IMC-0402-018.2NH+/-5%ERE4 datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> inductor> IMC-0402-018.2NH+/-5%ERE4

Preview

IMC-0402-018.2NH+/-5%ERE4: DescriptionGeneral Fixed Inductor, 1 ELEMENT, 0.0082 uH, GENERAL PURPOSE INDUCTOR, SMD; CategoryPassive components inductor; File Size157KB，2 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

IMC-0402-018.2NH+/-5%ERE4 Overview

General Fixed Inductor, 1 ELEMENT, 0.0082 uH, GENERAL PURPOSE INDUCTOR, SMD

IMC-0402-018.2NH+/-5%ERE4 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Vishay
package instruction	0402
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
uppercase and lowercase codes	0402
structure	Chip
DC Resistance	0.104 Ω
Nominal inductance(L)	0.0082 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e4
Manufacturer's serial number	IMC-0402-01
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package height	0.5 mm
Package length	1 mm
Package form	SMT
Package width	0.55 mm
method of packing	TR, 7 Inch
Minimum quality factor (at nominal inductance)	25
Maximum rated current	0.68 A
self resonant frequency	4400 MHz
series	IMC-0402-01
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Gold (Au)
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	250 MHz
Tolerance	5%
Base Number Matches	1

Preview

Download Datasheet

View All

IMC-0402-01

Vishay Dale

Surface Mount Inductor, Wirewound

FEATURES

•

Excellent solderability and resistance to soldering heat.

Suitable for reflow soldering.

High reliability and easy surface mount assembly.

Wide range of inductance values available.

Tape and reel packaging for automatic handling,

10,000/reel, EIA 481.

•

Lead (Pb)-free construction.

ELECTRICAL SPECIFICATIONS

STANDARD ELECTRICAL SPECIFICATIONS

IND.

(nH)

1.0

2.0

2.2

3.3

3.6

3.9

5.1

5.6

6.2

7.5

8.2

9.0

10.0

11.0

12.0

15.0

19.0

23.0

27.0

36.0

40.0

47.0

TEST FREQ.

L and Q

(MHz)

250

200

Q

MIN

13

16

18

20

23

25

23

26

SELF-

RESONANT

FREQ. MIN.

(MHz)

6000

5800

4400

4160

3900

3680

3600

3280

3040

2720

2480

2320

2240

2100

*RATED

DCR

DC

MAX. CURRENT

(Ohms)

(mA)

0.045

1360

0.070

1040

0.070

0.066

0.083

0.104

0.195

0.120

0.172

0.202

0.214

0.298

0.403

0.438

0.830

960

840

800

760

680

480

640

560

480

400

320

150

U

0.010 ref.

[0.25]

T

0.020

±

0.004

[0.5

±

0.1]

U

T

S

W

Inductance Range:

1nH to 47nH.

Operating Temperature:

-40°C to +125°C.

Storage Temperature:

-40°C to +125°C.

TOL.

±

0.3nH, 0.2nH

±

0.3nH, 0.2nH

±

0.3nH, 0.2nH

±

0.3nH, 0.2nH

±

0.3nH, 0.2nH

±

0.3nH, 0.2nH

±

10%, 5%

±

10%, 5%

±

10%, 5%

±

10%, 5%

±

10%, 5%

±

10%, 5%

±

5%, 2%

±

5%, 2%

±

5%, 2%

±

5%, 2%

±

5%, 2%

±

5%, 2%

±

5%, 2%

±

5%, 2%

±

5%, 2%

±

5%, 2%

TEST EQUIPMENT

• Inductance is measured in HP-4287A RF LCR

meter with HP-16193 fixture.

• Q is measured in HP-4287A RF LCR meter with

HP-16193 fixture.

• SRF is measured in HP-8753E RF network

analyzer.

• DCR is measured in HP-4338B millohmeter.

DIMENSIONS

in inches [millimeters]

L

0.039

±

0.004

[1.00

±

0.1]

W

0.022

±

0.004

[0.55

±

0.1]

S

0.008

±

0.004

[0.20

±

0.1]

* for a 15°C rise.

DESCRIPTION

IMC-0402-01

MODEL

10

n

H

INDUCTANCE

VALUE

±

5%

INDUCTANCE

TOLERANCE

ER

PACKAGE

CODE

e4

JDEC LEAD FREE

STANDARD

GLOBAL PART NUMBER

I

M

MODEL

C

0

4

SIZE

0

2

E

R

I

O

N

J

TOL.

0

1

PACKAGE

CODE

INDUCTANCE

VALUE

SERIES

www.vishay.com

52

For technical questions, contact Magnetics@vishay.com

Document Number 34163

Revision 12-Nov-04
