SPECIFICATION CONTROL DRAWING
Product
Name
B-106-3631
B-106-3632
B-106-3633
B-106-3481
B-106-3281
øA
min
4.00
[0.160]
4.60
[0.180]
6.50
[0.255]
4.00
[0.160]
4.00
[0.160]
Product Dimensions
B
C
L
nom
nom
max
6.60
0.80
30.00
[0.260]
[0.030]
[1.180]
6.60
0.80
32.00
[0.260]
[0.030]
[1.260]
6.60
0.80
33.00
[0.260]
[0.030]
[1.300]
5.05
0.80
30.00
[0.199]
[0.030]
[1.180]
2.80
0.50
22.50
[0.110]
[0.020]
[0.885]
Color (1)
Red
Blue
Yellow
Red
Red
Wire Dimensions
Size Range
øG
mm
2
(AWG)
min
0.5 - 1.0
1.4
(AWG 22-18)
[0.055]
1.5 - 2.5
2.0
(AWG 16-14)
[0.080]
3.0 - 6.0
2.8
(AWG 12-10)
[0.110]
0.5 - 1.0
1.4
(AWG 22-18)
[0.055]
0.5 - 1.0
1.4
(AWG 22-18)
[0.055]
max
4.0
[0.160]
4.6
[0.180]
6.5
[0.255]
4.0
[0.160]
4.0
[0.160]
MATERIALS
1. INSULATION SLEEVE: Heat-shrinkable, transparent color (1), radiation cross-linked modified polyamide with
thermoplastic adhesive coating inside.
2. PUSH-ON TERMINAL: Tin-plated brass.
BASE METAL: C260 Brass.
PLATING: Tin-plated per ASTM B545, Class A.
APPLICATION
1. These controlled crimp devices are designed to terminate a tin-plated or bare copper stranded wire having an insulation rated
for at least 75°C to a push-on terminal. It will provide a splash proof and strain relief connection.
UL listed wire connector 3Z11.
2. Temperature range: -55°C to +125°C.
3. For application tooling and installation, see RPIP-684-00.
For best results, prepare the wire as shown:
DuraSeal is a trademark of Tyco Electronics Corporation.
=
Tyco Electronics Corporation
300 Constitution Drive,
Menlo Park, CA. 94025, U.S.A.
Unless otherwise specified dimensions are in millimeters.
[Inches dimensions are shown in brackets]
TOLERANCES:
0.00 N/A
0.0 N/A
0 N/A
DRAWN BY:
ANGLES: N/A
ROUGHNESS IN
MICRON
CAGE CODE:
TITLE:
Raychem
DURASEAL PUSH-ON
RECEPTACLE
DOCUMENT NO.:
B-106-3XXX
REV.:
DATE:
Tyco Electronics reserves the right to amend
this drawing at any time. Users should
evaluate the suitability of the product for their
application.
REPLACES:
DCR NUMBER:
A
SCALE:
SIZE:
17-Jul-06
SHEET:
M. FORONDA
06090
D030510
D060178
© 2006 Tyco Electronics Corporation. All rights reserved.
If this document is printed it becomes uncontrolled. Check for the latest revision.
----
A
1 of 1
