N313A-D-F-1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> N313A-D-F-1

N313A-D-F-1: Description500 MHz - 2000 MHz RF/MICROWAVE SGL POLE TRIPLE THROW SWITCH, 1.6 dB INSERTION LOSS; CategoryWireless rf/communication Radio frequency and microwave; File Size69KB，1 Pages; ManufacturerMITEQ Inc

Download Datasheet Parametric View All

N313A-D-F-1 Overview

500 MHz - 2000 MHz RF/MICROWAVE SGL POLE TRIPLE THROW SWITCH, 1.6 dB INSERTION LOSS

N313A-D-F-1 Parametric

Parameter Name	Attribute value
Maker	MITEQ Inc
Reach Compliance Code	unknown
Is Samacsys	N
Other features	SMA-F
structure	COAXIAL
Maximum insertion loss	1.6 dB
Maximum operating frequency	2000 MHz
Minimum operating frequency	500 MHz
RF/Microwave Device Types	SP3T
Maximum voltage standing wave ratio	1.6
Base Number Matches	1

Preview

Download Datasheet

View All

SINGLE-POLE THREE-THROW SWITCHES

FEATURES

•

Multioctave bands 0.2 to 18 GHz

Current and TTL control

Low loss

High isolation

Medium and high speed models

Drop-in models

Amplitude and phase tracking

Binary decoded logic

Frequency

Range

(GHz)

Model

Number

S303A

S303B

N303A

N303B

S313A

S313B

N313A

N313B

S336A

S336B

N336A

N336B

S347A

S347B

N347A

N347B

S338A

S338B

N338A

N338B

S328A

S328B

N328A

N328B

Insertion

Loss

(dB, Max.)

1.3

1.6

1.7

1.2

1.5

1.6

1.9

1.7

1.9

2.1

2.2

2.4

2.2

2.5

2.7

2.8

3.2

2.8

3.1

2.9

3.4

Isolation

(dB, Min.)

VSWR

(Max.)

Type

DC Power Consumption

(Reflective/ Pos. Supply Neg. Supply

Absorptive) (mA, Max.) (mA, Min.)

Outline

SP3T

Ordering

Options

1-5

Additional

Features

–

0.2–2

0.5–2

2–8

4–12

2–18

1–18

STANDARD, MULTIOCTAVE BAND MODELS

1.6:1

Ref

1.6:1

Ref

1.6:1

Abs

1.6:1

Abs

1.6:1

Ref

1.6:1

Ref

1.6:1

Abs

1.6:1

Abs

1.7:1

Ref

1.7:1

Ref

1.7:1

Abs

1.7:1

Abs

1.7:1

Ref

1.7:1

Ref

1.7:1

Abs

1.7:1

Abs

2:1

Ref

2:1

Ref

2:1

Abs

2:1

Abs

2:1

Ref

2:1

Ref

2:1

Abs

2:1

Abs

Electrical performance of multioctave models can be optimized over narrower bandwidths, or for a particular parameter. Electrical options include: Lower

insertion loss, lower VSWR, higher isolation, flat amplitude response, amplitude tracking. Mechanical/Control options include: Custom packaging, single

supply operation, fast switching time, single TTL control line. Examples of custom models previously shipped are shown below. Consult factory for options.

OPTIMIZED PERFORMANCE MODELS

4.8–7.6

5.8–14.5

2–12

2–18

126145

126144

120608

124081

2.2

2.7

1.5:1

1.6:1

1.7:1

2:1

Ref

–

SP3T

Contact factory

SP3T

Single 5V supply

5V,-12V

5V,-12V. 50ns switch speed

*For reflective models, VSWR is not specified in the “OFF” state.

For absorptive models, VSWR in the “OFF” state is defined for port J2 only.
