Part Number

Search

3-210797-3

Description
SOCKET, PGA145, IC SOCKET
CategoryThe connector    socket
File Size109KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

3-210797-3 Overview

SOCKET, PGA145, IC SOCKET

3-210797-3 Parametric

Parameter NameAttribute value
Objectid1669506304
Reach Compliance Codeunknown
ECCN codeEAR99
Contact to complete cooperationGOLD (30)
Contact completed and terminatedGOLD (10) OVER NICKEL
Device slot typeIC SOCKET
Type of equipment usedPGA145
Shell materialPOLYETHYLENE
JESD-609 codee4
Manufacturer's serial number210797
Number of contacts145
My Account
Tyco Electronics
(C hange)
Se arch by Ke yword or Part #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Socket/C ard Products
>
Product Feature Selector
> Product Details
3-210797-3 Product Details
Live Product Chat
PGA Sockets
Not re vie we d for R oHS C om pliance
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3-210797-3
T E I nternal N umber: 3 - 2 1 0 7 9 7 - 3
Product Highlights:
l
Ultra Low Insertion Force
l
145 Positions
l
PC B Mount Style = Through Hole
l
Grid Size = 15x15
l
Grid Spacing = Standard: 2.54 x 2.54 mm
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Insertion Force
= Ultra Low
l
Number of Positions
= 145
l
PC B Mount Style = Through Hole
l
Grid Size
= 15x15
l
Grid Spacing (mm [in])
= Standard: 2.54 x 2.54 [.100 x .100]
l
C hip C ompatibility
= Other
l
Frame Style
= Open
l
Sleeve Material = Brass
l
Heat Sink Attachment
= Without
l
Profile
= Standard
l
Leg Style = Standard
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.84 [0.112]
l
Socket Identifier = None
l
Solder Tail C ontact Plating = Gold over Nickel
Body Related Features:
l
Assembly Process Feature = None
l
Socket Overall Height (mm [in]) = 4.46 [0.176]
Contact Related Features:
l
C ontact Style
= Stamped + Formed
l
C ontact Base Material
= Beryllium C opper
l
C ontact Plating, Mating Area, Material = Gold (30)
l
Sleeve Plating = Gold (10) over Nickel
Housing Related Features:
l
Housing C olor = Black
l
Housing Material = Thermoplastic - GF
l
Housing Flammability Rating = UL 94V-0
l
Housing Material Temperature = High
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Operation/Application:
l
Application
= Production
Packaging Related Features:
l
Packaging Method = Tube
Other:
l
Brand = AMP
