569765-3 Product Details
Live Product Chat
PCB Mounted Jacks - Single Port, Multi-port and Stacked
Not re vie we d for R oHS C om pliance
No Im age Ava ilable
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
569765-3
T E I nternal N umber: 5 6 9 7 6 5 - 3
Product Highlights:
l
Jack
l
Multiple Port C onfiguration
l
1 x 2 Jack C onfiguration
l
Jack Type = RJ45
l
Number of Positions = 8
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Superseded
Search for Replacement Parts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
Modular Jacks with Integral Light Emitting Diode (LED)
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Jack
l
Jack Type
= RJ45
l
Number of Positions
= 8
l
PC B Mount Angle
= Side Entry (Right Angle)
l
PC B Mount Style
= Through Hole
l
PC B Termination Type
= Solder
l
Shielded
= Yes
l
Performance C ategory
= C at 3
l
Number of C ontacts Loaded = 8
l
Grounding Options
= Panel Ground and PC B Ground
l
Panel Stops
= Without
l
Keyed
= No
l
Profile
= Standard
l
C olor
= Black
l
Shield Material = C opper Zinc Alloy
Mechanical Attachment:
l
Jack C onfiguration
= 1 x 2
l
Panel Attachment
= Without
Termination Related Features:
l
Solder Tail C ontact Plating
= Tin-Lead over Nickel
Body Related Features:
l
Port C onfiguration = Multiple
l
Inverted Jack Face
= No
l
LED
= With
l
Shield Plating = Tin-Lead over C opper
l
Number of PC B Ground Tabs = 3
l
PC B Tail Length (mm [in])
= 3.80 [0.150]
l
Number of C ontacts Loaded, RJ45 (8 Positions) = 8
l
LED Lightpipe Material = Polycarbonate Molding C ompound
l
PC B Ground Tab Location (mm [in]) = 4.57 [0.180]
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold (50)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Number of Panel Ground Tabs = 9
l
Housing Material = High Temperature Nylon
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Identification Marking:
l
LED Position 1 C olor
= Green
l
LED Position 2 C olor
= Green
l
LED Position 3 C olor
= Yellow
l
LED Lightpipe C olor = C lear
Packaging Related Features:
l
Packaging Method = Tray
l
Packaging Quantity = 16
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
