Document 306-1
USB 2.0 Common Mode Choke – 0805
These Coilcraft filters are designed to eliminate virtually
all common mode noise in high-speed, differential mode
signal transmission applications such as USB 2.0,
IEEE1394 and LVDS. Most provide greater than 25 dB
common mode attenuation and greater than 100 ohms
impedance.
The low profile design and standard 0805 footprint make
it the ideal solution for designs where board space is at
a premium.
These dual-wound filters feature very low DC resistance
and are available in eight values to meet your specific
requirements.
Coilcraft
Designer’s Kit C384
contains samples of all
values shown here plus all values in our 1206USB and
0603USB series. To order, contact Coilcraft or purchase
online at
http://order.coilcraft.com.
Common mode
impedance typ (Ohms)
10 MHz 100 MHz 500 MHz
Common mode
attenuation typ (dB)
10 MHz 100 MHz 500 MHz
Part number
1
Inductance
2
DCR max
3
min (nH)
(Ohms)
Isolation
(Vrms)
Irms
4
(mA)
0805USB-421ML_
0805USB-901ML_
0805USB-172ML_
0805USB-262ML_
0805USB-372ML_
0805USB-502ML_
0805USB-672ML_
0805USB-902ML_
14
28
57
85
118
148
246
294
42
90
170
260
370
500
670
900
70
154
303
435
641
945
1231
1715
1.1
1.4
2.3
3.0
4.5
4.9
8.4
8.7
2.3
4.2
6.7
8.6
11.9
14.5
16.6
18.7
8.4
16.9
22.0
27.8
34.3
31.3
30.0
30.5
23
47
84
147
189
273
322
413
0.12
0.17
0.25
0.26
0.32
0.37
0.45
0.65
2
250
250
250
250
250
250
250
250
500
500
500
500
500
500
500
400
1
1. When ordering, please specify
packaging
code:
0805USB-902MLC
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge),
use code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape (7500 parts per full reel).
2. Inductance measured at 100 MHz using an Agilent/HP 4286A
impedance analyzer and a Coilcraft SMD-A fixture.
3. DCR is specified per winding.
4. Current per winding that causes a 20°C rise from 25°C ambient.
5. Operating temperature range
−40°C
to 85°C.
6. Electrical specifications at 25°C.
0.080 ±0.004
2,03 ±0,10
0.065 max
1,65
3
0.020 0.040
0,51 1,02
0.004
0,10
0.030
0,76
2
1
2
4
0.036
0,91
1
0.014
0,36
0.050 ±0.004
1,27 ±0,10
4
3
3
4
0.018
0,46
Recommended
Land Pattern
0.020
0,51
Terminations:
Gold over nickel over silver-palladium-glass frit
Weight:
14.9 – 15.2 mg
Tape and reel:
2000/7″ reel; 7500/13″ reel 8 mm tape width
For packaging data see Tape and Reel Specifications section.
Specifications subject to change without notice.
Please check our website for latest information.
Document 306-1
Revised 04/01/08
© Coilcraft, Inc. 2009
