Features
Regulated
Converters
●
●
●
●
●
●
●
●
10W 1”x 2” Package (50.8x25.4x11.27mm)
1kVDC Isolation
Wide Input 2:1
&
4:1
Regulated Output
UL94V-0 Package Material
Continuous Short Circuit Protection
Remote ON/OFF-Control for Single Types
Efficiency to 82%
ECONOLINE
DC/DC-Converter
REC10-
S_DRWL(Z)
Series
10 Watt
1” x 2”
Single
&
Dual Output
Selection Guide
Part
Number
1” x 2”
REC10-xx05SRWL
REC10-xx12SRWL
REC10-xx15SRWL
REC10-xx24SRWL
REC10-xx05DRWL
REC10-xx12DRWL
REC10-xx15DRWL
REC10-xx05SRWLZ
REC10-xx12SRWLZ
REC10-xx15SRWLZ
REC10-xx24SRWLZ
REC10-xx05DRWLZ
REC10-xx12DRWLZ
REC10-xx15DRWLZ
2:1
xx = 9-18Vin = 12
xx = 18-36Vin = 24
xx = 36-72Vin = 48
Input
Voltage
(VDC)
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-18, 18-36, 36-72
9-36, 18-72
9-36, 18-72
9-36, 18-72
9-36, 18-72
9-36, 18-72
9-36, 18-72
9-36, 18-72
Output
Voltage
(VDC)
5
12
15
24
±5
±12
±15
5
12
15
24
±5
±12
±15
Output
Current
(mA)
2.000
830
670
416
±1.000
±416
±333
2.000
830
670
416
±1.000
±416
±333
(%)
78
81
81
82
78
81
82
79
80
81
79
78
81
81
Efficiency
* add suffix "CTRL" for optional Remote ON/OFF-Control
4:1
xx = 9-36Vin = 24
xx = 18-72Vin = 48
Specifications
(Core Operating Area)
Input Voltage Range
Output Voltage Accuracy
Line Voltage Regulation
Load Voltage Regulation (10% to 100% full load )
Output Ripple and Noise (at 20MHz BW)
Operating Frequency
Efficiency at Full Load
Isolation Voltage
Rated Working Voltage
Isolation Capacitance
Isolation Resistance
Short Circuit Protection
Operating Temperature Range (free air convection)
Storage Temperature Range
Relative Humidity
Case Material
Package Weight
MTBF (+25°C)
Detailed Information see
using MIL-HDBK 217F
(+70°C)
Application Notes chapter "MTBF"
using MIL-HDBK 217F
MSL Level 1
(tested for 1 second)
(long term isolation)
2:1 & 4:1
±2% max.
±0.2% max.
±0.2% max.
100mVp-p max.
200kHz typ.
75% max.
Output Power (%)
Derating-Graph
(Ambient Temperature)
120
100
80
60
40
20
0
Safe Operating Area
1.000VDC min.
see Application Notes
500pF max
1 GΩ min.
Continuous
-25°C to +70°C (see Graph)
-55°C to +100°C
95% RH
Metal Case
31.2 g
700 x 10
3
hours
560 x 10
3
hours
-25
0
25
50
Operating Temperature (°C)
75 100
70 90
}
112
April-2005
www.recom-international.com
ECONOLINE
DC/DC-Converter
Typical Characteristics
REC10-S_DRWL(Z)
Series
REC10 - types
Efficiency / Load
100
80
60
40
Efficiency %
20
0
40%
20%
60%
Total Output current (%)
80%
100%
Package Style and Pinning (mm) 1” x 2” , Wide Input 2:1 & 4:1
1“ x 2“ PIN Package
50.80
11.27
8.30
20.32
15.24
20.40
20.40
25.40
3rd angle
projection
25.40
Recommended Footprint Details
Pin Connections
3
1
2
5
10.20
2.54
7.66
2
1
4
3
2.54
Top View
5.08
Bottom View 4
Pin #
1
2
3
4
5
Single
+ Vin
– Vin
+ Vout
No Pin
– Vout
Dual
+ Vin
– Vin
+ Vout
Com
– Vout
5
XX.X ± 0.5 mm
XX.XX ± 0.25 mm
1.2ø+0.2/0.1
REC10-Series also available with Remote ON/OFF - Control
For detailed information please contact your RECOM representative.
Recommended Footprint Details
Pin Connections
3
1
2
6
10.20
Bottom View 4
6
2.54
2
1
5
4
3
5.08
5.08
7.66
5
Pin #
1
2
3
4
5
6
Single
+ Vin
– Vin
+ Vout
No Pin
– Vout
Remote ON/OFF
2.54
Top View
1.2ø+0.2/0.1
XX.X ± 0.5 mm
XX.XX ± 0.25 mm
www.recom-international.com
April-2005
