Tantalum Surface Mount Capacitors – MIL–PRF (CWR Style)
T492 Series MIL–PRF–55365/8 (CWR11 Style)
Table 1 – Ratings & Part Number Reference
Rated
Voltage
VDC @ 85ºC
4
4
4
4
4
4
4
4
6
6
6
6
6
6
6
6
6
6
10
10
10
10
10
10
10
10
10
15
15
15
15
15
15
15
15
15
20
20
20
20
20
20
20
20
VDC @ 85ºC
Rated Case Code/
Case Size
Cap
µF
2.2
4.7
6.8
10
15
33
68
100
1.5
2.2
3.3
4.7
6.8
10
15
22
47
68
1
1.5
2.2
3.3
4.7
6.8
15
33
47
0.68
1
1.5
2.2
3.3
4.7
10
22
33
0.47
0.68
1
1.5
2.2
3.3
4.7
6.8
µF
KEMET/EIA
A/3216-18
A/3216-18
B/3528-21
B/3528-21
B/3528-21
C/6032-28
D/7343-31
D/7343-31
A/3216-18
A/3216-18
A/3216-18
B/3528-21
B/3528-21
B/3528-21
C/6032-28
C/6032-28
D/7343-31
D/7343-31
A/3216-18
A/3216-18
A/3216-18
B/3528-21
B/3528-21
B/3528-21
C/6032-28
D/7343-31
D/7343-31
A/3216-18
A/3216-18
A/3216-18
B/3528-21
B/3528-21
B/3528-21
C/6032-28
D/7343-31
D/7343-31
A/3216-18
A/3216-18
A/3216-18
B/3528-21
B/3528-21
B/3528-21
C/6032-28
C/6032-28
KEMET/EIA
KEMET Part
Number
(See below for
part options)
T492A225(1)004(2)(3)(4)
T492A475(1)004(2)(3)(4)
T492B685(1)004(2)(3)(4)
T492B106(1)004(2)(3)(4)
T492B156(1)004(2)(3)(4)
T492C336(1)004(2)(3)(4)
T492D686(1)004(2)(3)(4)
T492D107(1)004(2)(3)(4)
T492A155(1)006(2)(3)(4)
T492A225(1)006(2)(3)(4)
T492A335(1)006(2)(3)(4)
T492B475(1)006(2)(3)(4)
T492B685(1)006(2)(3)(4)
T492B106(1)006(2)(3)(4)
T492C156(1)006(2)(3)(4)
T492C226(1)006(2)(3)(4)
T492D476(1)006(2)(3)(4)
T492D686(1)006(2)(3)(4)
T492A105(1)010(2)(3)(4)
T492A155(1)010(2)(3)(4)
T492A225(1)010(2)(3)(4)
T492B335(1)010(2)(3)(4)
T492B475(1)010(2)(3)(4)
T492B685(1)010(2)(3)(4)
T492C156(1)010(2)(3)(4)
T492D336(1)010(2)(3)(4)
T492D476(1)010(2)(3)(4)
T492A684(1)015(2)(3)(4)
T492A105(1)015(2)(3)(4)
T492A155(1)015(2)(3)(4)
T492B225(1)015(2)(3)(4)
T492B335(1)015(2)(3)(4)
T492B475(1)015(2)(3)(4)
T492C106(1)015(2)(3)(4)
T492D226(1)015(2)(3)(4)
T492D336(1)015(2)(3)(4)
T492A474(1)020(2)(3)(4)
T492A684(1)020(2)(3)(4)
T492A105(1)020(2)(3)(4)
T492B155(1)020(2)(3)(4)
T492B225(1)020(2)(3)(4)
T492B335(1)020(2)(3)(4)
T492C475(1)020(2)(3)(4)
T492C685(1)020(2)(3)(4)
(See below for
part options)
MIL–PRF–55365/8
DC
Part Number
Leakage
(See below for
part options)
CWR11C(6)225(1)(2)(5)
CWR11C(6)475(1)(2)(5)
CWR11C(6)685(1)(2)(5)
CWR11C(6)106(1)(2)(5)
CWR11C(6)156(1)(2)(5)
CWR11C(6)336(1)(2)(5)
CWR11C(6)686(1)(2)(5)
CWR11C(6)107(1)(2)(5)
CWR11D(6)155(1)(2)(5)
CWR11D(6)225(1)(2)(5)
CWR11D(6)335(1)(2)(5)
CWR11D(6)475(1)(2)(5)
CWR11D(6)685(1)(2)(5)
CWR11D(6)106(1)(2)(5)
CWR11D(6)156(1)(2)(5)
CWR11D(6)226(1)(2)(5)
CWR11D(6)476(1)(2)(5)
CWR11D(6)686(1)(2)(5)
CWR11F(6)105(1)(2)(5)
CWR11F(6)155(1)(2)(5)
CWR11F(6)225(1)(2)(5)
CWR11F(6)335(1)(2)(5)
CWR11F(6)475(1)(2)(5)
CWR11F(6)685(1)(2)(5)
CWR11F(6)156(1)(2)(5)
CWR11F(6)336(1)(2)(5)
CWR11F(6)476(1)(2)(5)
CWR11H(6)684(1)(2)(5)
CWR11H(6)105(1)(2)(5)
CWR11H(6)155(1)(2)(5)
CWR11H(6)225(1)(2)(5)
CWR11H(6)335(1)(2)(5)
CWR11H(6)475(1)(2)(5)
CWR11H(6)106(1)(2)(5)
CWR11H(6)226(1)(2)(5)
CWR11H(1)336(1)(2)(5)
CWR11J(6)474(1)(2)(5)
CWR11J(6)684(1)(2)(5)
CWR11J(6)105(1)(2)(5)
CWR11J(6)155(1)(2)(5)
CWR11J(6)225(1)(2)(5)
CWR11J(6)335(1)(2)(5)
CWR11J(6)475(1)(2)(5)
CWR11J(6)685(1)(2)(5)
(See below for
part options)
µA @ +20ºC
Max/5 Min
0.5
0.5
0.5
0.5
0.6
1.3
2.7
4.0
0.5
0.5
0.5
0.5
0.5
0.6
0.9
1.3
2.8
4.1
0.5
0.5
0.5
0.5
0.5
0.7
1.5
3.3
4.7
0.5
0.5
0.5
0.5
0.5
0.7
1.5
3.3
5.0
0.5
0.5
0.5
0.5
0.5
0.7
0.9
1.4
µA @ +20ºC
Max/5 Min
DF
% @ +20ºC
120 Hz Max
6.0
6.0
6.0
6.0
6.0
6.0
6.0
8.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
4.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
4.0
4.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
4.0
4.0
4.0
6.0
6.0
6.0
6.0
6.0
% @ +20ºC
120 Hz Max
ESR
Ω @ +20ºC
100 kHz Max
8.0
8.0
5.5
4.0
3.5
2.2
1.1
0.9
8.0
8.0
8.0
5.5
4.5
3.5
3.0
2.2
1.1
0.9
10.0
8.0
8.0
5.5
4.5
3.5
2.5
1.1
0.9
12.0
10.0
8.0
5.5
5.0
4.0
2.5
1.1
0.9
14.0
12.0
10.0
6.0
5.0
4.0
3.0
2.4
Ω @ +20ºC
100 kHz Max
Maximum
Operating
Temp
ºC
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
ºC
MSL
Reflow Temp
≤ 260ºC
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Reflow Temp
≤ 260ºC
Rated
Voltage
Rated
Cap
Case Code/
Case Size
KEMET Part Number
MIL–PRF–55365/8
Part Number
DC
Leakage
DF
ESR
Maximum
Operating
Temp
MSL
(1) To complete KEMET/CWR part number, insert M for ±20%, K for ±10%, or J for ±5%. Designates Capacitance tolerance.
(2) To complete KEMET/CWR part number, insert failure rate letter per the Ordering Information found on page 2. Designates Reliability Level.
(3) To complete KEMET part number, insert B = Gold Plated, C = Hot solder dipped, H or S = Solder Plated or K = Solder Fused. Designates Termination Finish.
(4) To complete KEMET part number, insert 4250 = +25°C after Weibull, 4251 = -55°C +85°C after Weibull, or 4252 = -55°C +85°C before Weibull. Designates
Surge current option.
(5) To complete CWR part number, insert A = +25°C after Weibull, B = -55°C +85°C after Weibull, C = -55°C +85°C before Weibull or Z = None. Designates Surge
current option.
(6) To complete CWR part number, insert B = Gold Plated, C = Hot Solder Dipped, H = Solder Plated or K = Solder Fused. Designates Termination Finish.
Refer to Ordering Information for additional detail.
