LOW PROFILE QT81, QT82, QT83
Q-TECH
CORPORATION
MINIATURE CLOCK OSCILLATORS
1.8 to 5.0Vdc - 300kHz to 160MHz
Description
Features
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Q-Tech’s surface mount 5 X 7 mm oscillator series consist
of an IC 5Vdc, 3.3Vdc, 2.5Vdc, 1.8Vdc clock square
wave generator and a miniature stripA quartz crystal built
T
in a low profile ceramic package with thru-hole, formed
lead, or gull wing. This is the smallest package Q-Tech
has ever offered for High Reliability applications.. The
lead forming can provide a solution for many applications
that require additional lead attachment from an outside
subcontractor.
Ordering Information
Q T8 1 H CD 1 0M -5 0 . 0 00 M H z
Q T 81 HC D 10 M - 50.000MHz
Solder Dip Option:
T = Standard
S = Solder Dip (*)
G = Solder Dip (*)
Output Frequency
Screening Option:
Blank = No Screening
M = Per MIL-PRF-55310, Level B
Frequency vs. Temperature Code:
= ± 75ppm at -55ºC to +125ºC
= ± 50ppm at -55ºC to +125ºC
= ± 100ppm at -55ºC to +125ºC
= ± 50ppm at -40ºC to +85ºC
= ± 75ppm at -60ºC to +125ºC
= ± 100ppm at -60ºC to +125ºC
See notes (**)
(Sample part number)
Applications
Made in the USA
ECCN: EAR99
Broad frequency range from 300kHz to 160MHz
Small footprint
LVHCMOS, HCMOS, and TTL compatible
5.0Vdc, 3.3Vdc, 2.5Vdc, 1.8Vdc supply
Able to meet 36000G shock, half sine, 0.5ms
Wide operating temperature range
Tri-State Output (Option D)
Hermetically sealed ceramic package
Fundamental and 3rd Overtone designs
Full or partial military screening tests available
Tape and reel packaging
Lead free tinning available
RoHS compliant
Logic & Supply Voltage:
HC = HCMOS
+5.0V
L = LVHCMOS +3.3V
N = LVHCMOS +2.5V
R = LVHCMOS +1.8V
See notes (**)
Tristate Option:
Blank = No Tristate
D = Tristate
Package:
81 = Thru-Hole
82 = Formed Lead
83 = Gull Wing
7
9
10
11
17
18
Available for temperatures up to +200ºC with Q-Tech MCM number.
(*) Hot Solder Dip options for an additional cost:
• Designed to meet today’s requirements for low voltage
applications
• High shock applications
• Gun launched munitions and systems
• Smart munitions
• Instrumentation
• Navigation
• Avionics
• Microprocessor clock
(**) Notes
• Supply voltage, frequency stability vs. temperature codes
may not be available in all frequencies.
• For Non-Standard requirements, contact Q-Tech Corporation
at Sales@Q-Tech.com
Specifications subject to change without prior notice.
S = Sn60/Pb40 per MIL-PRF 55310
G = Lead free Alloy SAC305 (96.5% Sn, 3% Ag, 0.5% Cu)
Q-TECH Corporation - 10150 W. Jefferson Boulevard, Culver City 90232 - Tel: 310-836-7900 - Fax: 310-836-2157 - www.q-tech.com
QPDS-0002 (Revision J, May 2018)
1
LOW PROFILE QT81, QT82, QT83
Q-TECH
CORPORATION
MINIATURE CLOCK OSCILLATORS
1.8 to 5.0Vdc - 300kHz to 160MHz
HC
300kHz — 50.000MHz
5.0Vdc ± 10%
7.0Vdc
See Option codes
See Option codes
20 mA max. - 300kHz ~ < 16MHz
25 mA max. - 16MHz ~ < 32MHz
35 mA max. - 32MHz ~ < 50MHz
6 mA max. - 300kHz ~
10 mA max. - 16MHz ~
20 mA max. - 32MHz ~
30 mA max. - 60MHz ~
40 mA max. - 100MHz ~
50 mA max. - 130MHz ~
< 16MHz
< 32MHz
< 60MHz
< 100MHz
< 130MHz
≤160MHz
-62ºC to + 125ºC
6 mA max. - 300kHz
15 mA max. - 40MHz
25 mA max. - 60MHz
35 mA max. - 85MHz
~ < 40MHz
~ < 60MHz
~ < 85MHz
~ ≤ 133MHz
4 mA max. - 300kHz
10 mA max. - 40MHz
20 mA max. - 50MHz
25 mA max. - 85MHz
~ < 40MHz
~ < 50MHz
~ < 85MHz
~ ≤ 100MHz
Electrical Characteristics
Output frequency range (Fo)
Supply voltage (Vdd)
Maximum Applied Voltage
(Vdd max.)
Parameters
L
300kHz — 160.000MHz
3.3Vdc ± 10%
N
300kHz — 133.000MHz
2.5Vdc ± 10%
5.0Vdc
R
300kHz — 100.000MHz
1.8Vdc ± 10%
Frequency stability (∆F/∆T)
Operating temperature (Topr)
Storage temperature (Tsto)
Operating supply current
(Idd) (No Load)
Symmetry
(50% of ouput waveform or
1.4Vdc for TTL)
Rise and Fall times
(with typical load)
Output Load
Start-up time (Tstup)
Output voltage (V ol)
oh/V
Output Current (Ioh/Iol)
Enable/Disable
Tristate function Pin 1
Aging (at 70ºC)
0.9 x Vdd min.; 0.1 x Vdd max.
± 24mA max.
VIH ≥ 2.2V Oscillation;
VIL ≤ 0.8V High Impedance
45/55% max. - 300kHz ~ < 21MHz
40/60% max. - 21 ~ ≤ 50MHz
6ns max. - Fo < 40MHz
3ns max. - Fo ≥ 40 - 50MHz
(between 10% to 90%)
15pF // 10kohms
50pF max. or 10TTL
45/55% max. - 300kHz ~ < 21MHz
40/60% max. - 21 ~ ≤ 160MHz
6ns max. - 300kHz ~ < 40MHz
3ns max. - 40 ~ ≤ 160MHz
(between 10% to 90%)
15pF // 10kohms
(30pF max. for F ≤ 50MHz)
10ms max.
45/55% max. - 300kHz ~ < 21MHz
40/60% max. - 21 ~ ≤ 133MHz
5ns max. - 300kHz ~ < 40MHz
3ns max. - 40 ~ ≤ 133MHz
(between 10% to 90%)
45/55% max. - 300kHz~ < 21MHz
40/60% max. - 21 ~ ≤ 100MHz
5ns max. - 300kHz ~ < 40MHz
3ns max. - 40 ~ ≤ 100MHz
(between 10% to 90%)
15pF // 10kohms
0.9 x Vdd min.; 0.1 x Vdd max.
± 4mA max.
VIH ≥ 0.7 x Vdd Oscillation;
VIL ≤ 0.3 x Vdd High Impedance
Jitter RMS 1σ (at 25ºC)
± 5ppm max. first year / ± 2ppm max. per year thereafter
-
10150 W. Jefferson Boulevard, Culver City 90232
-
Tel: 310-836-7900 - Fax: 310-836-2157
-
www.q-tech .co m
See Page 5
Q-TECH Corporation
QPDS-0002 (Revision J, May 2018)
2
LOW PROFILE QT81, QT82, QT83
Q-TECH
Package Outline and Pin Connections
Dimensions are in inches (mm)
CORPORATION
MINIATURE CLOCK OSCILLATORS
1.8 to 5.0Vdc - 300kHz to 160MHz
QT81
QT82
(4X)
R .200
(R .008)
.276 ± .006
(7.00 ± .200)
4
3
(4X)
R .200
(R .008)
4
QT83
.276 ± .006
(7.00 ± .200)
3
(4X)
R 0.20
(R .008)
0.276 ± .006
(7.0 ± 0.2)
4
3
0.197 ± .006
(5.00 ± 0.15)
P/N
FREQ.
D/C S/N
1
2
0.200 ± .008
(5.08 ± 0.2)
.197 ± .006
(5.00 ± .150)
P/N
FREQ.
D/C S/N
1
2
.200 ± .008
(5.08 ± .200)
.197 ± .006
(5.00 ± .150)
P/N
FREQ.
D/C S/N
1
.200 ± .008
(5.08 ± .200)
2
ESD SYMBOL
FOR PIN NO. 1
ESD SYMBOL
FOR PIN NO. 1
ESD SYMBOL
FOR PIN NO. 1
0.100
max.
(2.54)
0.028
(0.72)
0.040
(1.02)
.008
(.200)
.100
max.
(2.54)
.028
(.720)
.057 ± .005
(1.45 ± .130)
.008
(.200)
.100
max.
(2.54)
.028
(.720)
.063 ± .005
(1.60 ± .130)
0.008
(0.20)
0.200±.005
(5.80±0.13)
.018 ± .003
(.460 ± .080)
.018±.003
(.46 ± .08)
0.018±.003
(.46±0.08)
.216
(5.49)
.216
(5.49)
A’
.008
A’
.008
(.203)
0.200 ± .005
0.008 ± .001
(.20 ± 0.03)
0.205 ± .010
(5.20 ± 0.25)
(5.080 ± 0.13)
3º to 5º typ.
.062 ± .005
(1.57 ± .130)
(.203)
detail A’
.047 ± .005
(1.20 ± .130)
0.25
(6.35)
.250
(6.35)
.050
(1.27)
C BYPASS
Pin No.
1
2
3
4
TRISTA or N/C
TE
GND/CASE
OUTPUT
VDD
Function
0.05
(1.27)
C BYPASS
0.07
(1.78)
0.100
(2.54)
.130
(3.30)
.100
(2.54)
0.200 ± .008
(5.08 ± 0.2)
An external bypass capacitor 0.01µF
is required between Vdd and GND
.200 ± .008
(5.08 ± .203)
Q-TECH Corporation - 10150 W. Jefferson Boulevard, Culver City 90232 - Tel: 310-836-7900 - Fax: 310-836-2157 - www.q-tech.com
QPDS-0002 (Revision J, May 2018)
• Package material: 91% AL2O3
• Weight: .15g typ., 2g max.
• Lead material: Kovar
• Lead finish: Nickel Underplate: 100μ ~ 250μ inches
Gold Plated: 50μ ~ 80μ inches
Hot Solder Dip Sn60/Pb40 Finish (optional per P.O)
Lead Free Tinning (SAC305) finish (optional per P.O)
Package Information
Line 1: P/N (QT81L9M)
Line 2: Frequency (500.000K)
Line 3: ESD Symbol + D/C (
YYWW)
+ S/N
Marking Information
3
LOW PROFILE QT81, QT82, QT83
Q-TECH
Output Waveform (Typical)
SYMMETRY =
TH
T
Tr
VOH
Tf
Vdd
0.9xVdd
x 100%
CORPORATION
Test Circuit
+ mA
+
Power
supply
-
+
Vdc
-
MINIATURE CLOCK OSCILLATORS
1.8 to 5.0Vdc - 300kHz to 160MHz
Typical test circuit for CMOS logic
4
3
Output
QT81
0.1µF
or
1
2
0.01µF
15pF
(*)
10k
Ground
0.5xVdd
0.1xVdd
VOL
TH
GND
Tristate Function
Frequency vs. Temperature Curve
T
50
40
The Tristate function on pin 1 has a built-in pull-up resistor so it can be left
floating or tied to Vdd without deteriorating the electrical performance.
(*) CL includes probe and jig capacitance
FVT QT81LD10-20.000MHz
Embossed Tape and Reel Information for QT82
FEEDING (PULL) DIRECTION
2.0±0.1 4.0±0.1
1.75±0.1
0.3±.005
5°Max
Frequency Stability (PPM)
30
20
10
0
-10
Ø1.5
11.5
Ø1.5
12±0.1
26
2.0
Ø178±1
or
Ø330±1
-30
-40
-50
-55 -50 -45 -40 -35 -30 -25 -20 -15 -10 -5
7.70
0
5
10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105
Reflow Profile
TEMP(*C)
Temperature (°C)
TYPICAL REFLOW PROFILE FOR Sn-Pb ASSEMBLY
0.16
5.72±0.1
Ramp up (3ºC/s Max)
250
225
200
175
150
240º
Ø13.0±0.5
Ramp down (6ºC/s Max)
225º min.
240º max.
60s min.
150s max.
60s min.
120s max.
2.5
125
100
75
50
25
60s min.
120s max.
Dimensions are in mm. Tape is compliant to EIA-481-A.
120°
Time (s)
Environmental and Mechanical Specifications
0
0
20
40
60
80 100 120 140 160 180 200 220 240 260 280 300 320 340 360 380 400 420
Reel size (Diameter in mm)
178
Qty per reel (pcs)
1,000
Temperature cycling
Constant acceleration
Seal: Fine and Gross Leak
Vibration sinusoidal
Shock, non operating
Resistance to solder heat
Resistance to solvents
Solderability
ESD Classification
Moisture Sensitivity Level
Environmental Test
Test Conditions
MIL-STD-883, Method 1010, Cond. B
MIL-STD-883, Method 2001, Cond. A, Y1
MIL-STD-883, Method 1014, Cond. A and C
MIL-STD-202, Method 204, Cond. D
MIL-STD-202, Method 213, Cond. I
MIL-STD-202, Method 210, Cond. B
MIL-STD-202, Method 215
MIL-STD-202, Method 208
MIL-STD-883, Method 3015, Class 1 HBM 0 to 1,999V
J-STD-020, MSL=1
Q-TECH Corporation - 10150 W. Jefferson Boulevard, Culver City 90232 - Tel: 310-836-7900 - Fax: 310-836-2157 - www.q-tech.com
QPDS-0002 (Revision J, May 2018)
4
24.0±0.3
-20
P/N
FREQUENCY
D/C S/N
LOW PROFILE QT81, QT82, QT83
Q-TECH
Jitter And Phase Noise
CORPORATION
MINIATURE CLOCK OSCILLATORS
1.8 to 5.0Vdc - 300kHz to 160MHz
As data rate increases, effect of jitter becomes critical
with its budget tighter. Jitter is the deviation of a timing
event of a signal from its ideal position. Jitter is
complex and is composed of both random jitter (RJ) and
deterministic jitter (DJ) components.
Random Jitter (RJ) is theoretically unbounded and
Gaussian in distribution, while Deterministic Jitter (DJ)
is bounded and does not follow any predictable
distribution.
Q-Tech utilizes the EZJIT Plus jitter analysis software
with Noise reduction software that supports Agilent
Infinium real-time oscilloscope. Measure at its
maximum sampling rate 40Gs/s and memory depth, we
can separate the signal’s aggregate total jitter into
Random Jitter (RJ) and Deterministic Jitter (DJ).
Since Random Jitter is unbounded and Gaussian in
style, the Total Jitter is a function of Bit Error Rate
(BER).
Where:
10E-3
10E-6
10E-9
TJ = RJ + DJ
Figure 1: Jitter Analysis of a QT82LD-125MHZ
RJ = RJ(rms) x 2α + DJ(p-p)
BER
4.75
7.0
6
3.1
α
Typical Jitter at BER=10E-12
Frequency
16MHz (5.0V)
32MHz (3.3V)
40MHz (3.3V)
100MHz (3.3V)
125MHz (3.3V)
50MHz (5.0V)
2.7
2.2
10E-12
DJ
RJ
(p-p) ps (rms) ps
1.97
1.65
1.25
1.15
1.13
1.14
1.18
0.95
0.96
3.6
54.3
18.1
18.5
18.4
14.8
14.9
TJ
ps
Typical Phase Noise
Frequency
16MHz
32MHz
125MHz
40MHz
Figure 2: Jitter Analysis of a QT83HC-50MHZ
10Hz
-91
-77
-79
-74
100Hz
-122
-109
-106
-110
1kHz
-147
-133
-130
-133
10kHz
-158
-141
-141
-141
100kHz
-162
-145
-145
-146
1MHz
-166
-153
-152
-153
Phase Jitter
(ps) *
0.79
0.33
0.31
0.15
Q-TECH Corporation - 10150 W. Jefferson Boulevard, Culver City 90232 - Tel: 310-836-7900 - Fax: 310-836-2157 - www.q-tech.com
QPDS-0002 (Revision J, May 2018)
5
京公网安备 11010802033920号
EEWORLD
