INTERCONNECTS
1,27 Grid Headers and Sockets
Single and Double Row
2,21
(Number of Pins
X 1,27) + 0,38
Series 850, 851
852, 853
0,41 DIA.
•
Series 850 single and double row
interconnects have 1,27 pin spacing &
permit board stacking as low as 6,3.
•
Pin headers have 0,41 dia. pins ( MM
#4006-0 ). See page 175 for details.
•
MM #0467 and MM #4890 receptacles
use Hi-Rel, 3-finger BeCu #11 contacts
rated at 3 amps. ( #11 contact accepts
pin diameters from 0,38 - 0,51 ). See
pages 129 and 131 for details.
•
Insulators are high temp. thermoplastic,
suitable for all soldering operations.
2002/95/EC
3,0
2,21
0,41 DIA.
2,9
1,27
Fig. 1
3,05
(Number of Pins
X 1,27/2) + 0,38
RoHS
0,41 DIA.
3,0
Ordering Information
Single Row
2,21 Profile Pin Header
850-XX-0_ _-10-001000
Specify # of pins
Double Row
(Number of Pins
X 1,27) + 0,38
1,91 2,11
0,41 DIA.
3,0
Fig. 1
1,27
1,27
01-50
1,91 Profile Pin Header
Fig. 2
2,21
Fig. 2
852-XX-_ _ _-10-001000
Specify # of pins
002-100
For RoHS compliance
select
plating code.
3,05
1,91
4,09
0,46 DIA.
2,51
For Electrical,
Mechanical & Enviromental
Data, See pg. 4
XX=Plating Code
See Below
1,27
SPECIFY PLATING CODE XX=
10
90
40
5,08μm Sn
Fig. 3
3,05
(Number of Pins
X 1,27/2) + 0,38
Pin Plating
0,25μm Au 5,08μm Sn/Pb
Single Row
4,09 Profile Socket
851-XX-0_ _-10-001000
01-50
4,09 Profile Socket
002-100
4,7 Profile Socket
851-XX-0_ _-10-002000
01-77
For RoHS compliance
select
plating code.
Fig. 3
3,05
1,91
4,01
Specify # of pins
Double Row
0,46 DIA.
2,59
Fig. 4
1,27
853-XX-_ _ _-10-001000
Specify # of pins
Single Row
1,27
Fig. 4
1,78
(Number of Pins
X 1,27) + 1,02
Fig. 5
1,91
3,81 4,7
Specify # of pins
For Electrical,
Mechanical & Enviromental
Data, See pg. 4
0,46 DIA.
2,92
XX=Plating Code
See Below
SPECIFY PLATING CODE XX=
1,27
13
91
93
0,76µm Au
99
5,08µm Sn/Pb
41
43
5,08µm Sn
0,76µm Au
44
Sleeve (Pin)
Contact (Clip)
5,08µm Sn/Pb 5,08µm Sn/Pb
Fig. 5
w w w. m i l l - m a x . c o m
66
516-922-6000
