Chip Inductors - 0603LS Series (1608)
• Higher inductance values than other 0603 inductors
• Ferrite construction for high current handling
• Inductance values: 47 nH – 22 µH; 5% and 2% tolerance
Designer’s Kit C347
contains 10 each of all 5% values
Core material
Ceramic/Ferrite
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
4.8 – 6.2 mg
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+100°C with derated current
Storage temperature
Component: –40°C to +100°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
10000
8200 nH
3300 nH
Typical L vs Frequency
100000
Temperature Coefficient of Inductance (TCL)
+50 to +150 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Packaging
2000 per 7″ reel. Plastic tape: 8 mm wide, 0.23 mm thick,
4 mm pocket spacing, 1.1 mm pocket depth
PCB washing
Only pure water or alcohol recommended
Inductance (nH)
1000
1000 nH
330 nH
100 nH
100
10
1
10
100
1000
Irms Derating
120
110
100
Frequency (MHz)
Typical Q vs Frequency
35
30
Percent of rated
I
rms
90
80
70
60
50
40
30
20
10
25
8200 nH
1000 nH
100 nH
Q factor
15
3300 nH 330 nH
10
0
-40
-20
0
20
40
60
80
100
120
Ambient temperature (°C)
5
0
0.1
1
10
100
Frequency (MHz)
Specifications subject to change without notice.
Please check our website for latest information.
Document 264-1
25°C
20
Revised 10/06/08
© Coilcraft, Inc. 2009
Document 264-2
Chip Inductors – 0603LS Series
Part number
1
Inductance
2
(nH)
Percent
tolerance
Q min
3
SRF min
4
(MHz)
DCR max
5
(Ohms)
Irms
6
(A)
Color
code
Overall
width
0603LS-47NX_L_
0603LS-51NX_L_
0603LS-72NX_L_
0603LS-101X_L_
0603LS-121X_L_
0603LS-151X_L_
0603LS-181X_L_
0603LS-241X_L_
0603LS-271X_L_
0603LS-331X_L_
0603LS-391X_L_
0603LS-471X_L_
0603LS-561X_L_
0603LS-681X_L_
0603LS-781X_L_
0603LS-821X_L_
0603LS-102X_L_
0603LS-122X_L_
0603LS-152X_L_
0603LS-182X_L_
0603LS-222X_L_
0603LS-272X_L_
0603LS-332X_L_
0603LS-392X_L_
0603LS-472X_L_
0603LS-562X_L_
0603LS-682X_L_
0603LS-782X_L_
0603LS-822X_L_
0603LS-103X_L_
0603LS-153X_L_
0603LS-183X_L_
0603LS-223X_L_
47 @ 7.9 MHz
51 @ 7.9 MHz
72 @ 7.9 MHz
100 @ 7.9 MHz
120 @ 7.9 MHz
150 @ 7.9 MHz
180 @ 7.9 MHz
240 @ 7.9 MHz
270 @ 7.9 MHz
330 @ 7.9 MHz
390 @ 7.9 MHz
470 @ 7.9 MHz
560 @ 7.9 MHz
680 @ 7.9 MHz
780 @ 7.9 MHz
820 @ 7.9 MHz
1000 @ 7.9 MHz
1200 @ 7.9 MHz
1500 @ 7.9 MHz
1800 @ 7.9 MHz
2200 @ 7.9 MHz
2700 @ 7.9 MHz
3300 @ 7.9 MHz
3900 @ 7.9 MHz
4700 @ 7.9 MHz
5600 @ 7.9 MHz
6800 @ 7.9 MHz
7800 @ 7.9 MHz
8200 @ 7.9 MHz
10,000 @ 2.5 MHz
15,000 @ 2.5 MHz
18,000 @ 2.5 MHz
22,000 @ 2.5 MHz
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
12 @ 7.9 MHz
12 @ 7.9 MHz
12 @ 7.9 MHz
12 @ 7.9 MHz
12 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
15 @ 7.9 MHz
12 @ 2.5 MHz
20 @ 2.5 MHz
20 @ 2.5 MHz
22 @ 2.5 MHz
1500
1400
1400
1150
1100
1050
950
800
775
725
620
540
525
260
460
410
190
160
100
80
68
60
42
40
34
32
31
28
26
25
23
22
19
0.075
0.075
0.12
0.13
0.15
0.15
0.15
0.16
0.30
0.46
0.51
0.62
0.44
0.52
0.83
0.69
0.81
0.87
0.96
1.1
1.2
1.5
1.5
1.6
2.1
2.6
3.1
3.5
3.6
4.8
7.1
7.6
8.81
1.40
1.00
1.40
1.40
1.40
1.30
1.30
0.95
0.71
0.56
0.50
0.42
0.55
0.47
0.39
0.40
0.40
0.37
0.35
0.35
0.32
0.28
0.28
0.28
0.26
0.24
0.20
0.20
0.19
0.18
0.17
0.16
0.13
Black
Violet
Brown
Red
Orange
Yellow
Green
Violet
Gray
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
White
Black
Brown
Red
Orange
Yellow
Green
Black
Blue
Violet
Gray
White
Brown
Black
B1
B1
B1
B1
B1
B1
B1
B1
B1
B1
B1
B1
B1
B2
B1
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
B2
1. When ordering, specify
tolerance, termination
and
packaging
codes:
0603LS-822XJLC
Tolerance: G
= 2%
J
= 5% (Table shows stock tolerances in bold.)
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
2. Inductance measured at 0.1 Vrms, using Coilcraft SMD-A fixture in
Agilent/HP 4286A impedance analyzer with Coilcraft-provided
correlation pieces.
3. Q measured on Agilent/HP 4395A with Agilent/HP 16193 test fixture.
4. SRF measured using Agilent/HP 8753D network analyzer with Coilcraft
SMD-D test fixture.
5. DCR measured on Cambridge Technology Micro-ohmmeter.
6. Current that causes a 15°C temperature rise from 25°C ambient.
Because of their open construction, these parts will not saturate.
7. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
B
overall
C
D
H
I
J
I
F
A
G
F
E
terminal
Terminal wraparound:
approx 0.008/0,20 both ends
Recommended
Land Pattern
A
max
B
C
max
D
ref
E
F
G
H
I
J
0.071 See 0.044 0.015 0.030 0.013 0.034 0.040 0.025 0.025 inches
1,80 note 1,12 0,38 0,76 0,33 0,86 1,02 0,64 0,64 mm
Note:
B1 = 0.040 ±0.004 in / 1,016 ±0,102 mm
B2 = 0.046 ±0.004 in / 1,169 ±0,102 mm
Specifications subject to change without notice.
Please check our website for latest information.
Document 264-2
Revised 10/06/08
© Coilcraft, Inc. 2009
