NJM14558
DUAL OPERATIONAL AMPLIFIER
■ GENERAL DESCRIPTION
The NJM14558 is a dual operational amplifier, which can
operate from ±2V supply. The features are low offset voltage,
low bias current and low current consumption.
The package lineup is DIP, DMP and others, so that the
NJM14558 is suitable for portable audio and any kind of signal
amplifier.
■ FEATURES
● Operating Voltage
±2.0V~±7.0V
● Input Offset Voltage
3mV max.
● Slew Rate
2.5V/μs typ.
● Bipolar Technology
● Package Outline
DIP8, DMP8, SOP8 JEDEC 150mil
SSOP8,SIP8,
MSOP8 (VSP8)
MEET JEDEC MO-187-DA
■ PIN CONFIGURATION
( Top View )
1
2
3
4
A
B
■ PACKAGE OUTLINE
NJM14558D
NJM14558M
(DIP8)
(DMP8)
NJM14558E
NJM14558V
(SOP8)
(SSOP8)
NJM14558R
NJM14558L
(MSOP8(VSP8))
(SIP8)
8
7
6
5
A
B
1
2
3
4
5
6
7
8
NJM14558D/14558M/14558E
NJM14558V/14558R
NJM14558L
PIN FUNCTION
1.A OUTPUT
2.A –INPUT
3.A +INPUT
-
4.V
5.B +INPUT
6.B –INPUT
7.B OUTPUT
+
8. V
■ EQUIVALENT CIRCUIT
( 1/2 Shown )
V+
-INPUT
+INPUT
OUTPUT
V-
Ver.2014-06-05
-1-
NJM14558
■ABSOLUTE
MAXIMUM RATINGS
(Ta=25˚C)
PARAMETER
Supply Voltage
Differential Input Voltage
Input Voltage
SYMBOL
+ -
V /V
V
ID
V
IC
RATINGS
± 7.5
± 14
± 7 ( note )
( DIP8 ) 500
( DMP8 ) 300
( SOP8 ) 300
( SSOP8 ) 250
( MSOP8(VSP8) ) 320
( SIP8 ) 800
-40~+85
-40~+125
UNIT
V
V
V
Power Dissipation
P
D
mW
Operating Temperature Range
Storage Temperature Range
T
opr
T
stg
˚C
˚C
( note ) For supply voltage less than ±7V,the absolute maximum input voltage is equal to the supply voltage.
■ ELECTRICAL CHARACTERISTICS(
V
+
/V
-
=±5V
,
Ta=25˚C )
PARAMETER
Operating Voltage
Input Offset Voltage
Input Offset Current
Input Bias Current
Input Resistance
Large Signal Voltage Gain
Maximum Output Voltage Swing (+ )
Maximum Output Voltage Swing ( - )
Input Common Mode Voltage Range
Common Mode Rejection Ratio
Supply Voltage Rejection Ratio
Operating Current
Slew Rate
Equivalent Input Noise Voltage
Gain Bandwidth Product
SYMBOL
V
opr
V
IO
I
IO
I
B
R
IN
A
V
+
V
OM
-
V
OM
V
ICM
CMR
SVR
I
CC
SR
V
NI
GB
TEST CONDITION
R
S
≤
10kΩ
MIN.
±2
-
-
-
0.3
86
3.5
-
± 3.0
70
76.5
-
-
-
-
TYP.
-
0.5
5
70
5
100
4.0
-3.5
± 4.0
90
90
2.7
2.5
1.4
5
MAX.
±7
3
50
250
-
-
-
-3.0
-
-
-
4.5
-
-
-
UNIT
V
mV
nA
nA
MΩ
dB
V
V
V
dB
dB
mA
V/μs
μVrms
MHz
R
L
≥2kΩ,V
O
=±3V
R
L
≥2kΩ
R
L
≥2kΩ
R
S
≤
10kΩ
R
S
≤
10kΩ
RIAA,R
S
=
2.2kΩ,30kHz:LPF
-2-
Ver.2014-06-05
NJM14558
■ TYPICAL CHARACTERISTICS
Operating Current vs. Operating Voltage
4
3.5
(Ta=25ºC)
Input Offset Voltage vs. Operating Voltage
3
2.5
(Ta=25ºC)
Input Offset Voltage V
IO
[mV]
0
±2
±4
±6
Operating VoltageV+/V- [V]
Operating Current I
cc
[mA]
2
1.5
1
0.5
0
-0.5
-1
-1.5
-2
-2.5
-3
±2
±4
±6
Operating VoltageV+/V- [V]
Maximum Output Voltage Swing
vs. Operating Voltage
(Ta=25ºC)
3
2.5
2
1.5
1
0.5
0
Input Bias Current vs. Operating Voltage
Maximum Output Voltage Swing V
OM
[V]
±2
±4
±6
Operating VoltageV+/V- [V]
±8
100
90
(Ta=25ºC)
6.5
4.5
2.5
0.5
-1.5
-3.5
-5.5
-7.5
±2
±4
±6
Operating VoltageV+/V- [V]
Input Bias Current I
B
[nA]
80
70
60
50
40
30
20
10
0
Input Common Mode Voltage Range
3
2.5
(V /V =±5V, Ta=25ºC )
+
-
Input Offset Voltage V
IO
[mV]
2
1.5
1
0.5
0
-0.5
-1
-1.5
-2
-2.5
-3
-3.5
-2.5
-1.5 -0.5 0.5
1.5
IN
[V]
Input Voltage V
2.5
3.5
Ver.2014-06-05
-3-
NJM14558
■ TYPICAL CHARACTERISTICS
Maximum Output Voltage Swing
vs. Load Resistance
5
4.5
4
3.5
3
2.5
2
1.5
1
0.5
0
-0.5
-1
-1.5
-2
-2.5
-3
-3.5
-4
-4.5
-5
100
(V /V =±5V, Ta=25ºC )
+
-
Maximum Output Voltage Swing
vs.Frequency
Maximum Output Voltage Swing V
OPP
[V]
Maximum Output Voltage Swing V
OM
[V]
10
(V /V =±5V, Ta=25ºC)
+
-
8
6
4
2
0
10
100
1k
10k
Frequency f [Hz]
100k
1M
1k
10k
Load Resistance R
L
[Ω]
100k
-4-
Ver.2014-06-05
NJM14558
■ TYPICAL CHARACTERISTICS
Large signal Voltage Gain vs. Operating Voltage
160
(Ta=25ºC)
Large signal Voltage Gain vs. Frequency
50
(V /V =±5V, Ta=25ºC)
+
-
200
180
140
120
100
80
60
40
20
0
±2
±4
±6
Operating VoltageV+/V- [V]
Large signal Voltage Gain Av [dB]
Large signal Voltage Gain A
v
[dB]
45
40
35
30
25
20
15
10
5
0
100
1k
gain
phase
140
120
100
80
60
40
20
10k
100k
Frequency f [Hz]
1M
0
10M
Slew Rate(Fall)
Slew Rate(Rise)
input Voltage
Output Voltage V
o
[V]
V /V =±5V
V:1V/div
t:400nS/div
Ta=25ºC
+
-
Output Voltage V
o
[V]
V
+
/V
-
=±5V
V:1V/div
t:400nS/div
Ta=25ºC
input Voltage
Time t
Time t
THD vs. Output Voltage
10
Equivalent Input Noise Voltage vs. Frequency
Equivalent Input Noise Voltage[nV/Hz]
(V =±5V, Ta=25ºC)
+
1000
(V /V =±5V, Ta=25ºC)
+
-
1
THD[%]
0.1
20kHz
100
0.01
20Hz,1kHz
0.001
0.0001
0.1
1
Output Voltage V
o
[Vrms]
10
10
1
10
100
Frequency f [Hz]
1k
Ver.2014-06-05
-5-
Phase Margin φ[deg]
160
