ISL8840A, ISL8841A, ISL8842A,
ISL8843A, ISL8844A, ISL8845A
Data Sheet
April 18, 2007
FN6320.3
High Performance Industry Standard
Single-Ended Current Mode PWM
Controller
The ISL884xA is a high performance drop-in replacement for
the popular 28C4x and 18C4x PWM controllers suitable for a
wide range of power conversion applications including
boost, flyback, and isolated output configurations. Its fast
signal propagation and output switching characteristics
make this an ideal product for existing and new designs.
Features include 30V operation, low operating current, 90μA
start-up current, adjustable operating frequency to 2MHz,
and high peak current drive capability with 20ns rise and fall
times.
PART NUMBER
ISL8840A
ISL8841A
ISL8842A
ISL8843A
ISL8844A
ISL8845A
RISING UVLO
7.0
7.0
14.4V
8.4V
14.4V
8.4V
MAX. DUTY CYCLE
100%
50%
100%
100%
50%
50%
Features
• 1A MOSFET gate driver
• 90μA start-up current, 125μA maximum
• 35ns propagation delay current sense to output
• Fast transient response with peak current mode control
• 30V operation
• Adjustable switching frequency to 2MHz
• 20ns rise and fall times with 1nF output load
• Trimmed timing capacitor discharge current for accurate
deadtime/maximum duty cycle control
• 1.5MHz bandwidth error amplifier
• Tight tolerance voltage reference over line, load and
temperature
• ±3% current limit threshold
• Pb-free plus anneal available
and ELV, WEEE, RoHS
Compliant
Applications
• Telecom and datacom power
• Wireless base station power
• File server power
• Industrial power systems
• PC power supplies
• Isolated buck and flyback regulators
• Boost regulators
Pinout
ISL8840A, ISL8841A, ISL8842A, ISL8843A, ISL8844A, ISL8845A
(8 LD SOIC, MSOP)
TOP VIEW
COMP 1
FB 2
CS 3
RTCT 4
8 VREF
7 VDD
6 OUT
5 GND
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 1-888-468-3774
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright © Intersil Americas Inc. 2005, 2006, 2007. All Rights Reserved.
All other trademarks mentioned are the property of their respective owners.
ISL8840A, ISL8841A, ISL8842A, ISL8843A, ISL8844A, ISL8845A
Ordering Information
PART
NUMBER*
ISL8840AABZ
(See Note)
PART
MARKING
8840 AABZ
TEMP.
PACKAGE PKG.
RANGE (°C) (Pb-free) DWG. #
-40 to +105 8 Ld SOIC
M8.15
Ordering Information
(Continued)
PART
NUMBER*
PART
MARKING
TEMP.
PACKAGE PKG.
RANGE (°C) (Pb-free) DWG. #
-55 to +125 8 Ld SOIC
M8.15
ISL8843AMBZ 8843 AMBZ
(See Note)
ISL8843AMUZ 43AMZ
(See Note)
ISL8844AABZ
(See Note)
8844 AABZ
ISL8840AAUZ 40AAZ
(See Note)
ISL8840AMBZ 8840 AMBZ
(See Note)
ISL8840AMUZ 40AMZ
(See Note)
ISL8841AABZ
(See Note)
8841 AABZ
-40 to +105 8 Ld MSOP M8.118
-55 to +125 8 Ld SOIC
M8.15
-55 to +125 8 Ld MSOP M8.118
-40 to +105 8 Ld SOIC
M8.15
-55 to +125 8 Ld MSOP M8.118
-40 to +105 8 Ld SOIC
M8.15
ISL8844AAUZ 44AAZ
(See Note)
ISL8844AMBZ 8844 AMBZ
(See Note)
ISL8844AMUZ 44AMZ
(See Note)
ISL8845AABZ
(See Note)
8845 AABZ
-40 to +105 8 Ld MSOP M8.118
-55 to +125 8 Ld SOIC
M8.15
ISL8841AAUZ 41AAZ
(See Note)
ISL8841AMBZ 8841 AMBZ
(See Note)
ISL8841AMUZ 41AMZ
(See Note)
ISL8842AABZ
(See Note)
8842 AABZ
-40 to +105 8 Ld MSOP M8.118
-55 to +125 8 Ld SOIC
M8.15
-55 to +125 8 Ld MSOP M8.118
-40 to +105 8 Ld SOIC
M8.15
-55 to +125 8 Ld MSOP M8.118
-40 to +105 8 Ld SOIC
M8.15
ISL8845AAUZ 45AAZ
(See Note)
ISL8845AMBZ 8845 AMBZ
(See Note)
ISL8845AMUZ 45AMZ
(See Note)
-40 to +105 8 Ld MSOP M8.118
-55 to +125 8 Ld SOIC
M8.15
ISL8842AAUZ 42AAZ
(See Note)
ISL8842AMBZ 8842 AMBZ
(See Note)
ISL8842AMUZ 42AMZ
(See Note)
ISL8843AABZ
(See Note)
8843 AABZ
-40 to +105 8 Ld MSOP M8.118
-55 to +125 8 Ld SOIC
M8.15
-55 to +125 8 Ld MSOP M8.118
-55 to +125 8 Ld MSOP M8.118
-40 to +105 8 Ld SOIC
M8.15
*Add “-T” suffix for tape and reel.
NOTE: Intersil Pb-free plus anneal products employ special Pb-free
material sets; molding compounds/die attach materials and 100%
matte tin plate termination finish, which are RoHS compliant and
compatible with both SnPb and Pb-free soldering operations. Intersil
Pb-free products are MSL classified at Pb-free peak reflow
temperatures that meet or exceed the Pb-free requirements of
IPC/JEDEC J STD-020.
ISL8843AAUZ 43AAZ
(See Note)
-40 to +105 8 Ld MSOP M8.118
2
FN6320.3
April 18, 2007
