT, 0.50 MM PITCH, MICRO SMD, 5 PIN
Contacts	5
Reach Compliance Code	unknown
Is Samacsys	N
Other features	PULSE FREQUENCY MODULATION TECHNIQUE IS ALSO POSSIBLE
Analog Integrated Circuits - Other Types	SWITCHING REGULATOR
control mode	VOLTAGE-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	5.5 V
Minimum input voltage	2.7 V
Nominal input voltage	3.6 V
JESD-30 code	R-PBGA-B5
JESD-609 code	e0
length	1.387 mm
Humidity sensitivity level	1
Number of functions	1
Number of terminals	5
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Maximum output current	1.15 A
Package body material	PLASTIC/EPOXY
encapsulated code	VFBGA
Package shape	RECTANGULAR
Package form	GRID ARRAY, VERY THIN PROFILE, FINE PITCH
Peak Reflow Temperature (Celsius)	260
Maximum seat height	0.675 mm
surface mount	YES
Switch configuration	BUCK
Maximum switching frequency	2600 kHz
Temperature level	OTHER
Terminal surface	TIN LEAD
Terminal form	BALL
Terminal pitch	0.5 mm
Terminal location	BOTTOM
Maximum time at peak reflow temperature	40
width	1.057 mm
Base Number Matches	1

Preview

Download Datasheet

View All
