3-1450120-1 Product Details
Live Product Chat
MULTI-BEAM XL and MULTI-BEAM XLE - Power
Distribution Connector System
5 of 6 EU R oHS/ELV C om pliant
(
Sta te m e nt of C om pliance
)
Quick Links
C heck Pricing & Availability
Search for Tooling
View Mating Products (1)
Product Feature Selector
C ontact Us About This Product
3-1450120-1
T E I nternal N umber: 3 - 1 4 5 0 1 2 0 - 1
Product Highlights:
l
Board-to-Board Application
l
Product Series = XL
l
Header Assembly
l
Right Angle Mount Angle
l
Termination Style = Solder
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Preliminary
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
l
Mating Products (1)
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Series = XL
l
Product Type
= Header Assembly
l
Mount Angle
= Right Angle
l
Termination Style
= Solder
l
Mating Type
= Blindmate
l
PC B Retention Feature
= Yes
l
Guides = With
l
C omment = For additional configurations available, contact Tyco
Electronics.
Electrical Characteristics:
l
Voltage Rating (Signal) (VAC ) = 60
l
Voltage Rating (Power) (VDC ) = 200
Termination Related Features:
l
Termination Post Length (mm [in]) = 3.43 [0.135]
Body Related Features:
l
Total Number of AC Power
= 0
l
Total Number of Signal
= 24
l
Sequencing
= No
l
PC B Retention Method
= Boardlock(s)
l
C onnector C onfiguration Orientation = Left-to-Right
l
C enterline, DC Module (mm [in]) = 6.35 [0.250]
l
C enterline, Matrix (mm [in]) = 2.54 x 2.54 [.100 x .100]
Contact Related Features:
l
C ontact Material (Power) = High C onductivity C opper
l
C ontact Material (Signal) = C opper Alloy
l
C ontact Plating, Mating Area, Material = Gold (30)
Housing Related Features:
l
Housing Material = High Temperature Thermoplastic
Configuration Related Features:
l
Total Number of DC Power
= 4
l
C onnector C ontact C onfiguration (No. of Pos./Type) = 2/DC Power,
24/Signal, 2/DC Power
Industry Standards:
l
RoHS/ELV C ompliance
= ELV compliant, 5 of 6 C ompliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
Operation/Application:
l
Application
= Board-to-Board
Other:
l
Brand = AMP
