1981200000 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Circuit protection> Circuit protection> 1981200000

1981200000: DescriptionElectric Fuse, Time Delay Blow, 2A, 100A (IR), 5x20mm,; CategoryCircuit protection Circuit protection; File Size54KB，2 Pages; ManufacturerLittelfuse; Websitehttp://www.littelfuse.com

Download Datasheet Parametric View All

1981200000 Overview

Electric Fuse, Time Delay Blow, 2A, 100A (IR), 5x20mm,

1981200000 Parametric

Parameter Name	Attribute value
Maker	Littelfuse
Reach Compliance Code	unknown
Is Samacsys	N
Fusing characteristics	D
body height	20 mm
Body length or diameter	5.2 mm
Circuit protection type	Electric Fuse
Fuse size	5x20mm
Maximum operating temperature	70 °C
Minimum operating temperature	-25 °C
physical size	5.2mm x 20mm
Rated breaking capacity	100 A
Rated current	2 A
Rated voltage	250 V
Guideline	CSA, UL
Base Number Matches	1

Preview

Download Datasheet

View All

INIATURE

USES

WICKMANN

5x20mm / No. 198

250V,

UL 248-14, 250V, D

Time-Current Characteristic

Time Delay (D)

Specifications

Packaging

000:

002:

040:

043:

Bulk (1000 pcs.)

Bulk (10 pcs.)

Axial Leads - Bulk (1000 pcs.)

Axial Leads - Tape/Reel (1250 pcs.)

Glass

Nickel-plated brass

Silver-plated caps

Tin-plated copper wires

Standard

UL 248-14

CSA C22.2 No. 248.14

Approvals

UL Listed: File No. E 67006

CSA Certified: File No. 51378-37

Materials

Tube:

End Caps:

Axial Leads:

Features

Dimensions (mm)

Visual fault indication

Direct solderable or plug-in versions

Internationally approved

Worldwide availability

Temperature

Operating Temperature

-25ºC to +70ºC (consider de-rating)

Climatic Category

-25ºC/+70ºC/21 days (EN 60068-1..3)

WebLinks

∅

5,2

0,65

+0.04

-0.01

∅

5,4

21 +0,5

103,5 max.

Stock Conditions

+10ºC to +60ºC

relative humidity

≤

75% yearly average,

without dew, maximum value for 30 days-95%

Data Sheet

www.wickmann.com/products/198.pdf

Approval Certificates

www.wickmann.com/approvals

Vibration Resistance

24 cycles at 15 min. each (EN 60068-6)

10 - 60Hz at 0.75mm amplitude

60 - 2000Hz at 10g acceleration

Time-Current Curve

www.wickmann.com/itcurves

Packaging

www.wickmann.com/pack

Solderability

260ºC,

≤

3 sec. (Wave)

350ºC,

≤

1 sec. (Hand)

FaxBack Document # 201

Soldering Heat Resistance

260ºC, 10 sec. (IEC 60068-2-20)

Marking

, Current Rating, 250VAC, D, 198, Approvals

Limits for Pre-arcing Time

Rated Current

80mA ... 3.00A

3.50A

Unit Weight

5s ... 120s

12s ... 120s

1.1g (approx.)

2.0g (with leads)

1.35 x I

Rated

2.0 x I

Rated

< 1h

75%

Permissible continuous operating current is

≤

75% at ambient temperature of 23ºC (73.4ºF).

Rated

Amp

Voltage

Breaking

Voltage Drop Power DissipationMelting Integral

Current

Code

Rating

Capacity

1.0 x I

Rated

1.0 x I

Rated

10 x I

Rated

max. (mV)

max. (W)

min. (A

80mA

100mA

125mA

150mA

200mA

250mA

300mA

400mA

500mA

600mA

700mA

800mA

1.00A

1.25A

1.60A

2.00A

2.50A

3.00A

3.50A

0080

0100

0125

0150

0200

0250

0300

0400

0500

0600

0700

0800

1100

1125

1160

1200

1250

1300

1350

250V

2800

2400

2100

1800

1300

1100

1050

850

650

550

500

400

350

300

270

235

215

200

0.4

0.5

0.6

0.7

0.8

0.9

1.0

1.1

1.2

1.3

0.019

0.038

0.066

0.10

0.18

0.29

0.5

1.0

1.6

2.7

3.7

5.6

9.5

110

180

Approvals

CSA

35A / 250VAC

10kA / 125VAC

50-60Hz

cos

= 0.7-0.8

100A / 250VAC

10kA / 125VAC

50-60Hz

cos

= 0.7-0.8

•

Order

Information

000801

Qty.

Order-

Number

Series

198

Amp Code

Packaging

WebSite:

www.wickmann.com

FaxBack: +1 (404) 699-6176

• Europe

Tel: +49 (2302) 662-107

• Americas

Tel: +1 (404) 699-7820

• Asia

Tel: +852 26 14-1108

E-mail: sales@wickmann.com

E-mail: service@wickmannusa.com E-mail: sales@wickmann.com.hk
