PR
E
CI
PIN RECEPTACLES
for 1,02 - 1,27 diameter pins
M
ON
S
I
CHI
A
PINS
NE
D
0355
0,41
3,0 DIA.
2,44
2,54 DIA.
0354
3,02 DIA.
0,71
0,51
2,44
2,97
6,6
2,24 DIA.
7,37
3490
0,30
2,77 DIA.
2,39 DIA.
KNURL
2,06 DIA.
1,35
2,24
4,06
4,88
3808
2,67 DIA.
0,41
2,29 2,44
4,45
0,76
6,6
2,36 DIA.
KNURL
2,06 DIA.
7,37
0,99 DIA.
1,5 DIA.
2,74 DIA.
0,51
3,05
1,73 DIA.
HOLE
0355-0-15-XX-02-XX-10-0
Solder mount in 2,59 min.
mounting hole
0354-0-15-XX-02-XX-10-0
Pentagonal press-fit in 2,64 min.
plated thru hole
3490-0-15-XX-02-XX-10-0
Press-fit in 2,31 mounting hole
3808-0-15-XX-02-XX-10-0
Press-fit in 2,29 mounting hole
9184
3,96 DIA.
3,30 DIA.
9222
3,96 DIA.
3,05 DIA.
4,83
4,06
2,11
2,03 DIA.
3,18
4,39
2,11
1,4
5,08
12mm
2,54
8mm
2,29 DIA.
1,78
9184-0-15-XX-02-XX-40-0
Bottom entry, surface mount
2,34 min. plated thru hole.
Also available on carrier tape,
Order as: 9184-0-57-XX-02-XX-40-0
9222-2-15-XX-02-XX-40-0
Bottom entry, surface mount
2,08 min. plated thru hole
Also available on carrier tape,
Order as: 9222-2-57-XX-02-XX-40-0
Carrier tape format for
9184 & 9222.
1,500 pieces per 330mm reel
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±0,13
DIAMETERS: ±0,05
ANGLES:
± 2°
ORDER CODE: XXXX - X - 15 - XX - 02 - XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
5,08μm TIN/LEAD OVER NICKEL
80
5,08μmTIN OVER NICKEL (RoHS)
15
0,25μm GOLD OVER NICKEL (RoHS)
2002/95/EC
SPECIFY CONTACT FINISH:
01
5,08μm TIN/LEAD OVER NICKEL
80
5,08μm TIN OVER NICKEL (RoHS)
27
0,76μm GOLD OVER NICKEL (RoHS)
RoHS
CONTACT
#02
CONTACT (DATA ON PAGE 225)
w w w. m i l l - m a x . c o m
156
516-922-6000
