RADIAL 10MM VARIABLE
SHIELDED COILS
AIRV-10EZ
FEATURES:
•
•
•
•
•
•
Precision Molded Polypropylene
Constant Winding Pitch
Excellent Q Values
Long Term Stability
Shielded Case
High Reliability
OPTIONS:
• Bulk Packaging is Standard
• Tolerance: 10% is Standard
COMMON APPLICATIONS:
•
•
•
•
Telecommunication Equipment
RF and Oscillator Circuits
AM & FM IFT Circuits
General Electronic Applications
where Tunable Inductance
is required
STANDARD SPECIFICATIONS
Part
Number
AIRV-10EZ
L
µH
Tol
%
Q
Min
Test
Freq
MHz
Part
Number
AIRV-10EZ
L
µH
Tol
%
Q
Min
Test
Freq
MHz
AIVC-10EZ-101K
AIVC-10EZ-121K
AIVC-10EZ-151K
AIVC-10EZ-181K
AIVC-10EZ-221K
AIVC-10EZ-331K
AIVC-10EZ-391K
100
120
150
180
220
330
390
±10
±10
±10
±10
±10
±10
±10
100
100
100
100
100
100
100
796
796
796
796
796
796
796
AIVC-10EZ-561K
AIVC-10EZ-681K
AIVC-10EZ-821K
AIVC-10EZ-102K
AIVC-10EZ-122K
AIVC-10EZ-152K
AIVC-10EZ-182K
560
680
820
1000
1200
1500
1800
±10
±10
±10
±10
±10
±10
±10
100
100
100
50
50
50
50
796
796
796
252
252
252
252
RADIAL 10mm HIGH FREQUENCY VARIABLE SHIELDED COILS
AIRV-10EZH
STANDARD SPECIFICATIONS
Part
Number
AIRV-10EZH
L
µH
Tol
%
Q
Min
Test
Freq
MHz
Part
L
Tol
Q
PHYSICAL CHARACTERISTICS
Number
µH
%
Min
AIRV-10EZH
Test
Freq
MHz
AIRV-10EZH-4R7K
AIRV-10EZH-5R6K
AIRV-10EZH-6R8K
AIRV-10EZH-8R2K
AIRV-10EZH-100K
AIRV-10EZH-120K
AIRV-10EZH-150K
AIRV-10EZH-180K
4.7
5.6
6.8
8.2
10.0
12.0
15.0
18.0
±10
±10
±10
±10
±10
±10
±10
±10
100
100
100
100
60
60
60
60
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
AIRV-10EZH-220K
AIRV-10EZH-270K
AIRV-10EZH-330K
AIRV-10EZH-390K
AIRV-10EZH-470K
AIRV-10EZH-560K
AIRV-10EZH-680K
AIRV-10EZH-820K
22.0
27.0
33.0
39.0
47.0
56.0
68.0
82.0
±10
±10
±10
±10
±10
±10
±10
±10
60
60
60
60
60
60
60
60
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
TECHNICAL INFORMATION:
• Testing: (Equivalent acceptable)
Inductance: HP 4285A
Q: Megro M-1601
• AIRV-10EZ = Temperature Coefficient: TC (L) 750 ±500 ppm/°C\
• AIRV-10EZH = Temperature Coefficient: TC (L) 220 ±220 ppm/°C
Note: All specifications subject to change without notice.
PHYSICAL CHARACTERISTICS
Dimensions: mm
