Metric Conductor, One-Hole, Standard Barrel with Window Lug
For Use with Class 2 Stranded Copper Conductors
Type LCMA
• Inspection window to visually assure full conductor insertion
• Tin-plated to inhibit corrosion
• UL Listed, UL Recognized, and CSA Certified to 35 KV** and
temperature rated to 90°C when crimped with Panduit tools
and dies
• Product information marked on connector for selection
and installation
• Rounded tongue convenient for use in tight spaces
• Internally beveled wire entry for fast and easy installation
D
D2.
Power
Connectors
D3.
Grounding
Connectors
E1.
Labeling
Systems
B
B
N
M
INSPECTION
WINDOW
E2.
Labels
INSPECTION
WINDOW
I
I
E3.
Pre-Printed
& Write-On
Markers
E4.
Permanent
Identification
L
L
Part
Number
LCMA6-5-C*
LCMA6-6-C*
LCMA6-8-C*
Copper
Conductor
Size
Class 2R
(mm²)
4–6
4–6
4–6
Figure Dimensions
(mm)
Current
Rating
(Amps)
30
30
30
Stud Hole
Size
(mm)
M5
M6
M8
ØI
3.8
3.8
3.8
B
10.0
10.8
13.0
M
7.8
7.8
8.0
N
6.2
6.2
8.0
L
27.5
27.5
30.5
ØD
5.5
6.6
9.0
Panduit Std.
Die Index Pkg.
No.‡
Qty.
P10
100
P10
100
P10
100
E5.
Lockout/
Tagout
& Safety
Solutions
F.
Index
‡See page D3.83 for tool and die information.
*UL Recognized only.
**Consult cable manufacturer for voltage stress relief instructions with applications greater than 2000 V.
