REVISION FD
DO NOT
SCALE FROM
THIS PRINT
NOTES:
TFM-1XX-XX-XXX-D-XXX
OPTION
-A: ALIGNMENT PIN (USE TFM-XX-D-XX-A,
SEE TABLE 1) (SEE FIG 8, SHT 3)
(NOT AVAILABLE FOR -RA OR -REX)
-LC: LOCKING CLIP (USE LC-05-TM)
(NOT AVAILABLE FOR -RA OR -REX)
(SEE FIG 10, SHT 3 & NOTES 3 & 11)
-P: PICK AND PLACE PAD (USE PPP-04)
(AVAILABLE IN ALL POSITIONS -05 THRU
-50 EXCEPT -05 WITH -WT)
(NOT AVAILABLE FOR -RA OR -REX,
SEE FIG 7, SHT 3)
-RA: RIGHT ANGLE
(AVAILABLE ONLY IN LEAD STYLE: -01
SEE FIG 5, SHT 2)
-TR: TAPE AND REEL (SEE FIG 4, SHT 7)
(NOT AVAILABLE WITH -DS OPTION
OR THROUGH HOLE LEAD STYLE)
-SA: STAKED ALIGNMENT PIN (SEE FIG 9, SHT 3)
(NOT AVAILABLE FOR -RA OR -RE)
-K: POLYIMIDE FILM (SEE FIG 3, SHT 2)
(USE K-DOT-.217-.313-.005)
(NOT AVAILABLE FOR -RA OR -REX)
(ALL LEAD STYLES EXCEPT -21 AVAILABLE)
-WT: WELD TABS (USE WT-25-XX-T)
(AVAILABLE ON -01, -02 & -03 LEAD
STYLES ONLY) (SEE FIG 6, SHT 2)
(MATES WITH SFSS/SFSD -SR & -DR ONLY)
(NOT AVAILABLE WITH -A, -LC,
-RA, OR -SA OPTIONS)
-RE1: RIGHT ANGLE ELEVATED .062 PCB
(USE TFM-XX-D-01-RE, NOT AVAILABLE
WITHOUT -WT, AVAILABLE IN LEAD
STYLE -01 ONLY, -03 THRU -50 POS)
(MATES WITH SFSS/SFSD -SR & -DR ONLY)
(SEE FIG 11, SHT 4)
-RE2: RIGHT ANGLE ELEVATED .093 PCB
(USE TFM-XX-D-01-RE, NOT AVAILABLE
WITHOUT -WT, AVAILABLE IN LEAD
STYLE -01 ONLY, -03 THRU -50 POS)
(MATES WITH SFSS/SFSD -SR & -DR ONLY)
(SEE FIG 11, SHEET 4)
-SN: SOLDER NAIL FOR .062 BOARD
(TFM-XX-D-01-SN AND WT-27-01-T)
(SEE FIG12, SHT 3)
(ONLY AVAILABLE WITH -02 LEAD STYLE)
(NOT AVAILABLE WITH OPTIONS -A, -LC,
-RA, -SA, -WT, -RE1 OR -RE2)
-SN2: SOLDER NAIL FOR .093 BOARD
(TFM-XX-D-01-SN AND WT-27-02-T)
(SEE FIG12, SHT 3)
(ONLY AVAILABLE WITH -02 LEAD STYLE)
(NOT AVAILABLE WITH OPTIONS -A, -LC,
-RA, -SA, -WT, -RE1 OR -RE2)
-DS: DUAL SCREW DOWN FOR .062 BOARD
(SEE FIG 18, SHT 5)
(ONLY AVAILABLE WITH -01 & -02 LEAD
STYLE)
(NOT AVAILABLE WITH OPTIONS -A, -LC, -P,
-RA, -TR, -SA, -K, -WT, -RE1, -RE2, -SN, -SN2)
(-01 LEAD STYLE USES TFM-XX-D-01-DSL
& T1-M2-4-VSFM-T, 02 LEAD STYLE USES
TFM-XX-D-01-DSA & T1-M2-4-VSFM-T)
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE FOR CONTACTS, WELD TABS,
No OF POSITIONS
AND THREADED INSERTS: 12 OZ.
LEAD STYLE -01, -02, -03: -02 THRU -50 (ALL
3. MINIMUM LOCKING CLIP RETENTION: 8 OZS.
POSITIONS AVAILABLE)
4. MAXIMUM HEIGHT VARIATION BETWEEN ANY TWO PINS: .005[0.13]
LEAD STYLES -11, -12, -13: (-05 THRU -50 MULTIPLES OF 5)
5. MAXIMUM TERMINAL BURR: .003[0.08]
POSITIONS 12, 16, 17 ALSO AVAILABLE
6. COPLANARITY: .004[0.10] = POS 02 THRU 26 C
LEAD STYLES -21, 22, 23: (-05 THRU -50 MULTIPLES OF 5)
.006[0.15] = POS 27 THRU 50
POSITIONS 12 & 13 ALSO AVAILABLE
7. MEASURED FROM BEND.
LEAD STYLES 31, 32: 12 POSITION ALSO AVAILABLE
8. DIMENSION CHANGED PER REVISION AD. CONTACT ENGINEERING
FOR INFORMATION.
9. MEASURE FROM TIPS OF PIN.
LEAD STYLE
10. THIS FEATURE ONLY PRESENT ON -01 &-02 LEAD STYLES.
THROUGH HOLE
SURFACE MOUNT
11. DUE TO THE HIGH AMOUNT OF INSERTION FORCE NEEDED,
-01, -03 (SEE FIG 1)
-02 (SEE FIG 2)
THE –LC OPTION IS NOT COMPATIBLE WITH AUTO PLACEMENT. SAMTEC
-11, -13 (SEE FIG 1)
-12 (SEE FIG 2)
RECOMMENDS MANUAL PLACEMENT FOR ALL ASSEMBLIES WITH THE
-21,-23 (SEE FIG 1)
-22 (SEE FIG 2)
–LC OPTION.
-31 (SEE FIG 1)
-32 (SEE FIG 2)
12. SIDES OF PLASTIC BODIES ON ALL LEAD STYLES EXCEPT THE -01, -02 & -03
PLATING SPECIFICATION
WILL BE SOLID AND WITHOUT SIDE SLOTS.
13. NOTE DELETED.
-S: 30µ" SELECTIVE GOLD ON CONTACT AREA,
(No OF POSITIONS x .050[1.27]) + .125[3.18] REF
(No OF POSITIONS x .050[1.27]) + .025[.64] REF
02
.110 2.79 REF
.155 3.94
REF
01
.075 1.91
REF
.050 1.27
REF
C
(No OF POSITIONS x .050[1.27]) - .050[1.27]
.018 0.46 REF
"A"
2 MAX SWAY
(EITHER DIRECTION)
.225 5.72
REF
SEE NOTE 10
MATTE TIN TAIL
-L: 15µ" SELECTIVE GOLD ON CONTACT AREA,
MATTE TIN TAIL
-F: 3µ" FLASH GOLD ON CONTACT AREA,
MATTE TIN TAIL
-H: 30µ" SELECTIVE GOLD ON CONTACT AREA,
3µ" FLASH GOLD ON TAIL
-SM: 30µ" SELECTIVE GOLD ON CONTACT AREA,
MATTE TIN TAIL
-LM: 15µ" SELECTIVE GOLD ON CONTACT AREA,
MATTE TIN TAIL
-FM: 3µ" FLASH GOLD ON CONTACT AREA,
MATTE TIN TAIL
-STL: 30µ" SELECTIVE GOLD ON CONTACT AREA,
TIN/LEAD (90/10 ±5%) TAIL
BODY SPECIFICATION
-D: DOUBLE ROW
.050 1.27
"D" REF
(SEE TABLE 1,
SHT 7)
.135 3.43 REF
2 MAX SWAY
(EITHER DIRECTION)
.1635 4.153
"A" REF
REF
(SEE TABLE 1,
SHT 7)
SEE NOTE 12
"A"
.014 0.36 REF
2 MAX SWAY
(EITHER DIRECTION)
C
(No OF POSITIONS x .050[1.27]) - .050[1.27]
C
"C"±.003 [0.08]
C
(SEE TABLE 1,
SHT 7)
.010 0.25 REF
C
"J" ± .003 [0.08]
(SEE TABLE 1, SHT 7)
.096 2.44
(SEE NOTE 8)
.050 1.27
C
2 MAX SWAY
(EITHER DIRECTION)
SECTION "A"-"A"
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
ANGLES
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
THROUGH HOLE
-01, -03, -11, -13, -21, -23, -31
FIG 1
.XX: .01[0.3]
2
.XXX: .005[0.13]
.XXXX: .0020[0.051]
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
IN-PROCESS
F:\DWG\MISC\MKTG\TFM-1XX-XX-XXX-D-XXX-MKT.SLDDRW
INSULATOR:
LCP, UL 94-VO
COLOR: BLACK
TERMINAL: PHOSPHOR BRONZE
.050 X .050 TERMINAL STRIP
BY:
garyp
TFM-1XX-XX-XXX-D-XXX
11/5/2014
SHEET
1
OF
7
REVISION FD
"B"
"K"±.006[0.15]
(SEE TABLE 1,SHT 7)
C
90°
3
2
C
SEE NOTE 6
.217 5.50
REF
"E"
(SEE TABLE 1,
SHT 7)
SEE NOTE 12
C
3 MAX SWAY
(EITHER DIRECTION)
"B"
C
FLUSH TO .012 [0.30] MAX
(SEE NOTE 7)
7 (-12, -22 & -32 STYLES)
3 (-02 STYLE ONLY)
.235 5.97 MAX
"S"
(SEE NOTE)
"R"
(SEE NOTE)
SEE NOTE 10
"E"
(SEE TABLE 1,
SHT 7)
01 03
SECTION "B"-"B"
02
No OF POSITIONS x .050) - .050[1.27]
(TOL ACCUM ±.005[0.13]
OVER 50 POS)
SEE NOTE 10
SURFACE MOUNT
-02, -12, -22, -32
DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1
"A" REF
(SEE TABLE 1,
SHT 7)
TERMINAL 2
(SEE TABLE 1, SHT 7)
TERMINAL 1
(SEE TABLE 1, SHT 7)
FIG 2
NOTE: “R” = OVERALL LENGTH (REF)
“S” = {(“R” - .216[5.49] /2} ±.020[.51]
-K: POLYIMIDE FILM PAD
.005±.020 0.13±0.508
FIG 3
02
NOTCH TO BE
ORIENTED AS SHOWN
"C"
(No OF POSITIONS X .050[1.27]) + .263[6.68] REF
"D"
TFM-XX-D-XX-WT
WT-25-04-T
01
.075 1.91 REF
.014 0.36
REF (TYP)
"C"
2 MAX SWAY
(EITHER DIRECTION)
C
C
90°
.020 0.51
C
(SEE NOTE 9 &
TABLE 1, SHT 7)
C
.093 2.36 (TYP)
.010 0.25
REF (TYP)
(No OF POSITIONS x .050[1.27]) + .154[3.91]
.050 1.27
C
(SEE NOTE 9 &
TABLE 1, SHT 7)
"D"
.025 0.64 REF
2 MAX SWAY
(EITHER DIRECTION)
SECTION "D"-"D"
-RA OPTION
DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1
.422 10.72
"A" REF
(SEE TABLE 1,
SHT 7)
.422 10.72
TERMINAL 2
(SEE TABLE 1,
SHT 7)
FIG 5
SECTION "C"-"C"
-WT OPTION
DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1
FIG 6
TERMINAL 2
(SEE TABLE 1,
SHT 7)
TERMINAL 1
(SEE TABLE 1,
SHT 7)
F:\DWG\MISC\MKTG\TFM-1XX-XX-XXX-D-XXX-MKT.SLDDRW
CARRIER STRIP
I.D. MARK
C
90°
.075 1.91 REF
TERMINAL 1
(SEE TABLE 1, SHT 7)
.020 0.51
C
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
(ORIENT I.D. MARK AS SHOWN)
(FOR -RA OPTION ONLY)
IN-PROCESS 1
DO NOT SCALE DRAWING
.050 X .050 TERMINAL STRIP
IN-PROCESS 2
SHEET SCALE: 2:1
BY:
garyp
TFM-1XX-XX-XXX-D-XXX
11/5/2014
SHEET
2
OF
7
REVISION FD
"P"
(SEE NOTE)
"M"
(SEE NOTE)
C
(No OF POSITIONS x .050[1.27]) + .075[1.91]
.045 1.14
REF
R.025 [0.64] REF
.050 1.27
REF
.394 10.01
REF
.050 1.27
"E"
*PPP-04
.225 5.72
REF
-A OPTION
DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1
C
L
FIG 8
C
L
"E"
SECTION "E"-"E"
SM-A5
(No OF POSITIONS x .050[1.27])
+ .075[1.91]
+.008[0.20]
-.009[0.23]
.050 1.27
.035 0.89
REF
2 MAX SWAY
(EITHER DIRECTION)
NOTE: “M” = (No. OF POSITIONS X .050[1.27]) + .125[3.18] (REF)
WITH -WT “M” = (No. OF POSITIONS X .050[1.27]) + .263[6.68] (REF)
“P” = {(“M” - .394[10.01]) /2} ±.020[.51]
* NOTCH ON PAD TO BE ON SAME END
AS THE NOTCH IN THE TFM BODY
-SA OPTION: STAKED ALIGNMENT PIN
DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1
(No OF POSITIONS x .050[1.27]) + .275 REF
TFM-XX-D-01-SN
"K"
C
L
FLUSH TO .005[0.13]
ABOVE
FIG 9
-P OPTION
DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1
(PAD TO BE POSITIONED ON C.L. AS SHOWN)
FIG 7
TFM-1XX-02-D-LC
C
L
WT-27-XX-T
"K"
"B" REF
.075 1.91 REF
.050 1.27
C
LC-05-TM
2 MAX SWAY
(EITHER DIRECTION)
.056 1.42 REF
.010 0.25 REF
2 MAX SWAY
(EITHER DIRECTION)
2 MAX SWAY
(EITHER DIRECTION)
(No OF POSITIONS x .050[1.27]) + .175[4.45]
SECTION "K"-"K"
.026 0.66 REF
-SNX: SOLDER NAIL
DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1
F:\DWG\MISC\MKTG\TFM-1XX-XX-XXX-D-XXX-MKT.SLDDRW
PROPRIETARY NOTE
FIG 12
((No OF POS x .050[1.27]) + .075[1.91])±.002[0.05]
-LC OPTION
DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1
(NOT AVAILBLE ON -RA)
FIG 10
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.050 X .050 TERMINAL STRIP
BY:
garyp
TFM-1XX-XX-XXX-D-XXX
11/5/2014
SHEET
3
OF
7
